Airtac B52-HLQ Copper-Free Precision Slide Table Cylinder B52-HLQ20X50SA
AirTAC B52-HLQ20X50SA Copper-Free Precision Slide Table Cylinder
- Series: B52-HLQ Precision Slide Cylinder
- Full model: B52-HLQ20X50SA
- Bore size: Ø20mm
- Stroke: 50mm (±0.5mm precision)
- Structure: Compact integrated slide guide
- Material: Aluminum alloy body (Cu-free treatment)
- Rod material: Stainless steel SUS304
- Operating pressure: 0.1–0.9 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable rubber bumper
- Seal material: NBR/PU compound seals
- Mounting type: Through-hole base mounting
- Weight: 1.2kg (excluding accessories)
- Dimensions: 150mm(L) × 52mm(W) × 48mm(H)
- Position detection: Optional magnetic sensor slots
- Surface treatment: Anodized aluminum (black)
- ISO standard: 15552 compliant
Copper-free precision linear actuator combining cylinder and linear guide in one unit, designed for contamination-sensitive environments. Features zero copper components to prevent oxidation in humid/chemical atmospheres. Integrated slide mechanism ensures ±0.05mm repeat positioning accuracy with dual adjustable cushions.
- Semiconductor wafer handling systems
- Pharmaceutical production lines
- Food packaging machinery
- Optical lens positioning stages
- Cleanroom automation equipment
Installation notes:
Lubricate guide rails with silicone-free grease (Molykote EM-50L recommended).
Maximum side load capacity 15N. Avoid using in environments with phosphate ester-based lubricants.
| Property | Property Value |
|---|---|
| sku | B52-HLQ20X50SA |
