Airtac 3V2M-F Base 3V2M1F
The AirTAC Airtac 3V2M-F Base 3V2M1F is a genuine 3V2M manifold base for 1 stations on one shared air supply. A base is a machined block: it carries no coil and no solenoid, so the valves that sit on it are ordered separately.
- Valve type3/2-way (3-port, 2-position)
- Port size1/8 in
- Stations1
- Flow (Cv)0.1
- Series3V2M
About the Airtac 3V2M-F Base 3V2M1F
The 3V2M1F is a one-station manifold base for AirTAC 3V2M valves - the smallest block in the range and a practical starting point. It is a machined manifold, not a valve: there is no coil, no solenoid, no NC or NO state and no IP rating on the block itself. It routes one shared air supply to a single 3/2 valve position and merges that station's exhaust into the centralised port.
Fitting the valve on this base instead of piping an individual unit keeps the supply and wiring layout identical to a larger 3V2M bank, so later expansion to a 2F or bigger block changes nothing upstream. The valve for this one position is ordered separately.
Airtac 3V2M-F Base 3V2M1F Technical Specifications
| Model | Airtac 3V2M-F Base 3V2M1F |
|---|---|
| Series | 3V2M |
| Item form | Manifold base (no coil, no solenoid, no initial state) |
| Stations | 1 |
| Exhaust | Centralised exhaust |
| Port size | 1/8 in |
| Thread | PT |
| Operating pressure | 0-0.8 MPa (0-114 psi) |
|---|---|
| Vacuum service | Not rated for vacuum |
| Flow coefficient | Cv 0.1 |
| Temperature | -20 to 70 C |
| Construction | Coaxial shut-off (poppet), base-mounted, spring return |
| Medium | Air, filtered by a 40 µm or finer element. Lubrication not required. |
Figures follow the official AirTAC 3V2M catalogue. Confirm coil voltage and thread (PT / NPT / G) against the product label before wiring.
Model Code: Airtac 3V2M-F Base 3V2M1F
| 3V2M | Body — sets the flow, the coil power and whether vacuum is rated. |
|---|---|
| 1/8 in | Port size. M5, 06 = 1/8 in, 08 = 1/4 in, 10 = 3/8 in. |
| 1F | 1 stations in one assembly, centralised exhaust. |
| PT | Port thread. PT ships from stock; G and NPT are available to order. |
What a 3/2 Valve Does
A 3/2 valve has three ports — supply, outlet and exhaust — and two states. It either feeds the outlet or vents it to exhaust, and that is the whole job.
That makes it the right valve for a single-acting (spring-return) cylinder, on/off air blow, a clamp, switching a vacuum generator or suction cup, and piloting a larger valve.
It cannot run a double-acting cylinder. A double-acting cylinder needs air alternately on two sides, which takes a 5-port valve — the AirTAC 4V series.
Where the Airtac 3V2M-F Base 3V2M1F Is Used
Lab pneumatic test bench
A single-point pressure test station on a QA bench keeps its supply and wiring layout identical to the plant's larger 3V2M banks.
Machining centre chip blow-off
One blow nozzle clears chips from a fixture on a milling machine, fed from the shared supply routed through the block.
Jig clamp retrofit
A maintenance team adds one spring-return clamp to a workholding jig using the same base and wiring scheme as existing 3V2M installations.
Is the Airtac 3V2M-F Base 3V2M1F the Right Part?
Choose the valve for this single station by matching five points: NC or NO state, coil voltage, DIN plug or flying-lead entry, the 1-station count, and centralised exhaust. PT is the standard thread on this family; G and NPT are options you order.
A base-mounted 3V2M valve flows Cv 0.1, less than an individually piped 3V2 at Cv 0.18 (1/8") or 0.19 (1/4"), so pick an individual 3V2 or the 3V3 (Cv 0.62, 1/4", vacuum-rated) where this one point needs more flow. The 3V1 saves power at 3.0 W DC for small duties. For a double-acting cylinder use the AirTAC 4V series. NC and NO are fixed at order time.
Confirm before you order
- ✓ Port size and thread (PT from stock; G / NPT to order)
- ✓ Initial state — NC or NO, ordered up front
- ✓ Coil voltage matches your controller output
- ✓ Electrical entry — DIN plug or flying lead
- ✓ Single valve, bare base, or complete assembly
- ✓ Single-acting duty, not double-acting
Installation & Wiring Notes
- check Use clean air filtered to 40µm or finer.
- check Stay within 0-0.8 MPa (0-114 psi) operating pressure.
- check Use the manual override to test before powering up.
- check Leave the exhaust port clear, or fit a silencer.
- check Blank any unused station on the base before pressurising.
- check Wiring by qualified personnel, per AirTAC documentation.
Airtac 3V2M-F Base 3V2M1F FAQ
The mounted 3/2 valve gives Cv 0.1, works at 0-0.8 MPa (0-114 psi) and -20 to 70 C, is IP65 (DIN 40050) protected, and draws 7 VA on AC or 7.0 W on DC depending on the coil ordered. The 1-station base itself carries none of these ratings - it is unpowered.
The block is machined for one station, so extra positions mean ordering a larger base; 3V2M stations combine and expand freely as separate blocks. NC or NO is fixed by the valve you order and cannot be reversed afterwards - flipping the base gasket does not convert the state.
