Airtac 2WH High-Pressure Solenoid Valve 2WH05010BI
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2、Wide pressure range applicability - available in Ultra-high pressure (X), High pressure (H), Standard, Large flow (L), and Super-large flow (T) variants;
3、Compact structure with minimized dimensions, lightweight design, and tool-free installation;
4、Brass valve body construction with Class B thermal-rated coil. Standard FPMF (Fluoroelastomer Viton®) seals compatible with multiple media. Custom seal materials available upon request (consult technical department);
5、IP65-rated coil protection. Wiring options: Direct lead wire or DIN connector configuration.
Category: High Pressure Solenoid Valves | Brand: AIRTAC | Series: 2WH
AirTAC 2WH05010BI High-Pressure Solenoid Valve Specifications
- Model: 2WH05010BI
- Type: 2-position, 5-port direct-acting solenoid valve
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.5–21 MPa (72.5–3045 PSI)
- Max flow rate: 1800 NL/min (ANR)
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: DC: 5.5W / AC: 7.5VA
- Weight: 480g ±2%
- Dimensions: 78mm(L) × 50mm(W) × 64mm(H)
- Seal material: FKM fluorocarbon rubber
- Temperature range: -10℃ to 150℃ (non-freezing)
- Response time: ≤15ms (excitation), ≤20ms (reset)
- Protection rating: IP67 (dustproof & temporary immersion)
- Port thread depth: 12mm (both inlet/outlet)
- Mounting orientation: Any (horizontal/vertical)
Heavy-duty high-pressure solenoid valve with military-grade sealing technology, featuring reinforced stainless steel plunger and anti-vibration coil design. Optimized for systems requiring rapid cycling under extreme pressures. Includes manual override button for emergency operation and status indication LED (DC models only). Requires ISO 8573-1 class 3 filtered air (max 5μm particles).
- Hydraulic system pressure regulation in injection molding machines
- High-pressure pneumatic testing equipment (leak detectors, burst testers)
- CNC machine tool clamping/unclamping mechanisms
- Power plant steam control systems
- Mining equipment pneumatic circuits
- High-altitude aviation ground support systems
Installation protocol:
Apply 20-30Nm torque during port connection. Use shock-absorbing mounts
in high-vibration environments. Perform 10-15 test cycles before full-load
operation. Replace seals every 500,000 cycles or 2 years (whichever comes first).
| Property | Property Value |
|---|---|
| sku | 2WH05010BI |
| Port Size | PT3/8 |
| Flow Aperture | <4mm> |
| Coil Voltage | DC24V |
