Airtac B01-MALJ Special Application Cylinder B01-MALJ40X125-50S
AirTAC B01-MALJ40X125-50S Special Purpose Cylinder Specifications
- Model: B01-MALJ40X125-50S
- Series: MALJ compact guided cylinder
- Bore size: 40mm
- Stroke: 125mm
- Operating pressure: 0.15–0.8 MPa (21.7–116 psi)
- Piston speed: 50–800 mm/s
- Cushioning: Adjustable rubber buffer (both ends)
- Mounting type: Front/rear flange (MF1/MF2) with ISO 15552 mounting pattern
- Rod material: Hard chrome-plated S45C steel
- Seal material: NBR (Nitrile) for general use
- Temperature range: -20℃ to 80℃ (non-freezing)
- Port size: M5×0.8 (G1/8 equivalent)
- Weight: 2.25 kg (with standard accessories)
- Dimensions:
- Extended length: 248mm
- Retracted length: 123mm
- Body width: 54mm
- Height (with rod): 82mm
- Mounting hole spacing: 25×25mm grid
High-precision guided cylinder with integrated linear bearings, designed for applications requiring anti-rotation and lateral load resistance. Features dual piston seals for leak prevention and anodized aluminum body for corrosion resistance. Includes built-in magnet for position sensing compatibility (sensor sold separately).
- Precision alignment in semiconductor wafer handling
- Vertical lifting mechanisms in packaging lines
- Clamping fixtures for CNC machine tooling
- Sorting gate actuators in logistics systems
- Press-fit operations in electronic assembly
Installation guidelines:
Use alignment jigs during mounting to ensure parallel installation.
Lubricate with ISO VG32 hydraulic oil before initial operation.
For vertical mounting, install exhaust mist lubricator (AM300 series recommended).
- Magnetic sensor: D-A93 series
- Rod lock kit: B01-LK40
- Heat-resistant seals (FKM) for 120℃ environments
- Low-friction piston seals for high-speed applications
