Airtac GC FRL Unit GC20006MC1W
2. 360° rotary oil flow adjustment ring with linear flow gradient, allowing approximate oil output estimation through calibrated indexing;
3. In-line oil replenishment without interrupting airflow;
4. Specialized nozzle design generates negative pressure at outlet port, minimizing mist formation;
5. Quick-connect interface enables secure installation and maintenance efficiency;
6. Pressure regulation maintains stability with high repeatability accuracy;
7. High-efficiency removal of moisture and solid particulates;
8. Optional drainage configurations: manual, differential pressure-activated, or automatic discharge.
Category: Air Treatment Units | Brand: Airtac | Series: GC
AirTAC GC Series Trio Unit GC20006MC1W Technical Specifications
- Model: GC20006MC1W (Compact Aluminum Body Series)
- Configuration: Filter-Regulator-Lubricator (FRL) Combination
- Port size: PT1/2 (G1/2 BSPP Thread)
- Operating pressure range: 0.15–1.0 MPa
- Maximum flow: 3,500 L/min (ANR)
- Filter rating: 5 μm (40 μm optional with different element)
- Pressure gauge: 1/8" BSP dial type (0-1.6 MPa range)
- Adjustment knob: Lockable rotary type with ±2% regulation accuracy
- Lubricator oil capacity: 150 cm³ (with drip rate 5-15 drops/min)
- Weight: 1.25 kg (empty) / 1.4 kg (with oil)
- Dimensions: 198mm(L) × 95mm(W) × 125mm(H)
- Material: Aluminum alloy body, NBR/POM seals
- Temperature range: -5℃ to 60℃ (non-freezing conditions)
- Drain type: Manual float drain (semi-automatic option available)
Industrial-grade air preparation unit combining particulate filtration, pressure regulation, and pneumatic lubrication in a space-saving modular design. Features corrosion-resistant construction with visible oil level window and pressure relief safety mechanism. Equipped with tamper-proof adjustment knob for stable pressure maintenance in vibration-prone environments.
- Production line pneumatic control systems
- CNC machine tool air supply conditioning
- Automated packaging equipment
- Plastic injection molding machines
- Automotive assembly line tools
Installation Guidelines:
Mount vertically with flow arrow alignment. Maintain minimum 300mm upstream straight piping.
Lubricator should be positioned last in the FRL sequence. Replace filter element every 2,000 operational hours.
Compatibility Note:
Use only ISO VG32 or equivalent turbine oil. Not suitable for phosphate ester-based fluids.
Install downstream moisture separator if relative humidity exceeds 80%.
| Property | Property Value |
|---|---|
| sku | GC20006MC1W |
| Port Size | PT1/8 |
