AirTAC GC200-06 FRL Unit (GC20006LF1)
The AirTAC AirTAC GC200-06 FRL Unit (GC20006LF1) is a genuine G-series three-unit F.R.L. combination: a separate filter, a separate regulator and a separate lubricator assembled as one air-preparation station. It has PT1/8" ports, a 40 µm element, a differential-pressure drain and regulates 0.15 - 0.9 MPa (20 - 130 psi).
- TypeF.R.L. combination (3 units)
- Port sizePT1/8"
- Regulating range0.15 - 0.9 MPa (20 - 130 psi)
- Filtering grade40 µm
- DrainDifferential-pressure drain
- Bowl materialPC
- Pressure gaugeFitted
- ThreadPT
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the AirTAC GC200-06 FRL Unit (GC20006LF1)
GC20006LF1 is a genuine AirTAC G-series three-unit F.R.L. combination: a separate air filter, pressure regulator and oil-mist lubricator mounted in line in that order. This 200-size set is fitted with PT1/8 ports (1/8 in PT as standard), the low-pressure regulator type, an embedded square gauge scaled in MPa, the standard 40 um filter element and a differential-pressure drain on the filter bowl. The medium is compressed air only, with a maximum working pressure of 1.0 MPa (145 psi) and a -5 to 70 C operating window. The 200-size filter and lubricator bowls are polycarbonate.
The G series spans 200/300/400/600 sizes with ports from 1/8 in to 1 in, plus optional 5 um filtration, manual or automatic drains, alternative gauge styles and scales, and G (BSPP) or NPT thread options. Flow is published as performance curves rather than a single rated figure, so we confirm flow and full datasheet details on request before you order.
AirTAC GC200-06 FRL Unit (GC20006LF1) Technical Specifications
| Model | AirTAC GC200-06 FRL Unit (GC20006LF1) |
|---|---|
| Series | GC200 F.R.L. combination |
| Composition | Filter + regulator + lubricator (3 units) |
| Port size | PT1/8" (PT thread) |
| Filtering grade | 40 µm |
| Regulating range | 0.15 - 0.9 MPa (20 - 130 psi) |
| Pressure type | Low-pressure type |
| Fluid | Compressed air |
|---|---|
| Max. working pressure | 1.0 MPa (145 psi) |
| Temperature range | -5 to +70 °C (unfreeze) |
| Drain type | Differential-pressure drain |
| Bowl material | PC |
| Pressure gauge | Fitted — square, MPa scale |
| Reflux valve | Not fitted |
Specifications follow the official AirTAC G-series air-preparation data. The regulating band is set by the drain type: automatic and differential-pressure drains regulate 0.15 - 0.9 MPa, a manual drain regulates 0.05 - 0.9 MPa. The low-pressure type adjusts over a lower band than standard; we confirm the exact figures from the factory datasheet. The combination has no separate bracket code — the three units couple together with their own mounting hardware. Flow curves, weight and outline dimensions are not published in our data set — ask us and we will confirm from the factory datasheet.
Model Code: AirTAC GC200-06 FRL Unit (GC20006LF1)
| GC200 | G-series F.R.L. combination, 200 body — sets the port range. |
|---|---|
| 06 | Port size PT1/8". This body offers 06 = PT1/8", 08 = PT1/4". |
| (blank) | Drain: Differential-pressure drain — this also sets the regulating band (0.15 - 0.9 MPa (20 - 130 psi)). |
| L | Low-pressure type. Blank is standard, L is the low-pressure type. |
| (blank) | Pressure gauge fitted (blank). |
| F | Gauge shape: Square. C is round, F is square. |
| 1 | Gauge scale: MPa. 1 is MPa, 2 is psi, 3 is bar. |
| (blank) | Filtering grade 40 µm. Only 40 µm (blank) and 5 µm (W) exist. |
| (blank) | PT thread. PT is the default; G is BSPP and T is NPT. |
| (blank) | No reverse-flow valve (the default). |
Field order is size, port, drain, type, gauge, shape, scale, grade, thread, reflux — there is no bracket position on a combination. Constituent units, orderable separately as spares: GF200-06 filter, GR200-06 regulator and GL200-06 lubricator.
Size Class & How It Differs From GFC
- GC200PT1/8" - PT1/4"
- GC300PT1/4" - PT1/2"
- GC400PT3/8" - PT1/2"
- GC600PT3/4" - PT1"
A GC is three separate units, so the filter and the regulator can each be serviced or replaced on their own. A GFC is the two-unit set, where filtering and regulating share one body — shorter, but the two functions come as one part. Both filter, regulate and lubricate.
| This model | GC200 · PT1/8" · 40 µm |
|---|---|
| One size up | GC300 |
| Two-unit equivalent | GFC200-06 |
| Build order | Filter → regulator → lubricator |
Where the AirTAC GC200-06 FRL Unit (GC20006LF1) Is Used
Air knife and blow-off header on a filling line
Conditioning the low-pressure air that sweeps containers or labels off a conveyor section, with the square MPa gauge visible for line-side setting checks.
Control panel pneumatic actuator feed
Supplying filtered, regulated, lubricated low-pressure air to the small actuators inside a machine control cabinet, where the compact square gauge sits cleanly in the panel.
Jig and clamp circuit on a weld cell fixture
Feeding the swing clamps and rest pads of a welding jig from one conditioned drop, keeping moisture and scale out of the clamp valves through repeated cycles.
Is the AirTAC GC200-06 FRL Unit (GC20006LF1) the Right Station?
Step up from 200 to 300/400/600 when the line needs more flow and larger ports (1/4 in to 1 in). This unit carries the L low-pressure regulator type, so choose the standard type if your process is set near the top of the pressure range; we confirm the exact setting band from the datasheet on request. Drain choices for the filter bowl are differential-pressure (fitted here), automatic or manual. Filtration is 40 um as supplied; the W variant gives 5 um for finer downstream protection. The gauge here is the embedded square MPa version; the round external gauge and psi or bar scales are catalogue options. Thread is PT as standard, with G (BSPP) and NPT available to order. Flow appears only as curves, so ask us to confirm sizing against your application before ordering.
Quick checklist
- ✓ Body size for your peak flow (PT1/8" here)
- ✓ Element 40 µm or 5 µm
- ✓ Drain sets the regulating band
- ✓ Gauge fitted, shape and scale
- ✓ Three-unit (GC) or two-unit (GFC) layout
- ✓ Oil mist acceptable downstream
Installation & Maintenance Notes
- check Install with the airflow arrow: filter first, lubricator last.
- check Mount vertically, bowls down.
- check Keep inlet pressure at or below 1.0 MPa (145 psi).
- check Adjust only within 0.15 - 0.9 MPa (20 - 130 psi).
- check Drain condensate before the bowl fills; check the oil level.
- check Keep the station above freezing (-5 to +70 °C, unfreeze).
The PC bowls must not be cleaned with solvents — wipe them with a dry cloth. The lubricator adds an oil mist downstream of the regulator. If any branch of the line must stay oil-free, take that branch off before the lubricator, or use a GR200-06 regulator with a GF200-06 filter on that branch.
AirTAC GC200-06 FRL Unit (GC20006LF1) FAQ
AirTAC publishes G-series flow as performance curves rather than as a single rated figure, so this page carries no flow number. Tell us your line pressure, port size and air demand and we will confirm the correct size from the datasheet on request before you order.
C orders the round external gauge and F the embedded square gauge; the trailing digit sets the scale, so F1 here is square and reading in MPa. Square suits a flush look on the regulator body, while the round version is a catalogue alternative. Other scales (psi, bar) are available to order.
