Airtac CMSH Reed Sensor CMSH-030
The AirTAC Airtac CMSH Reed Sensor CMSH-030 is a genuine CMS magnetic position switch. It senses the magnet ring in a pneumatic cylinder's piston and signals when the piston reaches that point, giving a 2-wire output on 5-240 V AC/DC with a 3 m flying lead. It only works on a cylinder that carries a piston magnet.
- TechnologyReed (magnetic contact)
- Output2-wire
- Supply voltage5-240 V AC/DC
- ProtectionIP64
- Profile (groove fit)H
- Lead / connector3 m flying lead
- VersionStandard
- RequiresMagnet-equipped cylinder
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac CMSH Reed Sensor CMSH-030
The CMSH-030 is a reed-type magnetic position switch from AirTAC. Inside sits a sealed mechanical reed contact, not solid-state electronics, so it closes on either AC or DC anywhere from 5-240 V and needs no polarity. It seats in the sensor groove of an AirTAC cylinder fitted with the piston magnet option and signals position through its 2-wire circuit. This version carries a 3 m flying lead; the general-type body is sealed to IP64.
Because the contact is mechanical, it behaves like a classic limit switch: wire it in series with the load, expect a finite contact life under very heavy cycling, and mind inrush loads on the line. The H profile letter sets the groove fit for the cylinder body, so check it against your series before ordering - exact seating is what makes or breaks detection.
Airtac CMSH Reed Sensor CMSH-030 Technical Specifications
| Model | Airtac CMSH Reed Sensor CMSH-030 |
|---|---|
| Family | CMS — Reed switch cylinder sensor |
| Technology | Reed (magnetic contact) |
| Output | 2-wire |
| Outputs in this family | 2-wire contact |
| Lead / connector | 3 m flying lead |
| Supply voltage | 5-240 V AC/DC |
|---|---|
| Protection rating | IP64 |
| Version | Standard version |
| Profile letter | H (cylinder-groove fit) |
| Profiles in this family | E, G, H, J |
| Detects | Piston magnet ring inside the cylinder |
A reed contact switches a wide window, 5-240 V AC or DC, which is why it suits AC circuits and relay logic. IP64. The CMS range has no RW / IP68 option - that belongs to DMS and EMS. Switching distance, response time, current rating, voltage drop, LED behaviour, contact life, weight and dimensions are not published in our data set — ask us and we will confirm from the factory datasheet.
Model Code: Airtac CMSH Reed Sensor CMSH-030
| CMS | Reed switch cylinder sensor — reed (magnetic contact). |
|---|---|
| H | Profile letter: the mounting / groove type that fits a particular cylinder body. This family offers E, G, H, J. It is a fit code, not a performance grade. |
| 030 | 3 m flying lead. 020 / 030 / 050 / 100 are 2 / 3 / 5 / 10 m flying leads; M08 and M12 are M8 / M12 connector versions. |
| (blank) | Standard version. On a CMS the suffix -H is the high-temperature version — do not confuse it with the H profile letter. |
We do not hold the full profile-to-cylinder-series table, so confirm the profile letter against your cylinder model before ordering — send us the cylinder part number and we will check the fit.
Which Family Do You Need?
- DMSElectronic, 2-wire / NPN / PNP, DC
- EMSMini electronic, 2-wire only, DC
- CMSReed contact, 2-wire, 5-240 V AC/DC
The split is electrical, not quality. Solid-state DMS and EMS are DC-only and suit modern PLC inputs; the reed-based CMS switches a much wider window, so it is the one for AC circuits, relay logic and older panels. The RW (IP68) option exists on DMS and EMS only.
| This switch | CMSH · 2-wire · 5-240 V AC/DC |
|---|---|
| Consider DMS | the solid-state range with NPN / PNP 3-wire outputs (DC only) |
| Consider EMS | the mini 2-wire solid-state switch (DC only) |
| Mounting parts | F-MQ (round body), F-ACT (tie-rod) |
Where the Airtac CMSH Reed Sensor CMSH-030 Is Used
Relay panel end-of-stroke
A packaging machine's clamp cylinder signals full close to a 24 V DC relay rung; the 2-wire reed contact drops straight into the series path.
Assembly fixture clamp check
On a bench fixture, an AirTAC clamp cylinder with the magnet option proves the part is gripped before the press cycle may start.
Three-point slide detection
Three switches seated at home, mid and end positions on one slide cylinder each report over their own 3 m leads back to the terminal strip.
Is the Airtac CMSH Reed Sensor CMSH-030 the Right Switch?
Choose CMSH when your control circuit wants a simple series contact on AC or DC; pick a DMS or EMS electronic switch instead if cycles are fast and you want solid-state switching with no bounce. This 3 m flying lead suits fixed mounts where the cable never moves; for plug-in service swaps, ask about an M8 or M12 connector build. The -H build handles hot zones, while this general type suits ordinary ambient. Either way, the H profile must match your cylinder's groove and the piston must carry the built-in magnet.
Quick checklist
- ✓ Cylinder has a piston magnet
- ✓ Profile letter fits your cylinder groove
- ✓ Output matches the PLC input (2-wire)
- ✓ Supply rail is 5-240 V AC/DC
- ✓ Lead length or M8 / M12 connector
- ✓ High temperature? Use the -H version
Installation & Wiring Notes
- check The cylinder must carry a piston magnet — a plain cylinder cannot be sensed.
- check Slide the switch along the groove to the stop position, then lock it.
- check Keep the supply within 5-240 V AC/DC.
- check A reed contact suits AC or DC; observe the load limits on the datasheet.
- check Keep the lead clear of moving parts; use the RW type where it must flex.
- check Rated IP64 — protect it beyond that rating.
Use the F-MQ bracket on round-body cylinders and F-ACT on tie-rod cylinders where there is no groove to seat the switch. Both are ordered separately from the switch. Switching distance and mounting dimensions come from the factory datasheet — ask us for the sheet that matches your cylinder.
Airtac CMSH Reed Sensor CMSH-030 FAQ
It is a reed position switch with a 2-wire mechanical contact. Supply range is 5-240 V AC or DC, protection is IP64, and it arrives with a 3 m flying lead. There is no polarity to observe and no output transistor, since the element is a sealed reed.
Pick the reed CMSH when your circuit wants a simple series contact on AC or DC and you value galvanic isolation. Choose an electronic DMS or EMS when switching is very frequent and you need solid-state operation without contact bounce. Remember the profile letter must seat in your cylinder's groove and the piston needs the built-in magnet.
