Airtac 2WH High-Pressure Solenoid Valve 2WH030-06-E
2、Wide pressure range applicability - available in Ultra-high pressure (X), High pressure (H), Standard, Large flow (L), and Super-large flow (T) variants;
3、Compact structure with minimized dimensions, lightweight design, and tool-free installation;
4、Brass valve body construction with Class B thermal-rated coil. Standard FPMF (Fluoroelastomer Viton®) seals compatible with multiple media. Custom seal materials available upon request (consult technical department);
5、IP65-rated coil protection. Wiring options: Direct lead wire or DIN connector configuration.
Category: High Pressure Solenoid Valves | Brand: AIRTAC | Series: 2WH
AirTAC 2WH030-06-E High Pressure Solenoid Valve Specifications
- Model: 2WH030-06-E
- Type: 2-position, 3-way normally closed (direct-acting)
- Port size: 1/8" NPT (G1/8 optional)
- Operating pressure: 0.5–16 MPa (72–2320 PSI)
- Max pressure rating: 20 MPa (2900 PSI)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: 3.5W (DC), 4.5VA (AC)
- Flow coefficient (Cv): 0.65
- Response time: ≤15ms (open/close)
- Seal material: Fluorocarbon rubber (FKM) standard (NBR optional)
- Temperature range: -10℃ to 120℃ (FKM seals)
- Protection rating: IP67 (dustproof/water immersion resistant)
- Electrical connection: DIN43650 Form A (direct plug-in)
- Weight: 320g ±5% (with connector)
- Dimensions: 78mm(L) × 42mm(W) × 45mm(H) (excluding mounting bracket)
High-pressure industrial solenoid valve featuring reinforced stainless steel core tube and shock-resistant coil design. Engineered for extreme pressure environments with 20MPa burst pressure certification. The hardened brass body includes anti-vibration mounting points and corrosion-resistant nickel plating. Requires minimum 10μm filtration and automatic drain maintenance for sustained performance.
- Hydraulic system pilot controls
- CNC machine tool clamping mechanisms
- High-pressure gas chromatography equipment
- Industrial boiler safety shut-off systems
- Automotive brake testing rigs
- Plastic injection molding machines
Installation note:
Mount with pressure direction arrow aligned to flow. Allow 15-minute
degaussing period after continuous 8-hour operation. Lubricate seals
with ISO VG32 hydraulic oil during maintenance.
| Property | Property Value |
|---|---|
| sku | 2WH030-06-E |
| Port Size | PT1/8 |
| Flow Aperture | <2mm> |
| Coil Voltage | AC24V |
