Airtac F-HLSL-BF Retracting End with Hydraulic Cushion Complete Assembly F-HLSL8BF
$34.86
Regular price
$42.36
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
F-HLSL8BF
Product type:
Tags:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
Category: Cylinder Accessories
Brand: AirTAC
Series: F-HLSL-BF Rear End Hydraulic Shock Absorber Complete Kit
Professional Description:
AirTAC F-HLSL-BF series represents a precision-engineered rear-mounted hydraulic cushioning solution for pneumatic cylinders, optimized for industrial automation systems requiring precision deceleration control. This complete assembly integrates a multi-stage buffering mechanism with adjustable oil viscosity compensation, ensuring smooth end-stroke energy absorption while minimizing piston rod rebound. Features include:
- Progressive damping force (5-15 N·m adjustable range)
- Compact T-slot mounting design compatible with ISO 15552 cylinder standards
- Temperature-resistant hydraulic fluid (-10°C to +80°C operational range)
- Hardened stainless steel impact rod with chromium-plated surface treatment
- Integrated buffer force indicator window for visual maintenance checks
- IP67 protection rating with fluorine rubber seals
Technical Specifications:
Max. cushioning capacity: 1.6 J/stroke
Operating pressure range: 0.1-1.0 MPa
Fluid viscosity grade: ISO VG 32 anticorrosive hydraulic oil
Impact velocity: ≤ 1.5 m/s
Meets ISO 6431 and VDMA 24562 standards for industrial cylinder accessories
Installation protocol:
Mount perpendicular to motion axis using supplied M5 screws (3.5N·m torque max).
Perform 10-15 test strokes before final adjustment. Maintain 15mm clearance
behind flange for maintenance access. Re-lubricate every 500,000 cycles.
Critical note:
Not compatible with phosphate ester fluids. Avoid side-load forces exceeding 20N.
Break-in period of 50 cycles required for optimal damping consistency.
AirTAC F-HLSL-BF Rear-Mounted Hydraulic Shock Absorber Kit (F-HLSL8BF)
- Model Series: F-HLSL-BF (Complete Kit)
- Specific Model: F-HLSL8BF
- Type: Adjustable hydraulic cushioning with rear flange mount
- Bore Size: Ø8mm piston diameter
- Stroke: 10mm standard cushion length
- Max. Absorption Energy: 0.65 N·m/stroke
- Max. Impact Speed: 0.8 m/s
- Operating Pressure: 0.05-1.0 MPa
- Operating Temperature: -10℃ to 80℃
- Fluid Compatibility: ISO VG32-68 hydraulic oil
- Body Material: Anodized aluminum alloy (AL6063)
- Seal Material: Nitrile rubber (NBR) + Special polyurethane
- Weight: 280g ±5% (including mounting hardware)
- Dimensions: 52mm(L) × 32mm(W) × 32mm(H) (flange base to tip)
- Mounting Thread: M5×0.8 internal thread (rear side)
- Surface Treatment: Black electrophoretic coating
- Adjustment Type: 4-stage damping force via rotary valve (tool-operated)
Precision-engineered hydraulic damper with multi-stage adjustment, designed for decelerating linear actuators in confined spaces. Features corrosion-resistant construction with integrated debris wipers and thermal compensation valve. Includes pre-lubricated seals and anti-vibration lock nuts for stable performance.
Typical Applications:
- Pneumatic cylinder end-of-stroke cushioning
- Pick-and-place robot arm shock absorption
- Packaging machine stopper mechanisms
- Automated assembly line indexing units
- Elevator door buffer systems
Installation protocol:
Mount perpendicular to motion axis using supplied M5 screws (3.5N·m torque max).
Perform 10-15 test strokes before final adjustment. Maintain 15mm clearance
behind flange for maintenance access. Re-lubricate every 500,000 cycles.
Critical note:
Not compatible with phosphate ester fluids. Avoid side-load forces exceeding 20N.
Break-in period of 50 cycles required for optimal damping consistency.
| Property | Property Value |
|---|---|
| sku | F-HLSL8BF |
| Bore Diameter | <8mm> |
