Airtac 2WH High-Pressure Solenoid Valve 2WH05010CI
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2、Wide pressure range applicability - available in Ultra-high pressure (X), High pressure (H), Standard, Large flow (L), and Super-large flow (T) variants;
3、Compact structure with minimized dimensions, lightweight design, and tool-free installation;
4、Brass valve body construction with Class B thermal-rated coil. Standard FPMF (Fluoroelastomer Viton®) seals compatible with multiple media. Custom seal materials available upon request (consult technical department);
5、IP65-rated coil protection. Wiring options: Direct lead wire or DIN connector configuration.
Category: High Pressure Solenoid Valves | Brand: AIRTAC | Series: 2WH
AirTAC 2WH05010CI High-Pressure Solenoid Valve Specifications
- Model: 2WH05010CI
- Type: 5/2-way mono-stable (pilot-operated)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.5–21 MPa
- Max pressure resistance: 31.5 MPa
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 320g ±5%
- Dimensions: 60mm(L) × 50mm(W) × 85mm(H)
- Valve body material: Anodized aluminum alloy
- Seal material: HNBR rubber (high-pressure resistant)
- Temperature range: -20℃ to 80℃ (with intermittent 100℃ tolerance)
- Power consumption: ≤3.5W
- Response time: ≤15ms (open), ≤20ms (close)
- Flow coefficient (Cv): 1.8
- Protection rating: IP67 (dustproof & temporary immersion)
- Port thread depth: 12mm (double O-ring sealing)
Industrial-grade high-pressure solenoid valve with reinforced structure for extreme pneumatic systems. Features dual-chamber pilot mechanism for reliable switching under 21MPa load. The hard-anodized body resists particle erosion in hydraulic hybrid applications. Requires 10μm filtration for optimal service life.
- Injection molding machine clamp force control
- Die-casting equipment pressure sequencing
- Hydraulic test bench pressure regulation
- CNC punch press cylinder actuation
- Offshore platform blowout preventer systems
Installation criticals:
Always install with pressure direction arrow alignment. Use backup flange supports
when pipe vibration exceeds 0.5mm amplitude. Perform monthly manual override tests
in continuous duty cycles. Lubricate only with ISO VG32 hydraulic oil if required.
| Property | Property Value |
|---|---|
| sku | 2WH05010CI |
| Port Size | PT3/8 |
| Flow Aperture | <4mm> |
| Coil Voltage | AC 110V |
