AirTAC GC200-06 FRL Unit (GC20006C1W)
The AirTAC AirTAC GC200-06 FRL Unit (GC20006C1W) is a genuine G-series three-unit F.R.L. combination: a separate filter, a separate regulator and a separate lubricator assembled as one air-preparation station. It has PT1/8" ports, a 5 µm element, a differential-pressure drain and regulates 0.15 - 0.9 MPa (20 - 130 psi).
- TypeF.R.L. combination (3 units)
- Port sizePT1/8"
- Regulating range0.15 - 0.9 MPa (20 - 130 psi)
- Filtering grade5 µm
- DrainDifferential-pressure drain
- Bowl materialPC
- Pressure gaugeFitted
- ThreadPT
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the AirTAC GC200-06 FRL Unit (GC20006C1W)
The GC series is AirTAC's three-piece F.R.L. combination: a separate air filter, a pressure regulator and a lubricator supplied as one matched set. This GC20006C1W is size 200 with PT1/8 (1/8 in) ports. The W code specifies the finer 5 um filtration element in the filter bowl, which has a differential-pressure drain; the regulator adjusts from 0.15-0.9 MPa (20-130 psi) and reads on an external round gauge scaled in MPa. The lubricator meters oil mist into the downstream air. Filter and lubricator bowls on this size are polycarbonate (PC). Maximum working pressure is 1.0 MPa (145 psi); operating temperature is -5 to 70 C.
This is a genuine AirTAC part. The G series is offered in sizes 200, 300, 400 and 600, with differential-pressure, automatic or manual drains, 40 um standard or 5 um (W) filtration, MPa, psi or bar gauge scales, and PT (standard), G (BSPP) or NPT threads. AirTAC publishes flow as curves rather than a single rated figure, so we confirm sizing and full datasheet figures for your application on request.
AirTAC GC200-06 FRL Unit (GC20006C1W) Technical Specifications
| Model | AirTAC GC200-06 FRL Unit (GC20006C1W) |
|---|---|
| Series | GC200 F.R.L. combination |
| Composition | Filter + regulator + lubricator (3 units) |
| Port size | PT1/8" (PT thread) |
| Filtering grade | 5 µm |
| Regulating range | 0.15 - 0.9 MPa (20 - 130 psi) |
| Pressure type | Standard type |
| Fluid | Compressed air |
|---|---|
| Max. working pressure | 1.0 MPa (145 psi) |
| Temperature range | -5 to +70 °C (unfreeze) |
| Drain type | Differential-pressure drain |
| Bowl material | PC |
| Pressure gauge | Fitted — round, MPa scale |
| Reflux valve | Not fitted |
Specifications follow the official AirTAC G-series air-preparation data. The regulating band is set by the drain type: automatic and differential-pressure drains regulate 0.15 - 0.9 MPa, a manual drain regulates 0.05 - 0.9 MPa. Standard type, regulating 0.15 - 0.9 MPa (20 - 130 psi). The combination has no separate bracket code — the three units couple together with their own mounting hardware. Flow curves, weight and outline dimensions are not published in our data set — ask us and we will confirm from the factory datasheet.
Model Code: AirTAC GC200-06 FRL Unit (GC20006C1W)
| GC200 | G-series F.R.L. combination, 200 body — sets the port range. |
|---|---|
| 06 | Port size PT1/8". This body offers 06 = PT1/8", 08 = PT1/4". |
| (blank) | Drain: Differential-pressure drain — this also sets the regulating band (0.15 - 0.9 MPa (20 - 130 psi)). |
| (blank) | Standard type. Blank is standard, L is the low-pressure type. |
| (blank) | Pressure gauge fitted (blank). |
| C | Gauge shape: Round. C is round, F is square. |
| 1 | Gauge scale: MPa. 1 is MPa, 2 is psi, 3 is bar. |
| W | Filtering grade 5 µm. Only 40 µm (blank) and 5 µm (W) exist. |
| (blank) | PT thread. PT is the default; G is BSPP and T is NPT. |
| (blank) | No reverse-flow valve (the default). |
Field order is size, port, drain, type, gauge, shape, scale, grade, thread, reflux — there is no bracket position on a combination. Constituent units, orderable separately as spares: GF200-06 filter, GR200-06 regulator and GL200-06 lubricator.
Size Class & How It Differs From GFC
- GC200PT1/8" - PT1/4"
- GC300PT1/4" - PT1/2"
- GC400PT3/8" - PT1/2"
- GC600PT3/4" - PT1"
A GC is three separate units, so the filter and the regulator can each be serviced or replaced on their own. A GFC is the two-unit set, where filtering and regulating share one body — shorter, but the two functions come as one part. Both filter, regulate and lubricate.
| This model | GC200 · PT1/8" · 5 µm |
|---|---|
| One size up | GC300 |
| Two-unit equivalent | GFC200-06 |
| Build order | Filter → regulator → lubricator |
Where the AirTAC GC200-06 FRL Unit (GC20006C1W) Is Used
CNC fixture clamping circuit
Supplies filtered, regulated and lubricated air to the clamping cylinders on a machining centre fixture, with 5 um filtration protecting the clamp valves and a stable set pressure on the gauge.
Bottling line gating cylinders
Conditions the air feeding gate and stopper cylinders along a bottling conveyor, keeping water and particulate out of the control valves while the lubricator feeds the cylinder seals.
Laboratory test rig actuation
Provides cleaner 5 um air to the actuators and grippers on a lab or pilot-scale test rig, where fine particulate downstream of the filter is undesirable.
Is the AirTAC GC200-06 FRL Unit (GC20006C1W) the Right Station?
Size 200 with 1/8 in PT ports suits compact circuits; move to size 300, 400 or 600 when the port size or flow demand grows. Drain is the differential-pressure default, with automatic (A) and manual (M) available. This unit carries the 5 um (W) element rather than the 40 um standard - the right choice when finer particulate removal matters downstream. The external round gauge reads MPa; psi (2) and bar (3) scales are options, as are PT, G (BSPP) and NPT threads. Flow is published as curves, not a single rating, so ask us to confirm sizing before ordering.
Quick checklist
- ✓ Body size for your peak flow (PT1/8" here)
- ✓ Element 40 µm or 5 µm
- ✓ Drain sets the regulating band
- ✓ Gauge fitted, shape and scale
- ✓ Three-unit (GC) or two-unit (GFC) layout
- ✓ Oil mist acceptable downstream
Installation & Maintenance Notes
- check Install with the airflow arrow: filter first, lubricator last.
- check Mount vertically, bowls down.
- check Keep inlet pressure at or below 1.0 MPa (145 psi).
- check Adjust only within 0.15 - 0.9 MPa (20 - 130 psi).
- check Drain condensate before the bowl fills; check the oil level.
- check Keep the station above freezing (-5 to +70 °C, unfreeze).
The PC bowls must not be cleaned with solvents — wipe them with a dry cloth. The lubricator adds an oil mist downstream of the regulator. If any branch of the line must stay oil-free, take that branch off before the lubricator, or use a GR200-06 regulator with a GF200-06 filter on that branch.
AirTAC GC200-06 FRL Unit (GC20006C1W) FAQ
AirTAC publishes flow for the GC series as curves rather than a single rated figure, so there is no single number to quote. Tell us your working pressure and flow demand and we will confirm the sizing against the datasheet on request.
40 um is the standard element for general air preparation; W specifies a 5 um element for finer particulate removal. Both are catalogue options for this size. If you are unsure which grade your application needs, we can review it with you and confirm details from the datasheet.
