AirTAC GC200-06 FRL Unit (GC20006MLC1)
The AirTAC AirTAC GC200-06 FRL Unit (GC20006MLC1) is a genuine G-series three-unit F.R.L. combination: a separate filter, a separate regulator and a separate lubricator assembled as one air-preparation station. It has PT1/8" ports, a 40 µm element, a manual drain and regulates 0.05 - 0.9 MPa (7 - 130 psi).
- TypeF.R.L. combination (3 units)
- Port sizePT1/8"
- Regulating range0.05 - 0.9 MPa (7 - 130 psi)
- Filtering grade40 µm
- DrainManual drain
- Bowl materialPC
- Pressure gaugeFitted
- ThreadPT
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the AirTAC GC200-06 FRL Unit (GC20006MLC1)
GC20006MLC1 is a genuine AirTAC GC-series three-unit F.R.L. combination - separate filter, regulator and lubricator - in size 200 with PT1/8 ports, specified in the low-pressure (L) regulator type. It carries a manual drain on the filter bowl, the standard 40 um filtering element, and an external round pressure gauge reading in MPa mounted at the regulator. Maximum working pressure is 1.0 MPa (145 psi) on compressed air; because this is the L type, confirm its exact adjustment range from the datasheet with us before relying on a figure.
This is a genuine AirTAC part. The GC family comes in 200, 300, 400 and 600 sizes with PT standard and G (BSPP)/NPT thread options, differential-pressure, automatic or manual drains, 40 um or 5 um filtration, and embedded square or external round gauges in MPa, psi or bar scales. Temperature range is -5 to 70 C (non-freezing) and the 200-size bowls are polycarbonate. Flow is published as curves, not a single rating, so we confirm datasheet figures on request.
AirTAC GC200-06 FRL Unit (GC20006MLC1) Technical Specifications
| Model | AirTAC GC200-06 FRL Unit (GC20006MLC1) |
|---|---|
| Series | GC200 F.R.L. combination |
| Composition | Filter + regulator + lubricator (3 units) |
| Port size | PT1/8" (PT thread) |
| Filtering grade | 40 µm |
| Regulating range | 0.05 - 0.9 MPa (7 - 130 psi) |
| Pressure type | Low-pressure type |
| Fluid | Compressed air |
|---|---|
| Max. working pressure | 1.0 MPa (145 psi) |
| Temperature range | -5 to +70 °C (unfreeze) |
| Drain type | Manual drain |
| Bowl material | PC |
| Pressure gauge | Fitted — round, MPa scale |
| Reflux valve | Not fitted |
Specifications follow the official AirTAC G-series air-preparation data. The regulating band is set by the drain type: automatic and differential-pressure drains regulate 0.15 - 0.9 MPa, a manual drain regulates 0.05 - 0.9 MPa. The low-pressure type adjusts over a lower band than standard; we confirm the exact figures from the factory datasheet. The combination has no separate bracket code — the three units couple together with their own mounting hardware. Flow curves, weight and outline dimensions are not published in our data set — ask us and we will confirm from the factory datasheet.
Model Code: AirTAC GC200-06 FRL Unit (GC20006MLC1)
| GC200 | G-series F.R.L. combination, 200 body — sets the port range. |
|---|---|
| 06 | Port size PT1/8". This body offers 06 = PT1/8", 08 = PT1/4". |
| M | Drain: Manual drain — this also sets the regulating band (0.05 - 0.9 MPa (7 - 130 psi)). |
| L | Low-pressure type. Blank is standard, L is the low-pressure type. |
| (blank) | Pressure gauge fitted (blank). |
| C | Gauge shape: Round. C is round, F is square. |
| 1 | Gauge scale: MPa. 1 is MPa, 2 is psi, 3 is bar. |
| (blank) | Filtering grade 40 µm. Only 40 µm (blank) and 5 µm (W) exist. |
| (blank) | PT thread. PT is the default; G is BSPP and T is NPT. |
| (blank) | No reverse-flow valve (the default). |
Field order is size, port, drain, type, gauge, shape, scale, grade, thread, reflux — there is no bracket position on a combination. Constituent units, orderable separately as spares: GF200-06 filter, GR200-06 regulator and GL200-06 lubricator.
Size Class & How It Differs From GFC
- GC200PT1/8" - PT1/4"
- GC300PT1/4" - PT1/2"
- GC400PT3/8" - PT1/2"
- GC600PT3/4" - PT1"
A GC is three separate units, so the filter and the regulator can each be serviced or replaced on their own. A GFC is the two-unit set, where filtering and regulating share one body — shorter, but the two functions come as one part. Both filter, regulate and lubricate.
| This model | GC200 · PT1/8" · 40 µm |
|---|---|
| One size up | GC300 |
| Two-unit equivalent | GFC200-06 |
| Build order | Filter → regulator → lubricator |
Where the AirTAC GC200-06 FRL Unit (GC20006MLC1) Is Used
Lab automation module
Conditions the air feeding small pneumatic actuators on a laboratory automation module, where the low-pressure regulator type suits circuits that operate well below full line pressure and the round gauge gives a clear local readout.
Truck body assembly tooling
Supplies hand-held pneumatic tooling at a truck body assembly and fit-out station, with filtered, regulated and lubricated air and a manual drain that operators bleed during daily start-up checks.
Calibration and setup rig
Feeds a workshop rig used to set up and tune pneumatic sub-assemblies, where the low-pressure regulator variant and round MPa gauge let technicians dial in and read operating pressure directly.
Is the AirTAC GC200-06 FRL Unit (GC20006MLC1) the Right Station?
Pick this code when the downstream equipment is regulated in the low-pressure type: the L suffix selects the low-pressure regulator variant, so verify the adjustment ceiling suits your setting point with us before ordering. The round external gauge in MPa is chosen here over the embedded square gauge if you prefer a separately mounted readout. Drain is manual - switch to automatic (A) or differential-pressure (blank) where the unit is inaccessible. The 40 um element is the standard grade; the 5 um (W) variant is available. Size 200 with 1/8" PT ports is the compact step of the range; G (BSPP) and NPT threads can be ordered instead of PT.
Sizing: flow is published as curves, not a single rated figure, so ask us to confirm this set against your application before ordering.
Quick checklist
- ✓ Body size for your peak flow (PT1/8" here)
- ✓ Element 40 µm or 5 µm
- ✓ Drain sets the regulating band
- ✓ Gauge fitted, shape and scale
- ✓ Three-unit (GC) or two-unit (GFC) layout
- ✓ Oil mist acceptable downstream
Installation & Maintenance Notes
- check Install with the airflow arrow: filter first, lubricator last.
- check Mount vertically, bowls down.
- check Keep inlet pressure at or below 1.0 MPa (145 psi).
- check Adjust only within 0.05 - 0.9 MPa (7 - 130 psi).
- check Drain condensate before the bowl fills; check the oil level.
- check Keep the station above freezing (-5 to +70 °C, unfreeze).
The PC bowls must not be cleaned with solvents — wipe them with a dry cloth. The lubricator adds an oil mist downstream of the regulator. If any branch of the line must stay oil-free, take that branch off before the lubricator, or use a GR200-06 regulator with a GF200-06 filter on that branch.
AirTAC GC200-06 FRL Unit (GC20006MLC1) FAQ
AirTAC publishes G-series flow as curves rather than a single rated figure, so there is no one rated number to quote. Send us your flow and pressure conditions and we will confirm sizing from the datasheet curves on request before you order.
The L suffix specifies the low-pressure regulator type instead of the standard one, for circuits whose working points sit in the lower part of the pressure range. Everything else in this code is a size 200, PT1/8, manual-drain, 40 um set with a round MPa gauge. Confirm the low-pressure adjustment range with us from the datasheet before finalising your setting point.
