AirTAC GC200-06 FRL Unit (GC20006C1)
The AirTAC AirTAC GC200-06 FRL Unit (GC20006C1) is a genuine G-series three-unit F.R.L. combination: a separate filter, a separate regulator and a separate lubricator assembled as one air-preparation station. It has PT1/8" ports, a 40 µm element, a differential-pressure drain and regulates 0.15 - 0.9 MPa (20 - 130 psi).
- TypeF.R.L. combination (3 units)
- Port sizePT1/8"
- Regulating range0.15 - 0.9 MPa (20 - 130 psi)
- Filtering grade40 µm
- DrainDifferential-pressure drain
- Bowl materialPC
- Pressure gaugeFitted
- ThreadPT
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the AirTAC GC200-06 FRL Unit (GC20006C1)
The AirTAC GC20006C1 is the three-piece F.R.L. combination from the G series: a separate filter, a separate regulator and a separate lubricator assembled as one unit. Together they remove water and particulate, hold downstream pressure and feed oil mist to the circuit. This size 200 build has PT 1/8 in ports (PT is the standard; G and NPT are order options), a 40 um filter element, the default differential-pressure drain and an external round gauge on the MPa scale. The regulator section adjusts 0.15-0.9 MPa (20-130 psi), maximum inlet pressure is 1.0 MPa (145 psi), and the working temperature is -5 to 70 C, non-freezing. The size 200 bowls are polycarbonate.
This is a genuine AirTAC part. The three-unit F.R.L. runs across sizes 200 to 600 with automatic (A) or manual (M) drains - the manual drain widens the regulator range to 0.05-0.9 MPa (7-130 psi) - a 5 um element (W), a reverse/check valve (K), an embedded square gauge or external round gauge in MPa, psi or bar scales, and no-bracket (J) options. AirTAC publishes flow only as curves, so we will confirm datasheet figures on request.
AirTAC GC200-06 FRL Unit (GC20006C1) Technical Specifications
| Model | AirTAC GC200-06 FRL Unit (GC20006C1) |
|---|---|
| Series | GC200 F.R.L. combination |
| Composition | Filter + regulator + lubricator (3 units) |
| Port size | PT1/8" (PT thread) |
| Filtering grade | 40 µm |
| Regulating range | 0.15 - 0.9 MPa (20 - 130 psi) |
| Pressure type | Standard type |
| Fluid | Compressed air |
|---|---|
| Max. working pressure | 1.0 MPa (145 psi) |
| Temperature range | -5 to +70 °C (unfreeze) |
| Drain type | Differential-pressure drain |
| Bowl material | PC |
| Pressure gauge | Fitted — round, MPa scale |
| Reflux valve | Not fitted |
Specifications follow the official AirTAC G-series air-preparation data. The regulating band is set by the drain type: automatic and differential-pressure drains regulate 0.15 - 0.9 MPa, a manual drain regulates 0.05 - 0.9 MPa. Standard type, regulating 0.15 - 0.9 MPa (20 - 130 psi). The combination has no separate bracket code — the three units couple together with their own mounting hardware. Flow curves, weight and outline dimensions are not published in our data set — ask us and we will confirm from the factory datasheet.
Model Code: AirTAC GC200-06 FRL Unit (GC20006C1)
| GC200 | G-series F.R.L. combination, 200 body — sets the port range. |
|---|---|
| 06 | Port size PT1/8". This body offers 06 = PT1/8", 08 = PT1/4". |
| (blank) | Drain: Differential-pressure drain — this also sets the regulating band (0.15 - 0.9 MPa (20 - 130 psi)). |
| (blank) | Standard type. Blank is standard, L is the low-pressure type. |
| (blank) | Pressure gauge fitted (blank). |
| C | Gauge shape: Round. C is round, F is square. |
| 1 | Gauge scale: MPa. 1 is MPa, 2 is psi, 3 is bar. |
| (blank) | Filtering grade 40 µm. Only 40 µm (blank) and 5 µm (W) exist. |
| (blank) | PT thread. PT is the default; G is BSPP and T is NPT. |
| (blank) | No reverse-flow valve (the default). |
Field order is size, port, drain, type, gauge, shape, scale, grade, thread, reflux — there is no bracket position on a combination. Constituent units, orderable separately as spares: GF200-06 filter, GR200-06 regulator and GL200-06 lubricator.
Size Class & How It Differs From GFC
- GC200PT1/8" - PT1/4"
- GC300PT1/4" - PT1/2"
- GC400PT3/8" - PT1/2"
- GC600PT3/4" - PT1"
A GC is three separate units, so the filter and the regulator can each be serviced or replaced on their own. A GFC is the two-unit set, where filtering and regulating share one body — shorter, but the two functions come as one part. Both filter, regulate and lubricate.
| This model | GC200 · PT1/8" · 40 µm |
|---|---|
| One size up | GC300 |
| Two-unit equivalent | GFC200-06 |
| Build order | Filter → regulator → lubricator |
Where the AirTAC GC200-06 FRL Unit (GC20006C1) Is Used
Form-fill-seal machine service unit
Installed as the point-of-use service unit on a vertical form-fill-seal machine, it dries and filters the plant air, sets the seal-cylinder pressure and oils the machine's air cylinders.
Loading dock air supply
Mounted where the shop compressor drop serves the loading dock's pneumatic tools and lift-assist cylinders, it cleans, regulates and lubricates the whole branch in one pass.
Knitting machine group supply
Fitted as the group supply unit feeding the air jets and small cylinders on a knitting machine frame, it conditions the branch air for filter, pressure and lubrication in one assembly.
Is the AirTAC GC200-06 FRL Unit (GC20006C1) the Right Station?
Match size and port to the air demand of the circuit: 200 with 1/8 in ports suits small machines and branch supplies; step to 300, 400 or 600 as demand grows. Choose the drain: differential-pressure (default) and automatic (A) give a 0.15-0.9 MPa (20-130 psi) adjustment range, manual (M) widens it to 0.05-0.9 MPa (7-130 psi). Keep the 40 um element or order 5 um (W) for finer capture. This build carries the external round gauge on MPa; psi and bar scales, K reverse/check valve and J no-bracket are orderable, and thread is PT standard with G and NPT options. Flow is published as curves, not a single rating - ask us to confirm sizing before ordering.
Quick checklist
- ✓ Body size for your peak flow (PT1/8" here)
- ✓ Element 40 µm or 5 µm
- ✓ Drain sets the regulating band
- ✓ Gauge fitted, shape and scale
- ✓ Three-unit (GC) or two-unit (GFC) layout
- ✓ Oil mist acceptable downstream
Installation & Maintenance Notes
- check Install with the airflow arrow: filter first, lubricator last.
- check Mount vertically, bowls down.
- check Keep inlet pressure at or below 1.0 MPa (145 psi).
- check Adjust only within 0.15 - 0.9 MPa (20 - 130 psi).
- check Drain condensate before the bowl fills; check the oil level.
- check Keep the station above freezing (-5 to +70 °C, unfreeze).
The PC bowls must not be cleaned with solvents — wipe them with a dry cloth. The lubricator adds an oil mist downstream of the regulator. If any branch of the line must stay oil-free, take that branch off before the lubricator, or use a GR200-06 regulator with a GF200-06 filter on that branch.
AirTAC GC200-06 FRL Unit (GC20006C1) FAQ
AirTAC publishes G-series flow as characteristic curves, not a single rated figure, so there is no single number to quote. Send us your line pressure, set-point and required flow and we will confirm the sizing from the datasheet on request before you order.
Yes. The GC20006C1 is the three-piece form of what AirTAC also offers as individual GF20006, GR20006C1 and GL20006 units. The combined set arrives piped and bracketed as one assembly, while separate units let you space or service each element independently. Either way the functions are the same: filtration, regulation and lubrication.
