Airtac 2WH High-Pressure Solenoid Valve 2WH03008-X0
2、Wide pressure range applicability - available in Ultra-high pressure (X), High pressure (H), Standard, Large flow (L), and Super-large flow (T) variants;
3、Compact structure with minimized dimensions, lightweight design, and tool-free installation;
4、Brass valve body construction with Class B thermal-rated coil. Standard FPMF (Fluoroelastomer Viton®) seals compatible with multiple media. Custom seal materials available upon request (consult technical department);
5、IP65-rated coil protection. Wiring options: Direct lead wire or DIN connector configuration.
Category: High Pressure Solenoid Valves | Brand: AIRTAC | Series: 2WH
AirTAC 2WH030-08X0 High-Pressure Solenoid Valve Specifications
- Model: 2WH030-08X0 (2WH03008-X0)
- Type: 2-position 3-way direct-acting (monostable)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.5–21 MPa (7–3,046 PSI)
- Voltage options: DC24V (±10%), AC110V 50/60Hz, AC220V 50/60Hz
- Weight: 1.2 kg (2.65 lbs)
- Dimensions: 72mm(L) × 55mm(W) × 98mm(H)
- Seal material: HNBR rubber (fluorocarbon optional)
- Temperature range: -5℃ to 80℃ (23℉ to 176℉)
- Flow coefficient (Cv): 1.8
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Protection rating: IP67 (dustproof/water immersion resistant)
- Port thread depth: 13mm (male thread)
Heavy-duty high-pressure solenoid valve engineered for industrial hydraulic systems requiring precise fluid control under extreme pressures. Features hardened stainless steel plunger, electromagnetic shielding design, and surge protection circuitry. Requires 40μm filtration and ISO VG32/46 hydraulic oil compatibility.
- Hydraulic press clamping/feeding systems
- CNC machine tool coolant control
- High-pressure lubrication systems (≥15MPa)
- Injection molding machine hydraulic circuits
- Pressure testing rigs for industrial valves
- Construction equipment hydraulic actuators
Installation requirements:
Mount horizontally with arrow aligned to flow direction.
Maintain minimum 50mm clearance below coil for heat dissipation.
Use backup power supply for voltage-sensitive applications.
Replace seals every 5 million cycles under 15MPa operation.
| Property | Property Value |
|---|---|
| sku | 2WH03008-X0 |
| Port Size | PT1/4 |
| Flow Aperture | <2mm> |
| Coil Voltage | DC24V |
