AirTAC GFC200-06 Combination Unit (GFC20006F1K)
The AirTAC AirTAC GFC200-06 Combination Unit (GFC20006F1K) is a genuine G-series two-unit air-preparation set: a filter regulator that filters and regulates in one body, coupled to a lubricator. Two bodies do the work of three, with PT1/8" ports, a 40 µm element, a differential-pressure drain and regulation over 0.15 - 0.9 MPa (20 - 130 psi).
- TypeTwo-unit set (F.R. + L.)
- Port sizePT1/8"
- Regulating range0.15 - 0.9 MPa (20 - 130 psi)
- Filtering grade40 µm
- DrainDifferential-pressure drain
- Bowl materialPC
- Pressure gaugeFitted
- ThreadPT
About the AirTAC GFC200-06 Combination Unit (GFC20006F1K)
GFC20006F1K is an AirTAC G-series two-unit air preparation set: a filter regulator plus a lubricator supplied as a matched pair, covering water and particle removal, pressure regulation and oil-mist lubrication in a single order. This configuration is size 200 with a 1/8 in PT port, and the K code adds a reverse (check) valve, which holds downstream pressure if the upstream supply drops. The filter bowl is differential-pressure drained (the standard arrangement) with the standard 40 um element, the regulator is the standard type covering 0.15-0.9 MPa (20-130 psi), and the embedded square gauge reads in MPa. Both bowls are polycarbonate at size 200.
This is a genuine AirTAC part for compressed air only, rated to 1.0 MPa (145 psi) maximum working pressure and -5 to 70 C (non-freezing). The G-series runs from size 200 to 600 with ports from 1/8 to 1 in; related options include automatic or manual drain, a 5 um element (W code), other gauge scales, G (BSPP) and NPT threads, and bracket choice. G-series flow is published as curves rather than a single rated figure, so we confirm datasheet and sizing figures on request.
AirTAC GFC200-06 Combination Unit (GFC20006F1K) Technical Specifications
| Model | AirTAC GFC200-06 Combination Unit (GFC20006F1K) |
|---|---|
| Series | GFC200 two-unit set |
| Composition | Filter regulator + lubricator (2 units) |
| Port size | PT1/8" (PT thread) |
| Filtering grade | 40 µm |
| Regulating range | 0.15 - 0.9 MPa (20 - 130 psi) |
| Pressure type | Standard type |
| Fluid | Compressed air |
|---|---|
| Max. working pressure | 1.0 MPa (145 psi) |
| Temperature range | -5 to +70 °C (unfreeze) |
| Drain type | Differential-pressure drain |
| Bowl material | PC |
| Pressure gauge | Fitted — square, MPa scale |
| Reflux valve | Fitted (reverse flow permitted) |
Specifications follow the official AirTAC G-series air-preparation data. The regulating band is set by the drain type: automatic and differential-pressure drains regulate 0.15 - 0.9 MPa, a manual drain regulates 0.05 - 0.9 MPa. Standard type, regulating 0.15 - 0.9 MPa (20 - 130 psi). The set has no separate bracket code — the two units couple together with their own mounting hardware. Flow curves, weight and outline dimensions are not published in our data set — ask us and we will confirm from the factory datasheet.
Model Code: AirTAC GFC200-06 Combination Unit (GFC20006F1K)
| GFC200 | G-series two-unit set, 200 body — sets the port range. |
|---|---|
| 06 | Port size PT1/8". This body offers 06 = PT1/8", 08 = PT1/4". |
| (blank) | Drain: Differential-pressure drain — this also sets the regulating band (0.15 - 0.9 MPa (20 - 130 psi)). |
| (blank) | Standard type. Blank is standard, L is the low-pressure type. |
| (blank) | Pressure gauge fitted (blank). |
| F | Gauge shape: Square. C is round, F is square. |
| 1 | Gauge scale: MPa. 1 is MPa, 2 is psi, 3 is bar. |
| (blank) | Filtering grade 40 µm. Only 40 µm (blank) and 5 µm (W) exist. |
| (blank) | PT thread. PT is the default; G is BSPP and T is NPT. |
| K | Reverse-flow (reflux) valve fitted. |
Field order is size, port, drain, type, gauge, shape, scale, grade, thread, reflux — there is no bracket position on a combination set. Constituent units, orderable separately as spares: GFR200-06 filter regulator and GL200-06 lubricator.
Size Class & How It Differs From GC
- GFC200PT1/8" - PT1/4"
- GFC300PT1/4" - PT1/2"
- GFC400PT3/8" - PT1/2"
- GFC600PT3/4" - PT1"
A GFC is two units because filtering and regulating share one body. A GC is three separate units — filter, regulator and lubricator. Both filter, regulate and lubricate; the GFC is the shorter assembly, the GC keeps the filter and regulator serviceable as separate bodies.
| This model | GFC200 · PT1/8" · 40 µm |
|---|---|
| One size up | GFC300 |
| Three-unit equivalent | GC200-06 |
| Build order | Filter regulator first, lubricator last |
Where the AirTAC GFC200-06 Combination Unit (GFC20006F1K) Is Used
Hold-fast clamping circuits
Supplying clamping circuits where workpieces must stay held if the plant air dips: the K-code reverse valve holds downstream pressure while the set continues to filter, regulate and lubricate the circuit.
Machine test stands
Conditioning air on a machine test stand where supply interruptions would spoil a running test; the check valve isolates the downstream side while the regulator holds the set test pressure.
Workshop air drops
Feeding a maintenance workshop air drop that runs impact tools and small cylinders, with filtration, regulated pressure, oil mist and supply-hold behaviour from one wall-mounted set.
Is the AirTAC GFC200-06 Combination Unit (GFC20006F1K) the Right Set?
Size 200 with a 1/8 in PT port is the entry step of the G-series ladder; step up to 300, 400 or 600 when the port size or the air demand of the line calls for it. The K code is the distinguishing choice here: the fitted reverse (check) valve suits circuits where downstream pressure must be held against supply interruptions. Drain choice also matters: differential-pressure drain (this code) works off the pressure drop across the element, while automatic and manual drain codes suit other line patterns. The regulator on this differential-drain set covers 0.15-0.9 MPa (20-130 psi) with the embedded square gauge on an MPa scale.
Filter grade is another decode choice: the standard 40 um element suits general actuator supply, while the W code gives 5 um for finer protection. Threads can be ordered as PT (standard on this code), G (BSPP) or NPT, and the bracket is included unless a J code is specified. Because flow is published as curves and not a single rating, ask us to confirm sizing against your application before ordering.
Quick checklist
- ✓ Body size for your peak flow (PT1/8" here)
- ✓ Element 40 µm or 5 µm
- ✓ Drain sets the regulating band
- ✓ Gauge fitted, shape and scale
- ✓ Two-unit (GFC) or three-unit (GC) layout
- ✓ Oil mist acceptable downstream
Installation & Maintenance Notes
- check Install with the airflow arrow: filter regulator first, lubricator last.
- check Mount vertically, bowls down.
- check Keep inlet pressure at or below 1.0 MPa (145 psi).
- check Adjust only within 0.15 - 0.9 MPa (20 - 130 psi).
- check Drain condensate before the bowl fills; check the oil level.
- check Keep the set above freezing (-5 to +70 °C, unfreeze).
The PC bowls must not be cleaned with solvents — wipe them with a dry cloth. The lubricator adds an oil mist downstream, so if any branch must stay oil-free, take that branch off before the lubricator or use a GFR200-06 filter regulator on its own.
AirTAC GFC200-06 Combination Unit (GFC20006F1K) FAQ
AirTAC publishes G-series flow as curves, not as a single rated figure, so we do not quote one number here. Tell us your line pressure and air demand and we will confirm the sizing from the datasheet on request.
The K code means a reverse (check) valve is fitted, so downstream pressure is held if the upstream supply drops. The base GFC20006F1 code is identical in size, port, drain, filter grade and gauge but carries no check valve - choose the K code when holding downstream pressure matters to the circuit.
