Airtac 2WH High-Pressure Solenoid Valve 2WH05010AI
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2、Wide pressure range applicability - available in Ultra-high pressure (X), High pressure (H), Standard, Large flow (L), and Super-large flow (T) variants;
3、Compact structure with minimized dimensions, lightweight design, and tool-free installation;
4、Brass valve body construction with Class B thermal-rated coil. Standard FPMF (Fluoroelastomer Viton®) seals compatible with multiple media. Custom seal materials available upon request (consult technical department);
5、IP65-rated coil protection. Wiring options: Direct lead wire or DIN connector configuration.
Category: High Pressure Solenoid Valves | Brand: AIRTAC | Series: 2WH
AirTAC 2WH05010AI High-Pressure Solenoid Valve Technical Details
- Model: 2WH05010AI
- Type: 2-position 5-way direct-acting (monostable)
- Port configuration: 1/4" NPT (G1/4 optional)
- Operating pressure range: 0.5–21 MPa (72.5–3045 PSI)
- Voltage variants: DC12V/24V (±10%), AC110V/220V (±15%)
- Coil insulation class: Class F (155℃)
- Flow coefficient (Cv): 1.8
- Max operating frequency: 5 Hz
- Weight: 850g ±3% (including coil)
- Dimensions: 110mm(L) × 55mm(W) × 70mm(H)
- Seal materials: HNBR + FKM composite
- Ambient temperature: -40℃ to 120℃ (non-freezing)
- Power consumption: 3.5W (DC), 4.2VA (AC)
- Protection class: IP67 (dust/water resistant)
- Response time: ≤15ms (energize), ≤20ms (de-energize)
Industrial-grade high-pressure valve engineered for extreme pneumatic systems, featuring dual-coil thermal protection and shock-resistant brass construction. The hardened stainless steel spool ensures 2 million+ cycle durability. Includes manual override and LED status indicator. Requires ISO 8573-1:2010 Class 3 compressed air (max 5mg/m³ oil content).
- Hydraulic pressurization systems in die-casting machines
- High-speed stamping equipment tool changers
- CNC machine coolant flow control
- Oil & gas pipeline pressure regulation
- Automotive brake testing rigs
- Plastic injection molding machines
Installation guidelines:
Mount horizontally with flow arrow alignment. Use 20-30Nm torque for port connections.
Install upstream 40μm filter and downstream silencer. Allow 15-minute cool-down after
continuous 8-hour high-pressure operation.
| Property | Property Value |
|---|---|
| sku | 2WH05010AI |
| Port Size | PT3/8 |
| Flow Aperture | <4mm> |
| Coil Voltage | AC220V |
