Airtac B52-HLQ Copper-Free Precision Slide Table Cylinder B52-HLQ12X100SAS
AirTAC B52-HLQ12X100SAS Copper-Free Precision Slide Table Cylinder Specifications
- Full Model: B52-HLQ12X100SAS
- Type: Dual-axis guided slide cylinder (copper-free design)
- Bore Size: Ø12mm
- Stroke: 100mm
- Operating Pressure: 0.1-0.9 MPa
- Cushioning: Adjustable air cushion (both ends)
- Rod Material: Stainless steel SUS304
- Body Material: Aluminum alloy with hard anodized finish
- Seal Material: NBR + Polyurethane hybrid seals
- Temperature Range: -20℃ to 80℃
- Sensor Compatibility: Built-in magnet for proximity sensors (SAS suffix indicates sensor-ready)
- Mounting: Standard M4 threaded holes on base and slide block
- Repeat Positioning Accuracy: ±0.01mm
- Weight: 0.82kg (including all mounting hardware)
- Dimensions: 200mm(L) × 42mm(W) × 34mm(H) (at mid-stroke position)
Precision-guided cylinder with copper-free construction for cleanroom and chemical environments. Features dual linear guides with preloaded ball bearings achieving C3 accuracy grade. The SAS variant includes T-slot sensor grooves compatible with M5-size inductive sensors. Anti-corrosion treatment meets ISO 9227 salt spray test standards.
- Semiconductor wafer handling robots
- Optical lens coating machinery
- Medical device assembly lines
- High-speed PCB component placement
- Laboratory automation with corrosive gas environments
Installation notes:
Lubricate with ISO VG32 turbine oil before initial use.
Maximum side load capacity 15N. For vertical mounting,
use counterbalance valves. Alignment tolerance ≤0.05mm/m.
- MHZW2-10D magnetic sensor kit
- APV-12 speed controller
- SS-LF12 linear flange adapter
| Property | Property Value |
|---|---|
| sku | B52-HLQ12X100SAS |
