Airtac B52-MD Copper-Free Multi-Position Locking Cylinder B52-MD20X30S
AirTAC B52-MD Copper-Free Multi-Position Locking Cylinder B52-MD20X30S Specifications
- Model: B52-MD20X30S
- Series: B52-MD (Copper-Free Design)
- Bore Size: 20mm
- Stroke: 30mm
- Operating Pressure: 0.05-1.0 MPa
- Temperature Range: -10℃ to 70℃
- Port Size: M5×0.8 (Standard) / Optional NPT1/8
- Mounting Style: Front Flange & Rear Foot Mount (Dual Option)
- Cylinder Material: Aluminum Alloy (Copper-Free Internal Components)
- Piston Rod Material: Stainless Steel SUS304
- Seal Material: NBR + PU Hybrid Seals
- Cushioning: Adjustable Rubber Buffer + Air Cushion
- Locking Positions: 3 Fixed Positions Along Stroke
- Weight: 0.58kg ±2%
- Dimensions: 144mm(L) × 32mm(W) × 32mm(H) (Extended Length)
- Protection Rating: IP54 (Standard) / IP67 Optional
- Lubrication: Pre-lubricated (Use ISO VG32 or Equivalent)
Specialized multi-position pneumatic cylinder featuring copper-free construction for environments sensitive to copper contamination. The 3-position mechanical locking mechanism enables precise intermediate stops without pressure maintenance. Enhanced corrosion resistance with stainless steel rod and hybrid seals ensures durability in humid conditions.
- Semiconductor wafer handling robots
- Pharmaceutical production line actuators
- Food packaging position-lock mechanisms
- Cleanroom automation systems
- Precision jig positioning in CNC machining
Installation Note:
Position locking pins must engage fully before operation. Use locknuts (not included) on mounting threads.
Requires 5μm filtered air with dew point -20℃ below ambient. Avoid side-load forces exceeding 15N.
- Locking Force: 120N (Static) / 80N (Dynamic)
- Position Repeatability: ±0.2mm
- Manual Override: Emergency release lever accessible
| Property | Property Value |
|---|---|
| sku | B52-MD20X30S |
