Airtac 3V-F Base 3V100M1F
The AirTAC Airtac 3V-F Base 3V100M1F is a genuine 3V-F manifold base manifold base for 1 stations on one shared air supply. A base is a machined block: it carries no coil and no solenoid, so the valves that sit on it are ordered separately.
- Valve type3/2-way (3-port, 2-position)
- Stations1
- Series3V-F manifold base
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac 3V-F Base 3V100M1F
The 3V100M1F is a genuine AirTAC manifold base in the 3V1x0 family, machined to carry a single 3/2 solenoid valve on one shared air supply. As a base it contains no coil, so it has no voltage, no electrical state and no power draw of its own - it is the mounting and air-distribution block, and the valve that sits on it is ordered separately. Its single station means one valve position fed from one inlet, which keeps the piping short and gives you a clean single point of isolation if that circuit ever needs attention.
We stock this base as a genuine AirTAC part and ship it with the matching 3V1x0 valves it accepts. Across the family you can order both NC and NO valves, all five coil voltages, and either DIN plug or flying-lead electrical entry, so the same base supports very different control panels. If you need a datasheet figure for the base or the valve you plan to mount on it, ask us and we will confirm it from the datasheet before you commit.
Airtac 3V-F Base 3V100M1F Technical Specifications
| Model | Airtac 3V-F Base 3V100M1F |
|---|---|
| Series | 3V-F manifold base |
| Item form | Manifold base (no coil, no solenoid, no initial state) |
| Stations | 1 |
| Port size | Confirm from the datasheet — ask us |
| Thread | PT |
| Operating pressure | Confirm from the datasheet — ask us |
|---|---|
| Flow coefficient | Confirm from the datasheet — ask us |
| Temperature | Confirm from the datasheet — ask us |
| Protection | Confirm from the datasheet — ask us |
Model Code: Airtac 3V-F Base 3V100M1F
| 3V-F manifold base | Body. |
|---|---|
| 1F | 1 stations in one assembly. |
| PT | Port thread. PT ships from stock; G and NPT are available to order. |
What a 3/2 Valve Does
A 3/2 valve has three ports — supply, outlet and exhaust — and two states. It either feeds the outlet or vents it to exhaust, and that is the whole job.
That makes it the right valve for a single-acting (spring-return) cylinder, on/off air blow, a clamp, switching a vacuum generator or suction cup, and piloting a larger valve.
It cannot run a double-acting cylinder. A double-acting cylinder needs air alternately on two sides, which takes a 5-port valve — the AirTAC 4V series.
Where the Airtac 3V-F Base 3V100M1F Is Used
Single-circuit drop on a production line
One base, one valve, one feed: mount a single 3/2 valve to switch air to a small workholder or air jet at one station of an assembly bench, with the base giving a tidy supply connection instead of loose pipework.
Clamp-and-release fixture on a welding jig
A spring-return clamp cylinder needs air in one direction only, which is exactly what a 3/2 valve delivers. A single-station base keeps that clamp circuit separate so it can be maintained without disturbing neighbours.
First position of a growing control panel
Starting a manifold with one valve now leaves room to add stations later on the same supply philosophy - one air feed, one wiring loom, and a fault-finding path that stays simple as the machine grows.
Is the Airtac 3V-F Base 3V100M1F the Right Part?
Start from the valve, not the base: the valve you mount decides the port size, the NC or NO state and the coil voltage, and the base simply carries it on a shared supply. Choose the valve state by what must happen on power loss - a normally closed valve gives no air at the outlet until energised, a normally open valve vents only when energised. Match the coil voltage to your panel supply, because a solenoid coil cannot be rewired to a different voltage. Pick DIN plug entry for a socketed connection or a flying lead for a pre-wired one. Because published flow figures for the 3V1x0 family are not in our hands, send us the actuator you intend to drive and we will confirm sizing before you order. If you want a fully specified 3-port valve with published flow and coil power today, look at the documented 3V2 (1/8in and 1/4in) or 3V3 (1/4in) direct-acting bodies. And if the job is a double-acting cylinder, no 3/2 valve will do it - that needs a 5-port valve from the AirTAC 4V series.
Confirm before you order
- ✓ Port size and thread (PT from stock; G / NPT to order)
- ✓ Initial state — NC or NO, ordered up front
- ✓ Coil voltage matches your controller output
- ✓ Electrical entry — DIN plug or flying lead
- ✓ Single valve, bare base, or complete assembly
- ✓ Single-acting duty, not double-acting
Installation & Wiring Notes
- check Use clean air filtered to 40µm or finer.
- check Use the manual override to test before powering up.
- check Leave the exhaust port clear, or fit a silencer.
- check Blank any unused station on the base before pressurising.
- check Wiring by qualified personnel, per AirTAC documentation.
Airtac 3V-F Base 3V100M1F FAQ
The 3V1x0 family carries no published figures in our catalogue, so we do not print numbers we cannot stand behind. Send us an RFQ and we will confirm the datasheet figures for the exact valve you plan to mount. If you need published flow and coil power in hand today, the documented AirTAC 3V2 and 3V3 direct-acting bodies have full datasheets you can compare before ordering.
The 3V100M1F is a manifold block only - it has no coil and does nothing until a 3/2 valve is fitted, so order the valve separately. Note that no 3/2 valve can drive a double-acting cylinder: that needs pressurised air to two ports in alternation, which is a 5-port job. Use the AirTAC 4V series for that, and keep a 3/2 for single-acting cylinders, blow-off and piloting.
