Airtac 2WH High-Pressure Solenoid Valve 2WH05010B
2、Wide pressure range applicability - available in Ultra-high pressure (X), High pressure (H), Standard, Large flow (L), and Super-large flow (T) variants;
3、Compact structure with minimized dimensions, lightweight design, and tool-free installation;
4、Brass valve body construction with Class B thermal-rated coil. Standard FPMF (Fluoroelastomer Viton®) seals compatible with multiple media. Custom seal materials available upon request (consult technical department);
5、IP65-rated coil protection. Wiring options: Direct lead wire or DIN connector configuration.
Category: High Pressure Solenoid Valves | Brand: AIRTAC | Series: 2WH
AirTAC 2WH05010B High-Pressure Solenoid Valve Specifications
- Model: 2WH05010B
- Type: 2-position 5-way direct-acting solenoid valve
- Port size: G1/8 (ISO228 standard)
- Operating pressure range: 0.5-16 MPa (72-2320 PSI)
- Maximum pressure: 25 MPa (burst pressure)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: 1.6W (DC), 3.5VA (AC)
- Weight: 520g ±2% (with connector)
- Dimensions: 98mm(L) × 34mm(W) × 55mm(H) (body only)
- Port thread depth: 12mm (4.7") with PTFE sealing tape requirement
- Seal material: Fluorocarbon rubber (FKM) for high-temperature resistance
- Temperature range: -20℃ to 150℃ (medium temperature), -5℃ to 80℃ (ambient)
- Protection rating: IP67 (dust tight & protected against temporary immersion)
- Response time: ≤15ms (at 20℃, nominal pressure)
- Flow coefficient (Cv): 1.2 (at 7 bar)
- Porting pattern: ISO 5599-1 standard
Industrial-grade high-pressure solenoid valve with reinforced brass body and hardened stainless steel core tube. Features double-sealing structure with dustproof plunger and surge protection circuit. Requires compressed air or inert gas with ≤50μm filtration. Compatible with vacuum applications when using special seals (optional).
- Hydraulic system pilot controls in injection molding machines
- High-pressure air compressors (15-20MPa range)
- CNC machine tool clamping mechanisms
- Automotive testing equipment pressure regulation
- Foundry pneumatic systems with high-temperature environments
- Underwater cutting equipment (utilizing IP67 protection)
Installation guidelines:
Mount with actuation axis ±5° from vertical position. Use copper seal washers (not included) for port connections exceeding 10MPa. Allow 30-minute run-in period at 50% rated pressure before full-load operation. Lubrication oil viscosity must be ISO VG32 or equivalent if used.
| Property | Property Value |
|---|---|
| sku | 2WH05010B |
| Port Size | PT3/8 |
| Flow Aperture | <4mm> |
| Coil Voltage | DC24V |
