Airtac B52-HLH Copper-Free Precision Slide Table Cylinder B52-HLH6X5S
AirTAC B52-HLH6X5S Copper-Free Precision Slide Table Cylinder Specifications
- Model: B52-HLH6X5S
- Type: Dual-axis guided slide cylinder (copper-free design)
- Bore size: 6mm
- Stroke: 5mm
- Operating pressure: 0.15–0.8 MPa
- Temperature range: -20℃ to 80℃
- Buffer type: Adjustable rubber cushion
- Material: Aluminum alloy body with chromium-plated rod (copper-free process)
- Seal material: NBR (Nitrile rubber)
- Mounting style: Horizontal/vertical multi-position
- Port size: M5x0.8 (1/8" NPT optional)
- Max speed: 500 mm/s
- Repeat positioning accuracy: ±0.01mm
- Protection rating: IP54 (standard), IP67 (optional)
- Lubrication: Pre-lubricated (Molykote EM-50L)
- Weight: 0.28 kg
- Dimensions: 52mm(L) × 30mm(W) × 40mm(H) (excluding mounting brackets)
High-precision slide cylinder featuring copper-free construction for corrosive environments, with dual linear guide rails ensuring ±0.01mm repeatability. The chromium-plated rod and aluminum alloy body provide exceptional wear resistance. Includes magnetic piston for sensor mounting (proximity switch not included). Requires 5μm filtered air supply.
- Semiconductor wafer handling robots
- Medical device assembly lines
- Optical lens positioning systems
- Food packaging machinery (copper-free compliance)
- Laboratory automation equipment
Installation note:
Maintain 0.5mm clearance between guide rails and load during mounting.
Use only copper-free pneumatic components in series. Lubrication interval:
2,000km travel distance or 6 months (whichever comes first).
| Property | Property Value |
|---|---|
| sku | B52-HLH6X5S |
