Airtac 3V-F Base 3V100M5F
The AirTAC Airtac 3V-F Base 3V100M5F is a genuine 3V-F manifold base manifold base for 5 stations on one shared air supply. A base is a machined block: it carries no coil and no solenoid, so the valves that sit on it are ordered separately.
- Valve type3/2-way (3-port, 2-position)
- Stations5
- Series3V-F manifold base
About the Airtac 3V-F Base 3V100M5F
The 3V100M5F carries five 3/2 valves from the AirTAC 3V1 series on a single machined base with one shared air inlet. Consolidating five valves onto one block shortens the tubing run, cuts the number of individual connections that can leak, and puts every coil on one wiring route.
This is a genuine AirTAC part, one of the 3V1 family manifold bases that run from 1F to 20F stations. The valves that mount on it are available as NC or NO, with AC220V, DC24V, AC110V, AC24V or DC12V coils, in DIN plug or flying-lead versions. We do not publish performance figures for this family here; ask on RFQ and we will confirm them from the datasheet.
Airtac 3V-F Base 3V100M5F Technical Specifications
| Model | Airtac 3V-F Base 3V100M5F |
|---|---|
| Series | 3V-F manifold base |
| Item form | Manifold base (no coil, no solenoid, no initial state) |
| Stations | 5 |
| Port size | Confirm from the datasheet — ask us |
| Thread | PT |
| Operating pressure | Confirm from the datasheet — ask us |
|---|---|
| Flow coefficient | Confirm from the datasheet — ask us |
| Temperature | Confirm from the datasheet — ask us |
| Protection | Confirm from the datasheet — ask us |
Model Code: Airtac 3V-F Base 3V100M5F
| 3V-F manifold base | Body. |
|---|---|
| 5F | 5 stations in one assembly. |
| PT | Port thread. PT ships from stock; G and NPT are available to order. |
What a 3/2 Valve Does
A 3/2 valve has three ports — supply, outlet and exhaust — and two states. It either feeds the outlet or vents it to exhaust, and that is the whole job.
That makes it the right valve for a single-acting (spring-return) cylinder, on/off air blow, a clamp, switching a vacuum generator or suction cup, and piloting a larger valve.
It cannot run a double-acting cylinder. A double-acting cylinder needs air alternately on two sides, which takes a 5-port valve — the AirTAC 4V series.
Where the Airtac 3V-F Base 3V100M5F Is Used
CNC fixture clamping
Five single-acting swing or edge clamps around a machining fixture each get their own 3/2 valve, all fed from the one manifold.
Laboratory automation
A benchtop lab rig switching small air and vent functions valve-by-valve benefits from one base that keeps tubing and wiring tidy.
Assembly press auxiliaries
Part ejection, blow-off and guard interlock vents around an assembly press are grouped on a five-station base next to the main machine valves.
Is the Airtac 3V-F Base 3V100M5F the Right Part?
Count the 3/2 functions your panel needs before choosing a station count - five here, with smaller and larger bases in the same family. Order each valve separately: the NC/NO choice sets what happens on power loss, the port (M5, 1/8in, 1/4in, 3/8in) sets how large an actuator it can serve, and the coil voltage must match the control supply. Because flow figures for this family are not in our hands, let us confirm sizing against your cylinders before ordering. Buyers who need a documented 3-port valve today can turn to the 3V2 (1/8in and 1/4in) or 3V3 (1/4in) bodies, where flow and coil power are published; a double-acting cylinder calls for a 5-port AirTAC 4V valve.
Confirm before you order
- ✓ Port size and thread (PT from stock; G / NPT to order)
- ✓ Initial state — NC or NO, ordered up front
- ✓ Coil voltage matches your controller output
- ✓ Electrical entry — DIN plug or flying lead
- ✓ Single valve, bare base, or complete assembly
- ✓ Single-acting duty, not double-acting
Installation & Wiring Notes
- check Use clean air filtered to 40µm or finer.
- check Use the manual override to test before powering up.
- check Leave the exhaust port clear, or fit a silencer.
- check Blank any unused station on the base before pressurising.
- check Wiring by qualified personnel, per AirTAC documentation.
Airtac 3V-F Base 3V100M5F FAQ
Station count and shared-supply arrangement we state directly; pressure, flow and coil power we confirm from the AirTAC datasheet on request. If you need numbers published today, the 3V2 (1/8in, 1/4in) and 3V3 (1/4in) valve bodies have documented flow and coil-power figures.
NC leaves the outlet dead and lets trapped air vent when de-energised, which suits clamps that must release on power loss; NO holds the outlet fed until you switch it. A 3/2 valve drives single-acting or spring-return actuators only - a double-acting cylinder needs a 5-port 4V series valve.
