Airtac 2WH High-Pressure Solenoid Valve 2WH05010A
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2、Wide pressure range applicability - available in Ultra-high pressure (X), High pressure (H), Standard, Large flow (L), and Super-large flow (T) variants;
3、Compact structure with minimized dimensions, lightweight design, and tool-free installation;
4、Brass valve body construction with Class B thermal-rated coil. Standard FPMF (Fluoroelastomer Viton®) seals compatible with multiple media. Custom seal materials available upon request (consult technical department);
5、IP65-rated coil protection. Wiring options: Direct lead wire or DIN connector configuration.
Category: High Pressure Solenoid Valves | Brand: AIRTAC | Series: 2WH
AirTAC 2WH05010A High-Pressure Solenoid Valve Specifications
- Model: 2WH05010A
- Type: 5/2-way monostable (direct-acting)
- Port size: PT1/4 (G1/4 thread standard)
- Operating pressure: 0.3–1.0 MPa (high-pressure optimized)
- Max pressure: 1.5 MPa (instantaneous peak)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: 2.5W (DC), 5VA (AC)
- Weight: 680g ±2% (including coil)
- Dimensions: 76mm(L) × 45mm(W) × 105mm(H) (body only)
- Port spacing: 33mm (between inlet/outlet ports)
- Seal material: HNBR rubber (high-pressure resistant)
- Temperature range: -10℃ to 80℃ (with dry air)
- Protection rating: IP67 (dust/water resistant)
- Response time: ≤15ms (at 0.5MPa)
- Flow coefficient: CV 1.8 (Kv 1.56)
- Manual override: Built-in emergency button
High-torque solenoid valve engineered for industrial hydraulic/pneumatic systems requiring stable performance under sustained high pressure. Features double-seal structure with wear compensation and copper-free aluminum alloy body meeting ISO/CE standards. Compatible with compressed air, inert gases (N2), and vacuum systems.
- Hydraulic press clamping sequence control
- Plastic injection molding machine actuators
- CNC machine tool pneumatic tool changers
- High-speed packaging line cylinder control
- Elevator braking system safety circuits
Installation requirements:
Mount horizontally with arrow direction matching airflow. Use vibration-damping mounts in environments exceeding 0.5G vibration. Lubricate with ISO VG32 turbine oil if operated >8hrs/day. Replace seals every 500,000 cycles in high-load applications.
- Filtered air (40μm mesh required)
- Non-corrosive gases (dew point -25℃)
- Non-lubricated operation permitted
- Mineral oil mist lubrication acceptable (ISO VG32)
| Property | Property Value |
|---|---|
| sku | 2WH05010A |
| Port Size | PT3/8 |
| Flow Aperture | <4mm> |
| Coil Voltage | AC220V |
