Airtac B52-HLS Non-Copper Precision Slide Cylinder B52-HLS25X75SB
The AirTAC Airtac B52-HLS Non-Copper Precision Slide Cylinder B52-HLS25X75SB is a genuine HLS slide-table cylinder: a double-acting dual-rod air cylinder integrated with a cross-roller guide so the table travels straight with high rigidity and low deflection. A floating joint spares the rod from side torque; the magnet is fitted as standard.
- TypeSlide-table, double acting
- Guidecross-roller guide
- Operating pressure0.15 - 0.7 MPa (22 - 100 psi)
- Port sizeM5x0.8
- CushionBumper (+ shock-absorber option)
- Magnet / sensorStandard; CMSH/DMSH/EMSH
- ThreadPT
About the Airtac B52-HLS Non-Copper Precision Slide Cylinder B52-HLS25X75SB
The AirTAC HLS25X75SB is a dual-rod double-acting slide-table cylinder with a 25 mm bore and 75 mm stroke. Its integrated cross-roller guide provides the highest precision and rigidity in the HLS family, and the dual-rod design doubles the thrust for this larger bore. The floating joint prevents side torque on the rods, keeping the table on a straight path. The B adjuster equips both ends with shock absorbers for smooth deceleration at high travel speeds.
This is a genuine AirTAC part with a standard magnet fitted for position sensing via CMSH, DMSH, or EMSH switches. We confirm exact thrust values, overall dimensions, and allowable load and moment from the AirTAC datasheet or on-page table on request.
Airtac B52-HLS Non-Copper Precision Slide Cylinder B52-HLS25X75SB Technical Specifications
| Model | Airtac B52-HLS Non-Copper Precision Slide Cylinder B52-HLS25X75SB |
|---|---|
| Type | Slide-table cylinder, double acting, dual rod |
| Series / guide | HLS (cross-roller guide) |
| Port size | M5x0.8 (PT thread) |
| Fluid | Air, filtered to 40 um |
|---|---|
| Operating pressure | 0.15 - 0.7 MPa (22 - 100 psi) |
| Proof pressure | 1.2 MPa (175 psi) |
| Temperature | -20 to 70 C |
| Speed range | 50 - 500 mm/s (meter-out) |
| Cushion | Bumper; shock-absorber / adjustable-stopper options |
| Magnet / sensor | Standard; CMSH, DMSH, EMSH |
Specifications follow the official AirTAC HL slide-table data. Max working pressure is 0.7 MPa. The table rides on an integrated linear guide — do not apply strong impact or large moment. Allowable load and moment are published as tables and curves, and overall dimensions vary per stroke — ask us and we confirm from the datasheet.
How to choose
Use the 25 mm bore when higher thrust is needed; verified push and pull values are in the spec table. The HLS cross-roller guide provides maximum rigidity and minimal deflection across the 75 mm stroke. The B adjuster adds shock absorbers at both ends, ideal for higher travel speeds where rubber bumpers would wear. Choose A-type rubber stoppers for lower-speed applications. Standard PT threads. We provide allowable load and moment data from the published AirTAC tables and deflection curves on request.
Applications
High-Speed Pick-and-Place
Use shock absorbers at both ends to decelerate a gripper head at higher cycle speeds while the cross-roller guide maintains positioning accuracy.
Small-Parts Transfer
Transfer parts between stations along the 75 mm stroke with shock-absorber cushioning for smooth stops at each end of travel.
Stopper Actuation
Deploy the slide as an actuated stopper where the 25 mm bore provides firm thrust and shock absorbers absorb the impact energy.
FAQ
Why choose the B shock-absorber adjuster on the HLS25X75SB?
The B code adds shock absorbers at both ends, which decelerate the table smoothly at higher travel speeds. This reduces impact wear compared to rubber stoppers. B-type adjusters are not available on bore 6 models.
How is load and moment capacity confirmed for this slide table?
Allowable load, moment, and kinetic energy are published as tables and deflection curves in the AirTAC datasheet. We confirm these values for your application on request. Maximum working pressure is 0.7 MPa and speed is limited to 500 mm/s with meter-out control.
