Airtac 2WH High-Pressure Solenoid Valve 2WH03008F
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2、Wide pressure range applicability - available in Ultra-high pressure (X), High pressure (H), Standard, Large flow (L), and Super-large flow (T) variants;
3、Compact structure with minimized dimensions, lightweight design, and tool-free installation;
4、Brass valve body construction with Class B thermal-rated coil. Standard FPMF (Fluoroelastomer Viton®) seals compatible with multiple media. Custom seal materials available upon request (consult technical department);
5、IP65-rated coil protection. Wiring options: Direct lead wire or DIN connector configuration.
Category: High Pressure Solenoid Valves | Brand: AIRTAC | Series: 2WH
AirTAC 2WH030-08F High Pressure Solenoid Valve Technical Details
- Model: 2WH030-08F
- Type: 3-position 5-way direct acting (closed center)
- Port size: PT1/4 (G1/4 adaptor available)
- Operating pressure: 0.5–12 MPa (high pressure series)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 350g ±5% (including coil)
- Dimensions: 80mm(L) × 45mm(W) × 60mm(H) (manual override version adds 15mm)
- Seal material: FKM fluorocarbon (standard) / Special seals available for >150℃
- Temperature range: -10℃ to 80℃ (standard) / -20℃ to 150℃ (high-temp variant)
- Power consumption: 2.5W (DC) / 5VA (AC)
- Protection rating: IP67 (coil protection)
- Flow coefficient (Cv): 1.8 (at 7 bar)
- Response time: ≤15ms (pressurized) / ≤30ms (vacuum)
- Port thread depth: 12mm (minimum engagement)
Industrial-grade high-pressure solenoid valve with triple-spool design for precision flow control in extreme conditions. Features hardened stainless steel plunger and military-grade epoxy-coated coil housing. Requires 10μm filtration (25μm max) with oil mist lubrication recommended for >5MPa operation. Includes LED status indicator and manual override capability.
- Injection molding machine hydraulic circuits
- CNC press brake pressure sequencing
- High-pressure pneumatic test benches (leak testing systems)
- Hydraulic pressurization systems for aerospace components
- Mining equipment pneumatic controls
- High-speed packaging lines with servo coordination
Installation requirements:
Mount with vibration-damping brackets when used in mobile machinery.
Maintain 20mm clearance on all sides for heat dissipation during continuous operation.
Pipe alignment must be stress-free - use flexible connectors if necessary.
| Property | Property Value |
|---|---|
| sku | 2WH03008F |
| Port Size | PT1/4 |
| Flow Aperture | <2mm> |
| Coil Voltage | DC12V |
