AirTAC GFC200-06 Combination Unit (GFC20006C1)
The AirTAC AirTAC GFC200-06 Combination Unit (GFC20006C1) is a genuine G-series two-unit air-preparation set: a filter regulator that filters and regulates in one body, coupled to a lubricator. Two bodies do the work of three, with PT1/8" ports, a 40 µm element, a differential-pressure drain and regulation over 0.15 - 0.9 MPa (20 - 130 psi).
- TypeTwo-unit set (F.R. + L.)
- Port sizePT1/8"
- Regulating range0.15 - 0.9 MPa (20 - 130 psi)
- Filtering grade40 µm
- DrainDifferential-pressure drain
- Bowl materialPC
- Pressure gaugeFitted
- ThreadPT
About the AirTAC GFC200-06 Combination Unit (GFC20006C1)
The AirTAC GFC20006C1 is a two-unit set: a filter regulator paired with a lubricator, giving filtration, pressure regulation and oil-mist lubrication in one assembly. This size 200 build has PT 1/8 in ports (PT is the standard; G and NPT are order options), a 40 um filter element, the default differential-pressure drain and an external round gauge on the MPa scale. The filter-regulator half adjusts 0.15-0.9 MPa (20-130 psi), maximum inlet pressure is 1.0 MPa (145 psi), and the working temperature is -5 to 70 C, non-freezing. The size 200 bowls are polycarbonate.
This is a genuine AirTAC part. The two-unit format is available across the G series (sizes 200 to 600) with automatic (A) or manual (M) drains - the manual drain widens the regulator adjustment to 0.05-0.9 MPa (7-130 psi) - a 5 um element (W), a reverse/check valve (K), square embedded or round external gauges in MPa, psi or bar, and no-bracket (J) options. AirTAC publishes flow only as curves, so ask us to confirm datasheet figures on request.
AirTAC GFC200-06 Combination Unit (GFC20006C1) Technical Specifications
| Model | AirTAC GFC200-06 Combination Unit (GFC20006C1) |
|---|---|
| Series | GFC200 two-unit set |
| Composition | Filter regulator + lubricator (2 units) |
| Port size | PT1/8" (PT thread) |
| Filtering grade | 40 µm |
| Regulating range | 0.15 - 0.9 MPa (20 - 130 psi) |
| Pressure type | Standard type |
| Fluid | Compressed air |
|---|---|
| Max. working pressure | 1.0 MPa (145 psi) |
| Temperature range | -5 to +70 °C (unfreeze) |
| Drain type | Differential-pressure drain |
| Bowl material | PC |
| Pressure gauge | Fitted — round, MPa scale |
| Reflux valve | Not fitted |
Specifications follow the official AirTAC G-series air-preparation data. The regulating band is set by the drain type: automatic and differential-pressure drains regulate 0.15 - 0.9 MPa, a manual drain regulates 0.05 - 0.9 MPa. Standard type, regulating 0.15 - 0.9 MPa (20 - 130 psi). The set has no separate bracket code — the two units couple together with their own mounting hardware. Flow curves, weight and outline dimensions are not published in our data set — ask us and we will confirm from the factory datasheet.
Model Code: AirTAC GFC200-06 Combination Unit (GFC20006C1)
| GFC200 | G-series two-unit set, 200 body — sets the port range. |
|---|---|
| 06 | Port size PT1/8". This body offers 06 = PT1/8", 08 = PT1/4". |
| (blank) | Drain: Differential-pressure drain — this also sets the regulating band (0.15 - 0.9 MPa (20 - 130 psi)). |
| (blank) | Standard type. Blank is standard, L is the low-pressure type. |
| (blank) | Pressure gauge fitted (blank). |
| C | Gauge shape: Round. C is round, F is square. |
| 1 | Gauge scale: MPa. 1 is MPa, 2 is psi, 3 is bar. |
| (blank) | Filtering grade 40 µm. Only 40 µm (blank) and 5 µm (W) exist. |
| (blank) | PT thread. PT is the default; G is BSPP and T is NPT. |
| (blank) | No reverse-flow valve (the default). |
Field order is size, port, drain, type, gauge, shape, scale, grade, thread, reflux — there is no bracket position on a combination set. Constituent units, orderable separately as spares: GFR200-06 filter regulator and GL200-06 lubricator.
Size Class & How It Differs From GC
- GFC200PT1/8" - PT1/4"
- GFC300PT1/4" - PT1/2"
- GFC400PT3/8" - PT1/2"
- GFC600PT3/4" - PT1"
A GFC is two units because filtering and regulating share one body. A GC is three separate units — filter, regulator and lubricator. Both filter, regulate and lubricate; the GFC is the shorter assembly, the GC keeps the filter and regulator serviceable as separate bodies.
| This model | GFC200 · PT1/8" · 40 µm |
|---|---|
| One size up | GFC300 |
| Three-unit equivalent | GC200-06 |
| Build order | Filter regulator first, lubricator last |
Where the AirTAC GFC200-06 Combination Unit (GFC20006C1) Is Used
Automated assembly station air
Feeding the pneumatic screwdrivers and clamps at an automated assembly station, the set cleans and regulates the supply, then meters oil mist into the tool air.
Belt-tensioner cylinder supply
Installed on the drop serving belt-tensioning and guide cylinders on a conveyor system, it removes water, holds the set pressure and keeps the cylinder seals lubricated.
Robot end-effector conditioning
Mounted on the delivery line to a robot end-effector's small pneumatic grippers, it conditions the air in one step: filtered, regulated to the gripper rating and oiled.
Is the AirTAC GFC200-06 Combination Unit (GFC20006C1) the Right Set?
Size the set by port and air demand: 200 with 1/8 in ports fits compact machines and branch lines; step to 300, 400 or 600 as demand grows. Choose the drain: the differential-pressure default and automatic (A) both give a 0.15-0.9 MPa (20-130 psi) adjustment range, while manual (M) widens it to 0.05-0.9 MPa (7-130 psi). Keep the 40 um element or order 5 um (W) for finer capture. This build carries the external round gauge on MPa; psi and bar scales, K reverse/check valve and J no-bracket are orderable. Thread is PT standard with G and NPT options. Flow is published as curves, not a single rating - ask us to confirm sizing against your application before ordering.
Quick checklist
- ✓ Body size for your peak flow (PT1/8" here)
- ✓ Element 40 µm or 5 µm
- ✓ Drain sets the regulating band
- ✓ Gauge fitted, shape and scale
- ✓ Two-unit (GFC) or three-unit (GC) layout
- ✓ Oil mist acceptable downstream
Installation & Maintenance Notes
- check Install with the airflow arrow: filter regulator first, lubricator last.
- check Mount vertically, bowls down.
- check Keep inlet pressure at or below 1.0 MPa (145 psi).
- check Adjust only within 0.15 - 0.9 MPa (20 - 130 psi).
- check Drain condensate before the bowl fills; check the oil level.
- check Keep the set above freezing (-5 to +70 °C, unfreeze).
The PC bowls must not be cleaned with solvents — wipe them with a dry cloth. The lubricator adds an oil mist downstream, so if any branch must stay oil-free, take that branch off before the lubricator or use a GFR200-06 filter regulator on its own.
AirTAC GFC200-06 Combination Unit (GFC20006C1) FAQ
AirTAC publishes G-series flow as characteristic curves rather than a single rated figure, so we do not quote a number here. Tell us your line pressure, set-point and consumption and we will confirm the sizing from the datasheet on request before you order.
The GFC20006C1 pairs a filter regulator with a lubricator: it filters, regulates and lubricates in two bodies. The GC three-unit set separates the filter, regulator and lubricator into three pieces, letting you mount and service each independently. Both cover the same three functions; the choice is layout and servicing preference.
