Airtac B52-MD Copper-Free Multi-Position Locking Cylinder B52-MD16X40S
AirTAC B52-MD Series Non-Copper Multi-Position Cylinder (B52-MD16X40S)
- Model: B52-MD16X40S
- Type: Compact multi-position fixed body cylinder
- Bore size: 16mm (ISO 6432 standard)
- Stroke: 40mm (±0.5mm tolerance)
- Operating pressure: 0.05-1.0 MPa
- Temperature range: -10℃ to 70℃
- Cushioning: Adjustable rubber buffer (both ends)
- Mounting styles: MA/MS/MP/MF series compatible
- Port size: M5×0.8 (Rc1/8 adapter optional)
- Body material: Aluminum alloy (copper-free design)
- Rod material: Stainless steel SUS304
- Seal material: NBR with fluorocarbon coating
- Weight: 520g ±2% (without accessories)
- Dimensions: 140mm(L) × 50mm(W) × 50mm(H)
- Rod end thread: M6×1.0 (male)
- Max speed: 500mm/s (with cushion)
- Lubrication: Pre-lubricated (Grease-free operation)
Copper-free pneumatic cylinder specifically engineered for corrosive environments requiring strict metal compatibility. Features 360° adjustable mounting slots and dual-piston guidance for enhanced stability in multi-position applications. The anodized surface treatment provides exceptional resistance to chemical vapors and particulate contamination.
- Semiconductor wafer handling robots
- Food-grade packaging machinery
- Chemical processing automation
- Medical sterilization equipment
- Marine environment control systems
Installation note:
Requires copper-free pneumatic components throughout system. For vertical mounting,
use rod-down orientation to prevent seal wear. Lubricate with ISO VG32 or equivalent
non-detergent oil if manual lubrication is needed.
