Airtac 2WH High-Pressure Solenoid Valve 2WH05010E
2、Wide pressure range applicability - available in Ultra-high pressure (X), High pressure (H), Standard, Large flow (L), and Super-large flow (T) variants;
3、Compact structure with minimized dimensions, lightweight design, and tool-free installation;
4、Brass valve body construction with Class B thermal-rated coil. Standard FPMF (Fluoroelastomer Viton®) seals compatible with multiple media. Custom seal materials available upon request (consult technical department);
5、IP65-rated coil protection. Wiring options: Direct lead wire or DIN connector configuration.
Category: High Pressure Solenoid Valves | Brand: AIRTAC | Series: 2WH
AirTAC 2WH05010E High-Pressure Solenoid Valve Specifications
- Model: 2WH05010E
- Type: 5/2-way direct-acting (high-pressure optimized)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.5–21 MPa (7–3,045 PSI)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (±15%), AC220V (±15%)
- Weight: 1.2 kg (2.65 lbs)
- Dimensions: 128mm(L) × 46mm(W) × 72mm(H)
- Seal material: FKM fluorocarbon rubber (high-pressure grade)
- Temperature range: -10℃ to 120℃ (with intermittent peak at 150℃)
- Power consumption: 4.5W (DC24V), 5.5VA (AC220V)
- Response time: ≤15ms (pressurized), ≤25ms (exhaust)
- Flow coefficient (Cv): 2.8
- Protection rating: IP67 (dust/water resistant)
- Port thread depth: 13mm (both sides)
High-performance solenoid valve engineered for extreme pressure environments, featuring dual-coil heat dissipation technology and tungsten carbide-coated spool. Optimized for hydraulic/pneumatic hybrid systems requiring rapid cycling (up to 15Hz). Includes manual override and surge protection circuitry. Requires ISO 8573-1:2010 Class 3 compressed air.
- Hydraulic pressurization systems in die-casting machines
- High-pressure gas control in CNC machining centers
- Subsea equipment pressure balancing systems
- Industrial boiler safety venting mechanisms
- Automotive brake system testing rigs
Installation guidelines:
Mount with vibration-damping brackets in high-shock environments.
Maintain minimum 50mm clearance from heat sources above 80℃.
Use Loctite 542 thread sealant for port connections.
Pre-lubricate with ISO VG32 hydraulic oil during assembly.
| Property | Property Value |
|---|---|
| sku | 2WH05010E |
| Port Size | PT3/8 |
| Flow Aperture | <4mm> |
| Coil Voltage | AC24V |
