Airtac 3V-F Base 3V100M6F
2、Features centralized inlet/exhaust ports and unified wiring configuration, which simplifies troubleshooting during system failures;
3、Offers flexible configuration and high expandability, allowing arbitrary combination or modular expansion of connected directional control valves;
Category: Solenoid Valve Bases | Brand: AIRTAC | Series: 3V-F
AirTAC 3V100M6F Valve Base Unit Technical Details
- Model: 3V100M6F (3V-F Series Modular Base)
- Valve compatibility: Designed for 3V1 series solenoid valves
- Port configuration: 6 ports (1P-2A-2B-1R)
- Thread standard: PT1/4 (G1/8 optional)
- Max operating pressure: 1.0 MPa
- Pressure range: 0.15–1.0 MPa
- Flow capacity: 750 L/min (ANR)
- Body material: Reinforced PA66 + glass fiber
- Seal material: HNBR (high-grade nitrile rubber)
- Temperature resistance: -10℃ to 80℃
- Weight: 320g ±5%
- Dimensions: 98mm(L) × 35mm(W) × 48mm(H)
- Mounting style: ISO 15407-1 compliant manifold mounting
- Surface finish: Anti-corrosion anodized treatment
Modular base unit enabling multi-valve manifold configurations with leak-proof manifold channels. Features integrated silencer and shock-resistant structure for high-cycle industrial environments. Designed for ISO 5599/1 standard valve cartridges with color-coded port identification (blue: exhaust, red: pressure).
- Automated assembly line clamping systems
- Plastic injection molding machine sequences
- CNC tool changer pneumatic circuits
- Beverage filling station manifold clusters
- Automotive welding robot end effectors
Installation protocol:
Use torque-controlled tightening (1.2-1.5 N·m) for manifold stacking.
Apply silicone-free lubricant on O-rings during assembly.
Maintain ambient humidity below 90% RH to prevent manifold icing.
| Property | Property Value |
|---|---|
| sku | 3V100M6F |
