Airtac GC FRL Unit GC20006C1WK
2. 360° rotary oil flow adjustment ring with linear flow gradient, allowing approximate oil output estimation through calibrated indexing;
3. In-line oil replenishment without interrupting airflow;
4. Specialized nozzle design generates negative pressure at outlet port, minimizing mist formation;
5. Quick-connect interface enables secure installation and maintenance efficiency;
6. Pressure regulation maintains stability with high repeatability accuracy;
7. High-efficiency removal of moisture and solid particulates;
8. Optional drainage configurations: manual, differential pressure-activated, or automatic discharge.
Category: Air Treatment Units | Brand: Airtac | Series: GC
AirTAC GC Series Trio Unit GC20006C1WK Technical Specifications
- Model: GC20006C1WK
- Type: Compact 3-in-1 unit (FRL - Filter Regulator Lubricator)
- Port size: PT1/4 (G1/4 equivalent)
- Operating pressure range: 0.05–0.85 MPa
- Max pressure: 1.0 MPa
- Filtration grade: 40μm (5μm optional with X suffix models)
- Pressure gauge: 0-1.6 MPa dial with ±2% accuracy
- Adjustment knob: 360° rotatable with lockable design
- Oil capacity: 120cc (visible oil level window)
- Temperature range: -5℃ to 60℃ (no freeze conditions)
- Body material: Anodized aluminum alloy
- Seal material: HNBR (Hydrogenated Nitrile)
- Weight: 580g ±3%
- Dimensions: 198mm(L) × 68mm(W) × 72mm(H)
- Drain type: Manual or semi-auto (depending on configuration)
- Installation: Bracket mounting with 32mm rail compatibility
Modular FRL unit combining precision filtration (99.9% 40μm particles), pressure stabilization (±0.008MPa regulation accuracy), and adjustable oil mist lubrication (2-3 drops/min). Features anti-clogging bowl design with safety shield and one-touch bowl removal. Includes pressure relief lock mechanism to prevent accidental adjustment.
- Pneumatic production lines requiring clean air supply
- CNC machine tool pneumatic systems
- Automated assembly equipment with multiple actuators
- Packaging machinery requiring consistent pressure
- Industrial robots with extended duty cycles
Maintenance protocol:
Install vertically with arrow marking aligned to airflow direction.
Replace filter element every 2,000 hours or when pressure drop exceeds 0.05MPa.
Use ISO VG32 turbine oil for lubrication. Drain condensate daily in humid environments.
| Property | Property Value |
|---|---|
| sku | GC20006C1WK |
| Port Size | PT1/8 |
