AirTAC GC200-06 FRL Unit (GC20006LN)
The AirTAC AirTAC GC200-06 FRL Unit (GC20006LN) is a genuine G-series three-unit F.R.L. combination: a separate filter, a separate regulator and a separate lubricator assembled as one air-preparation station. It has PT1/8" ports, a 40 µm element, a differential-pressure drain and regulates 0.15 - 0.9 MPa (20 - 130 psi).
- TypeF.R.L. combination (3 units)
- Port sizePT1/8"
- Regulating range0.15 - 0.9 MPa (20 - 130 psi)
- Filtering grade40 µm
- DrainDifferential-pressure drain
- Bowl materialPC
- Pressure gaugeNot fitted
- ThreadPT
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the AirTAC GC200-06 FRL Unit (GC20006LN)
The AirTAC GC series is a three-piece F.R.L. combination: a separate air filter, a pressure regulator and a lubricator, assembled as one air-treatment set. This GC20006LN is the 200 size with PT1/8 ports. It is the low-pressure regulator type (L), so downstream pressure is set within the low-pressure range up to 0.4 MPa. The filter element is the standard 40 um grade, the bowl drains by differential pressure, and no gauge is fitted (N).
This is a genuine AirTAC part. The GC series is also available in 300, 400 and 600 sizes with larger ports, a choice of 5 um (W) filter element, automatic or manual drains, embedded square or external round gauges with MPa, psi or bar scales, and G (BSPP) or NPT thread options. Flow is published as curves rather than a single rating, so we confirm the datasheet and sizing figures for you on request.
AirTAC GC200-06 FRL Unit (GC20006LN) Technical Specifications
| Model | AirTAC GC200-06 FRL Unit (GC20006LN) |
|---|---|
| Series | GC200 F.R.L. combination |
| Composition | Filter + regulator + lubricator (3 units) |
| Port size | PT1/8" (PT thread) |
| Filtering grade | 40 µm |
| Regulating range | 0.15 - 0.9 MPa (20 - 130 psi) |
| Pressure type | Low-pressure type |
| Fluid | Compressed air |
|---|---|
| Max. working pressure | 1.0 MPa (145 psi) |
| Temperature range | -5 to +70 °C (unfreeze) |
| Drain type | Differential-pressure drain |
| Bowl material | PC |
| Pressure gauge | Not fitted |
| Reflux valve | Not fitted |
Specifications follow the official AirTAC G-series air-preparation data. The regulating band is set by the drain type: automatic and differential-pressure drains regulate 0.15 - 0.9 MPa, a manual drain regulates 0.05 - 0.9 MPa. The low-pressure type adjusts over a lower band than standard; we confirm the exact figures from the factory datasheet. The combination has no separate bracket code — the three units couple together with their own mounting hardware. Flow curves, weight and outline dimensions are not published in our data set — ask us and we will confirm from the factory datasheet.
Model Code: AirTAC GC200-06 FRL Unit (GC20006LN)
| GC200 | G-series F.R.L. combination, 200 body — sets the port range. |
|---|---|
| 06 | Port size PT1/8". This body offers 06 = PT1/8", 08 = PT1/4". |
| (blank) | Drain: Differential-pressure drain — this also sets the regulating band (0.15 - 0.9 MPa (20 - 130 psi)). |
| L | Low-pressure type. Blank is standard, L is the low-pressure type. |
| N | No pressure gauge (N). |
| (blank) | Gauge shape: Factory standard. C is round, F is square. |
| (blank) | Gauge scale: Factory standard. 1 is MPa, 2 is psi, 3 is bar. |
| (blank) | Filtering grade 40 µm. Only 40 µm (blank) and 5 µm (W) exist. |
| (blank) | PT thread. PT is the default; G is BSPP and T is NPT. |
| (blank) | No reverse-flow valve (the default). |
Field order is size, port, drain, type, gauge, shape, scale, grade, thread, reflux — there is no bracket position on a combination. Constituent units, orderable separately as spares: GF200-06 filter, GR200-06 regulator and GL200-06 lubricator.
Size Class & How It Differs From GFC
- GC200PT1/8" - PT1/4"
- GC300PT1/4" - PT1/2"
- GC400PT3/8" - PT1/2"
- GC600PT3/4" - PT1"
A GC is three separate units, so the filter and the regulator can each be serviced or replaced on their own. A GFC is the two-unit set, where filtering and regulating share one body — shorter, but the two functions come as one part. Both filter, regulate and lubricate.
| This model | GC200 · PT1/8" · 40 µm |
|---|---|
| One size up | GC300 |
| Two-unit equivalent | GFC200-06 |
| Build order | Filter → regulator → lubricator |
Where the AirTAC GC200-06 FRL Unit (GC20006LN) Is Used
Lab purge-air skid
Filtered, regulated and lightly oiled supply for purge air on analytical instruments and lab enclosures, where the regulator is set well below 0.4 MPa.
Small CNC tool-change circuit
A compact three-unit set feeding the air-over-oil and clamping circuits of a benchtop machining centre, with a 40 um element protecting downstream valves.
Bottling line actuator drop
Point-of-use treatment on a bottling machine's low-pressure actuator drop, combining water and particulate removal with lubrication for the cylinder.
Is the AirTAC GC200-06 FRL Unit (GC20006LN) the Right Station?
Start with port size: the 200 size with PT1/8 ports suits the smallest branch lines; step up to 300/400/600 when the circuit needs a larger port and more flow. The L code makes this the low-pressure regulator variant, capped at 0.4 MPa of adjustment - pick a standard GC without L if you need the full range. Filter grade is the standard 40 um; choose a W-suffixed code for the 5 um element. Thread is PT as standard; G (BSPP) and NPT are catalogue options to order, and a bracket can be added.
Because AirTAC publishes flow as curves and not as a single rated figure, ask us to confirm sizing against your application before ordering.
Quick checklist
- ✓ Body size for your peak flow (PT1/8" here)
- ✓ Element 40 µm or 5 µm
- ✓ Drain sets the regulating band
- ✓ Gauge fitted, shape and scale
- ✓ Three-unit (GC) or two-unit (GFC) layout
- ✓ Oil mist acceptable downstream
Installation & Maintenance Notes
- check Install with the airflow arrow: filter first, lubricator last.
- check Mount vertically, bowls down.
- check Keep inlet pressure at or below 1.0 MPa (145 psi).
- check Adjust only within 0.15 - 0.9 MPa (20 - 130 psi).
- check Drain condensate before the bowl fills; check the oil level.
- check Keep the station above freezing (-5 to +70 °C, unfreeze).
The PC bowls must not be cleaned with solvents — wipe them with a dry cloth. The lubricator adds an oil mist downstream of the regulator. If any branch of the line must stay oil-free, take that branch off before the lubricator, or use a GR200-06 regulator with a GF200-06 filter on that branch.
AirTAC GC200-06 FRL Unit (GC20006LN) FAQ
AirTAC does not publish a single rated-flow number for the GC200 series; flow is given as curves that depend on the applied pressure and the regulation setting. Because of that we do not quote a figure here. Send us your line pressure and demand and we will confirm the sizing and the datasheet curves for you on request.
The N in GC20006LN means no gauge is fitted, so you read the downstream setting on your own gauge or add a gauge variant. The L in the code makes this the low-pressure regulator type, with adjustment up to 0.4 MPa rather than the standard range - order a standard GC code if your setpoint sits above that.
