Airtac F-HLSL-BF Retracting End with Hydraulic Cushion Complete Assembly F-HLSL25BF
AirTAC F-HLSL-BF Series Rear-Mounted Hydraulic Shock Absorber Kit - F-HLSL25BF
- Model: F-HLSL25BF
- Type: Adjustable hydraulic cushion with rear flange mounting
- Maximum impact energy: 0.15 N·m
- Stroke range: 15-30 mm (factory pre-set)
- Applicable piston rod diameter: Ø25 mm ±0.5 mm
- Maximum impact speed: 0.8 m/s
- Operating temperature: -20℃ to 80℃
- Housing material: Anodized aluminum alloy (AL6063-T5)
- Piston material: Stainless steel (SUS304)
- Seal type: High-temperature NBR seals
- Oil viscosity grade: ISO VG15 hydraulic fluid
- Adjustment method: Hex wrench fine-tuning (2.5mm tool included)
- Weight: 0.62 kg ±3%
- Dimensions: Ø25mm × 85mm (L) (excluding mounting flange)
- Flange size: 40mm × 40mm × 8mm (L×W×T)
- Surface treatment: Electrophoretic black coating (8-12μm)
Professional-grade hydraulic damper designed for precision deceleration in linear motion systems. Features micron-level oil filtration and multi-stage buffering technology that reduces terminal impact force by up to 85% compared to standard buffers. The sealed oil circuit with pressure compensation maintains consistent performance across temperature variations.
- High-cycle pneumatic cylinder end-of-stroke damping
- Robotic arm joint shock absorption
- Packaging machine vertical lifting mechanisms
- CNC tool changer positioning systems
- Automated warehouse stacker cranes
Installation note:
Mount perpendicular to impact direction using M5×16mm screws (8.8 grade min).
Perform 50-100 test cycles before full operation. Relubricate every 500,000 cycles
using AirTAC HLP-15 oil. Avoid side-load forces exceeding 20N.
| Property | Property Value |
|---|---|
| sku | F-HLSL25BF |
| Bore Diameter | <25 mm> |
