Airtac 2WH High-Pressure Solenoid Valve 2WH03008CI
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2、Wide pressure range applicability - available in Ultra-high pressure (X), High pressure (H), Standard, Large flow (L), and Super-large flow (T) variants;
3、Compact structure with minimized dimensions, lightweight design, and tool-free installation;
4、Brass valve body construction with Class B thermal-rated coil. Standard FPMF (Fluoroelastomer Viton®) seals compatible with multiple media. Custom seal materials available upon request (consult technical department);
5、IP65-rated coil protection. Wiring options: Direct lead wire or DIN connector configuration.
Category: High Pressure Solenoid Valves | Brand: AIRTAC | Series: 2WH
AirTAC 2WH03008CI High-Pressure Solenoid Valve Technical Details
- Model: 2WH03008CI
- Type: 2-position, 3-way direct-acting (Normally Closed)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.5–15 MPa (7–2175 PSI)
- Voltage variants: DC24V (±10%), AC220V 50/60Hz
- Flow coefficient (Cv): 0.8
- Max flow rate: 800 L/min (ANR)
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Seal materials: FKM (Fluorocarbon rubber) main seals, NBR (Nitrile) secondary seals
- Ambient temperature: -10℃ to 150℃ (with FKM seals)
- Fluid temperature: 5℃ to 60℃
- Power consumption: ≤2.5W (DC), ≤3.5VA (AC)
- Protection class: IP67 (dust-tight, protected against temporary immersion)
- Weight: 320g ±5% (without connector)
- Dimensions: 60mm(L) × 40mm(W) × 80mm(H) (manual override adds 12mm)
- Port thread depth: 12mm (minimum engagement)
High-pressure industrial solenoid valve with military-grade brass body construction, designed for aggressive hydraulic and pneumatic systems. Features zero-pressure differential operation capability and shock-resistant coil design. Requires 10μm filtration (recommended ISO 4406 18/16/13 cleanliness). Compatible with air, light hydraulic oils (ISO VG32 or lower), and inert gases.
- Hydraulic press clutch/brake systems
- Injection molding machine ejectors
- CNC tool changer mechanisms
- High-pressure gas chromatography systems
- Industrial laser cooling circuits
- Hydrostatic test rigs
Installation criticals:
Must be mounted horizontally (±15° tolerance). Always install downstream surge suppressor for AC models.
Pipe connections require PTFE tape with 1.5-2 wraps maximum. Torque specification: 18-22 N·m for port threads.
| Property | Property Value |
|---|---|
| sku | 2WH03008CI |
| Port Size | PT1/4 |
| Flow Aperture | <2mm> |
| Coil Voltage | AC 110V |
