Airtac 3V-F Base 3V100M3F
The AirTAC Airtac 3V-F Base 3V100M3F is a genuine 3V-F manifold base manifold base for 3 stations on one shared air supply. A base is a machined block: it carries no coil and no solenoid, so the valves that sit on it are ordered separately.
- Valve type3/2-way (3-port, 2-position)
- Stations3
- Series3V-F manifold base
About the Airtac 3V-F Base 3V100M3F
The 3V100M3F is a machined manifold base with three stations for 3/2 solenoid valves from the AirTAC 3V1 family. Instead of plumbing and wiring each valve individually, you mount the valves on one block that carries a single shared air supply. One feed in, three valve positions out, one wiring path along the manifold.
This is a genuine AirTAC part. The 3V1 valve family covers both NC and NO states, five coil voltages (AC220V, DC24V, AC110V, AC24V, DC12V) and both DIN plug and flying-lead entries, with bases from 1F up to 20F stations, so a matching valve set can be configured around this base. Raise an RFQ and we will pull the datasheet to confirm the figures for your build.
Airtac 3V-F Base 3V100M3F Technical Specifications
| Model | Airtac 3V-F Base 3V100M3F |
|---|---|
| Series | 3V-F manifold base |
| Item form | Manifold base (no coil, no solenoid, no initial state) |
| Stations | 3 |
| Port size | Confirm from the datasheet — ask us |
| Thread | PT |
| Operating pressure | Confirm from the datasheet — ask us |
|---|---|
| Flow coefficient | Confirm from the datasheet — ask us |
| Temperature | Confirm from the datasheet — ask us |
| Protection | Confirm from the datasheet — ask us |
Model Code: Airtac 3V-F Base 3V100M3F
| 3V-F manifold base | Body. |
|---|---|
| 3F | 3 stations in one assembly. |
| PT | Port thread. PT ships from stock; G and NPT are available to order. |
What a 3/2 Valve Does
A 3/2 valve has three ports — supply, outlet and exhaust — and two states. It either feeds the outlet or vents it to exhaust, and that is the whole job.
That makes it the right valve for a single-acting (spring-return) cylinder, on/off air blow, a clamp, switching a vacuum generator or suction cup, and piloting a larger valve.
It cannot run a double-acting cylinder. A double-acting cylinder needs air alternately on two sides, which takes a 5-port valve — the AirTAC 4V series.
Where the Airtac 3V-F Base 3V100M3F Is Used
Compact control panel
Three spring-return functions on a small machine - a clamp, a blow-off nozzle and piloting a larger valve - mount side by side on one base.
Packaging line sub-panel
A packaging cell with a handful of single-acting cylinders runs its 3/2 valves from one shared feed, so a single shutoff isolates the whole group.
Machine retrofit panel
When rebuilding an older fixture, a three-station base replaces three loose valves and their separate plumbing with one tidy block.
Is the Airtac 3V-F Base 3V100M3F the Right Part?
Choose the station count to match the number of 3/2 functions your machine needs, then order each valve separately with the state, port size, coil voltage and electrical entry you want. A three-station base suits a compact panel where three spring-return functions sit close together. Because published flow figures for this family are not in our hands, send us the actuator details and we will confirm sizing before you order; if you need a fully documented 3-port valve today, the AirTAC 3V2 (1/8in and 1/4in) and 3V3 (1/4in) bodies have published flow and coil-power figures. A double-acting cylinder needs a 5-port valve from the AirTAC 4V series instead.
Confirm before you order
- ✓ Port size and thread (PT from stock; G / NPT to order)
- ✓ Initial state — NC or NO, ordered up front
- ✓ Coil voltage matches your controller output
- ✓ Electrical entry — DIN plug or flying lead
- ✓ Single valve, bare base, or complete assembly
- ✓ Single-acting duty, not double-acting
Installation & Wiring Notes
- check Use clean air filtered to 40µm or finer.
- check Use the manual override to test before powering up.
- check Leave the exhaust port clear, or fit a silencer.
- check Blank any unused station on the base before pressurising.
- check Wiring by qualified personnel, per AirTAC documentation.
Airtac 3V-F Base 3V100M3F FAQ
We confirm operating pressure, flow and coil power from the AirTAC datasheet on request - just raise an RFQ. If you need published figures right now, the AirTAC 3V2 and 3V3 valve bodies have documented flow and coil-power data.
No. The 3V100M3F is the manifold block only; each 3/2 valve is ordered separately with its own state, port, coil voltage and electrical entry, and slots onto the shared supply.
