Airtac 3V-F Base 3V100M8F
2、Features centralized inlet/exhaust ports and unified wiring configuration, which simplifies troubleshooting during system failures;
3、Offers flexible configuration and high expandability, allowing arbitrary combination or modular expansion of connected directional control valves;
Category: Solenoid Valve Bases | Brand: AIRTAC | Series: 3V-F
AirTAC 3V100M8F Valve Base Technical Specifications
- Model: 3V100M8F
- Type: Modular base for 3V series solenoid valves
- Port configuration: 1/4" (M5x0.8 thread optional)
- Mounting pattern: ISO 15407-1 compliant
- Max operating pressure: 1.0 MPa
- Temperature resistance: -5℃ to 80℃ (with NBR seals)
- Material: Glass fiber reinforced PA66
- Surface finish: Anti-corrosion treatment
- Port alignment: 5/2-way or 5/3-way configurable
- Weight: 220g ±5g
- Dimensions: 78mm(L) × 42mm(W) × 34mm(H)
- Compatibility: Works with 3V210/3V310/3V410 series valves
- Pressure drop: ≤0.02 MPa at 1.0 MPa supply
Robust modular base designed for multi-valve manifold systems, featuring precision-molded flow channels for minimized pressure loss. The reinforced structure withstands vibration in high-cycle applications. Includes integrated silencer mounting slots and optional position sensor compatibility.
- Automated assembly line manifolds
- Semiconductor manufacturing equipment
- Plastic injection molding machines
- Textile machinery pneumatic clusters
- Food processing control panels
Installation protocol:
Use torque-controlled tightening (1.2-1.5N·m) for manifold stacking.
Apply thread sealant only on male ports. Maintain ambient humidity below 90% RH.
| Property | Property Value |
|---|---|
| sku | 3V100M8F |
