Airtac SGD Series Steel Tube Type Double Rod Cylinder SGD160X1000
2. SG Series features dual Y-type single-acting piston seals with automatic compensation, ensuring extended service life and low starting pressure. SGC Series adopts profiled dual-acting seal configuration for compact design and integrated oil reservoir capability;
3. SG Series utilizes cold drawn steel tubing construction with superior impact resistance;
4. SGC Series employs precision aluminum tubing with optional embedded sensor magnets (not compatible with SG Series);
5. Equipped with adjustable pneumatic cushioning mechanism for smooth deceleration control;
6. Comprehensive size range with multiple mounting accessories for flexible system integration;
7. Engineered with high humidity-resistant sealing compounds for operational temperature range of 0-150°C.
Category: Twin Shaft Cylinders | Brand: AIRTAC | Series: SGD
AirTAC SGD160X1000 Steel Tube Type Double Rod Cylinder Specifications
- Model: SGD160X1000
- Bore size: Ø160mm
- Stroke: 1000mm (customizable 50-3000mm)
- Operating pressure: 0.1-1.0 MPa
- Action type: Double acting
- Cushion type: Adjustable hydraulic buffer (both ends)
- Temperature range: -20℃ to 80℃
- Port size: Rc1" (NPT1" optional)
- Piston rod thread: M33×2 (both ends)
- Rod diameter: Ø45mm
- Rod material: Chrome-plated carbon steel
- Tube material: Cold drawn precision steel tube
- Mounting type: Fixed/Flange (ISO/VDMA standard)
- Weight: ~23.6kg (without accessories)
- Dimensions: 1218mm(L) × 204mm(W) × 204mm(H)
- Lubrication: Pre-lubricated (Use ISO VG32 pneumatic oil)
- Protection rating: IP65 (Dust-proof & water jet resistant)
Heavy-duty industrial cylinder with dual hardened steel guide rods for enhanced moment resistance and alignment stability. Features corrosion-resistant steel construction with double lip seals for ≤0.5m/min leakage rate. Includes magnetic piston for sensor mounting (sensor not included). Requires 40μm filtered air with 1-5μm oil mist lubrication for optimal performance.
- Automotive welding fixture positioning systems
- Steel coil handling equipment
- Injection molding machine ejectors
- Large-format CNC material clamping
- Shipbuilding jig alignment mechanisms
Installation note:
Must use alignment jigs during mounting to prevent rod binding.
Support rod ends every 500mm stroke length beyond 1500mm stroke.
Allow 0.05mm/mm thermal expansion clearance in high-temperature environments.
| Property | Property Value |
|---|---|
| sku | SGD160X1000 |
| Seal Material | NBR |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | BSPT 3/4 |
| Cushion Stroke | <50mm> |
| Bore Diameter | 160mm |
| Stroke | <1000mm> |
