AirTAC GC200-06 FRL Unit (GC20006F3)
The AirTAC AirTAC GC200-06 FRL Unit (GC20006F3) is a genuine G-series three-unit F.R.L. combination: a separate filter, a separate regulator and a separate lubricator assembled as one air-preparation station. It has PT1/8" ports, a 40 µm element, a differential-pressure drain and regulates 0.15 - 0.9 MPa (20 - 130 psi).
- TypeF.R.L. combination (3 units)
- Port sizePT1/8"
- Regulating range0.15 - 0.9 MPa (20 - 130 psi)
- Filtering grade40 µm
- DrainDifferential-pressure drain
- Bowl materialPC
- Pressure gaugeFitted
- ThreadPT
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the AirTAC GC200-06 FRL Unit (GC20006F3)
The GC series is AirTAC's three-piece F.R.L. combination: separate filter, pressure regulator and lubricator units that clean, regulate and oil-mist-lubricate a compressed-air line in one assembly. This GC20006F3 is a size 200 set with PT1/8 (PT 1/8 in.) ports, a standard 40 um filter element, a differential-pressure drain on the filter bowl, and an embedded square gauge scaled in bar. The standard regulator adjusts from 0.15 to 0.9 MPa (20-130 psi), maximum inlet pressure is 1.0 MPa (145 psi), and the polycarbonate bowls on the filter and lubricator suit -5 to 70 C (non-freezing) service on compressed air only.
You are ordering a genuine AirTAC part from the G-series range, which spans sizes 200, 300, 400 and 600 with ports from 1/8 in. to 1 in., drain choices (differential-pressure, automatic, manual), 40 um or 5 um filtration, MPa/psi/bar gauge scales, an optional reverse valve, and G (BSPP) or NPT thread alternatives. Flow is published as curves rather than a single rated figure, so we confirm the datasheet and sizing on request.
AirTAC GC200-06 FRL Unit (GC20006F3) Technical Specifications
| Model | AirTAC GC200-06 FRL Unit (GC20006F3) |
|---|---|
| Series | GC200 F.R.L. combination |
| Composition | Filter + regulator + lubricator (3 units) |
| Port size | PT1/8" (PT thread) |
| Filtering grade | 40 µm |
| Regulating range | 0.15 - 0.9 MPa (20 - 130 psi) |
| Pressure type | Standard type |
| Fluid | Compressed air |
|---|---|
| Max. working pressure | 1.0 MPa (145 psi) |
| Temperature range | -5 to +70 °C (unfreeze) |
| Drain type | Differential-pressure drain |
| Bowl material | PC |
| Pressure gauge | Fitted — square, bar scale |
| Reflux valve | Not fitted |
Specifications follow the official AirTAC G-series air-preparation data. The regulating band is set by the drain type: automatic and differential-pressure drains regulate 0.15 - 0.9 MPa, a manual drain regulates 0.05 - 0.9 MPa. Standard type, regulating 0.15 - 0.9 MPa (20 - 130 psi). The combination has no separate bracket code — the three units couple together with their own mounting hardware. Flow curves, weight and outline dimensions are not published in our data set — ask us and we will confirm from the factory datasheet.
Model Code: AirTAC GC200-06 FRL Unit (GC20006F3)
| GC200 | G-series F.R.L. combination, 200 body — sets the port range. |
|---|---|
| 06 | Port size PT1/8". This body offers 06 = PT1/8", 08 = PT1/4". |
| (blank) | Drain: Differential-pressure drain — this also sets the regulating band (0.15 - 0.9 MPa (20 - 130 psi)). |
| (blank) | Standard type. Blank is standard, L is the low-pressure type. |
| (blank) | Pressure gauge fitted (blank). |
| F | Gauge shape: Square. C is round, F is square. |
| 3 | Gauge scale: bar. 1 is MPa, 2 is psi, 3 is bar. |
| (blank) | Filtering grade 40 µm. Only 40 µm (blank) and 5 µm (W) exist. |
| (blank) | PT thread. PT is the default; G is BSPP and T is NPT. |
| (blank) | No reverse-flow valve (the default). |
Field order is size, port, drain, type, gauge, shape, scale, grade, thread, reflux — there is no bracket position on a combination. Constituent units, orderable separately as spares: GF200-06 filter, GR200-06 regulator and GL200-06 lubricator.
Size Class & How It Differs From GFC
- GC200PT1/8" - PT1/4"
- GC300PT1/4" - PT1/2"
- GC400PT3/8" - PT1/2"
- GC600PT3/4" - PT1"
A GC is three separate units, so the filter and the regulator can each be serviced or replaced on their own. A GFC is the two-unit set, where filtering and regulating share one body — shorter, but the two functions come as one part. Both filter, regulate and lubricate.
| This model | GC200 · PT1/8" · 40 µm |
|---|---|
| One size up | GC300 |
| Two-unit equivalent | GFC200-06 |
| Build order | Filter → regulator → lubricator |
Where the AirTAC GC200-06 FRL Unit (GC20006F3) Is Used
Electronics assembly bench air
Feeds pick-and-place modules and small pneumatic press fixtures on an electronics assembly bench from a 1/8 in. drop, with filtered and lubricated air.
Beverage bottling-line cylinders
Conditions supply air for the filler, capper and ejector cylinders on a bottling line, keeping the actuators regulated and oil-mist lubricated.
Vocational training rigs
Serves as the air-preparation station on mechatronics and pneumatics training rigs, where the separate filter, regulator and lubricator can be taught unit by unit.
Is the AirTAC GC200-06 FRL Unit (GC20006F3) the Right Station?
Match the size (200/300/400/600) and its port (06 = 1/8 in. here) to the air demand of your equipment; bigger sizes take bigger ports and more flow. Choose the drain type - differential-pressure (this model, the default), automatic (A) or manual (M); with a differential-pressure drain the regulator range is 0.15-0.9 MPa (20-130 psi). Pick 40 um standard or 5 um (W) filtration, the gauge scale (this unit reads bar; MPa and psi scales are also available), the thread (PT standard, G or NPT to order), and whether to fit a mounting bracket. Flow is published as curves, not a single rated figure, so ask us to confirm sizing against your application before ordering.
Quick checklist
- ✓ Body size for your peak flow (PT1/8" here)
- ✓ Element 40 µm or 5 µm
- ✓ Drain sets the regulating band
- ✓ Gauge fitted, shape and scale
- ✓ Three-unit (GC) or two-unit (GFC) layout
- ✓ Oil mist acceptable downstream
Installation & Maintenance Notes
- check Install with the airflow arrow: filter first, lubricator last.
- check Mount vertically, bowls down.
- check Keep inlet pressure at or below 1.0 MPa (145 psi).
- check Adjust only within 0.15 - 0.9 MPa (20 - 130 psi).
- check Drain condensate before the bowl fills; check the oil level.
- check Keep the station above freezing (-5 to +70 °C, unfreeze).
The PC bowls must not be cleaned with solvents — wipe them with a dry cloth. The lubricator adds an oil mist downstream of the regulator. If any branch of the line must stay oil-free, take that branch off before the lubricator, or use a GR200-06 regulator with a GF200-06 filter on that branch.
AirTAC GC200-06 FRL Unit (GC20006F3) FAQ
AirTAC publishes G-series flow as curves rather than a single rated figure, so we do not state a flow number here. Send us your duty and line conditions and we will confirm the datasheet and flow figures for the GC200 at PT1/8 on request before you order.
The F3 code selects the embedded square gauge with a bar scale; F1 is the same square gauge scaled in MPa and F2 in psi, so you can match the scale your maintenance team reads. Filtration grade, drain type, reverse valve and G or NPT threads are other decodable options.
