Airtac CMSH Reed Sensor CMSH-100
The AirTAC Airtac CMSH Reed Sensor CMSH-100 is a genuine CMS magnetic position switch. It senses the magnet ring in a pneumatic cylinder's piston and signals when the piston reaches that point, giving a 2-wire output on 5-240 V AC/DC with a 10 m flying lead. It only works on a cylinder that carries a piston magnet.
- TechnologyReed (magnetic contact)
- Output2-wire
- Supply voltage5-240 V AC/DC
- ProtectionIP64
- Profile (groove fit)H
- Lead / connector10 m flying lead
- VersionStandard
- RequiresMagnet-equipped cylinder
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac CMSH Reed Sensor CMSH-100
The CMSH-100 is an AirTAC CMS-series magnetic reed switch. It reads the piston magnet of an AirTAC cylinder ordered with the built-in magnet option and closes its 2-wire contact when the piston reaches the mounting point. The 100 wiring code gives a 10 m flying lead, so the cable can run the whole distance back to a distant control panel without joints or extensions. Supply range is 5-240 V AC/DC and the standard housing carries IP64 protection.
As a reed type, this switch has a genuine mechanical contact: no polarity to observe, happy on AC or DC, and it wires in series just like a conventional limit switch. The H in the model is a profile fit code that must match your cylinder's sensor groove - check the seating against your cylinder before you order.
Airtac CMSH Reed Sensor CMSH-100 Technical Specifications
| Model | Airtac CMSH Reed Sensor CMSH-100 |
|---|---|
| Family | CMS — Reed switch cylinder sensor |
| Technology | Reed (magnetic contact) |
| Output | 2-wire |
| Outputs in this family | 2-wire contact |
| Lead / connector | 10 m flying lead |
| Supply voltage | 5-240 V AC/DC |
|---|---|
| Protection rating | IP64 |
| Version | Standard version |
| Profile letter | H (cylinder-groove fit) |
| Profiles in this family | E, G, H, J |
| Detects | Piston magnet ring inside the cylinder |
A reed contact switches a wide window, 5-240 V AC or DC, which is why it suits AC circuits and relay logic. IP64. The CMS range has no RW / IP68 option - that belongs to DMS and EMS. Switching distance, response time, current rating, voltage drop, LED behaviour, contact life, weight and dimensions are not published in our data set — ask us and we will confirm from the factory datasheet.
Model Code: Airtac CMSH Reed Sensor CMSH-100
| CMS | Reed switch cylinder sensor — reed (magnetic contact). |
|---|---|
| H | Profile letter: the mounting / groove type that fits a particular cylinder body. This family offers E, G, H, J. It is a fit code, not a performance grade. |
| 100 | 10 m flying lead. 020 / 030 / 050 / 100 are 2 / 3 / 5 / 10 m flying leads; M08 and M12 are M8 / M12 connector versions. |
| (blank) | Standard version. On a CMS the suffix -H is the high-temperature version — do not confuse it with the H profile letter. |
We do not hold the full profile-to-cylinder-series table, so confirm the profile letter against your cylinder model before ordering — send us the cylinder part number and we will check the fit.
Which Family Do You Need?
- DMSElectronic, 2-wire / NPN / PNP, DC
- EMSMini electronic, 2-wire only, DC
- CMSReed contact, 2-wire, 5-240 V AC/DC
The split is electrical, not quality. Solid-state DMS and EMS are DC-only and suit modern PLC inputs; the reed-based CMS switches a much wider window, so it is the one for AC circuits, relay logic and older panels. The RW (IP68) option exists on DMS and EMS only.
| This switch | CMSH · 2-wire · 5-240 V AC/DC |
|---|---|
| Consider DMS | the solid-state range with NPN / PNP 3-wire outputs (DC only) |
| Consider EMS | the mini 2-wire solid-state switch (DC only) |
| Mounting parts | F-MQ (round body), F-ACT (tie-rod) |
Where the Airtac CMSH Reed Sensor CMSH-100 Is Used
Long pallet line
On a 30 m pallet conveyor, end-of-stroke confirmation from the stop cylinders travels 10 m on the built-in lead straight to the main panel, with no joints to fail.
Press zone
Clamp cylinders buried inside a stamping press report position to a cabinet mounted outside the safety fence; the long lead clears the guarded area in one piece.
Water treatment gate
Gate-lift cylinders on a clarifier walkway signal open and closed positions to a control kiosk across the platform.
Is the Airtac CMSH Reed Sensor CMSH-100 the Right Switch?
Pick the CMSH-100 when the run between cylinder and panel is long: the 10 m lead removes the need for splices on wide machines or remote cabinets. Reed vs electronic is a circuit decision - a reed contact suits AC and mixed AC/DC supplies and behaves like a plain limit switch, while DMS/EMS electronic types are DC-only solid-state units. Your cylinder must have the magnet option, and the H profile must seat correctly in its groove; send the cylinder series and we will verify the fit.
Quick checklist
- ✓ Cylinder has a piston magnet
- ✓ Profile letter fits your cylinder groove
- ✓ Output matches the PLC input (2-wire)
- ✓ Supply rail is 5-240 V AC/DC
- ✓ Lead length or M8 / M12 connector
- ✓ High temperature? Use the -H version
Installation & Wiring Notes
- check The cylinder must carry a piston magnet — a plain cylinder cannot be sensed.
- check Slide the switch along the groove to the stop position, then lock it.
- check Keep the supply within 5-240 V AC/DC.
- check A reed contact suits AC or DC; observe the load limits on the datasheet.
- check Keep the lead clear of moving parts; use the RW type where it must flex.
- check Rated IP64 — protect it beyond that rating.
Use the F-MQ bracket on round-body cylinders and F-ACT on tie-rod cylinders where there is no groove to seat the switch. Both are ordered separately from the switch. Switching distance and mounting dimensions come from the factory datasheet — ask us for the sheet that matches your cylinder.
