AirTAC GFC200-06 Combination Unit (GFC20006LN)
The AirTAC AirTAC GFC200-06 Combination Unit (GFC20006LN) is a genuine G-series two-unit air-preparation set: a filter regulator that filters and regulates in one body, coupled to a lubricator. Two bodies do the work of three, with PT1/8" ports, a 40 µm element, a differential-pressure drain and regulation over 0.15 - 0.9 MPa (20 - 130 psi).
- TypeTwo-unit set (F.R. + L.)
- Port sizePT1/8"
- Regulating range0.15 - 0.9 MPa (20 - 130 psi)
- Filtering grade40 µm
- DrainDifferential-pressure drain
- Bowl materialPC
- Pressure gaugeNot fitted
- ThreadPT
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the AirTAC GFC200-06 Combination Unit (GFC20006LN)
The GFC20006LN is a genuine AirTAC G-series two-unit set: a filter regulator plus a lubricator that together filter, regulate and oil-mist lubricate compressed air. This size 200 configuration has a PT1/8 in. port, the standard 40 um filter element, a differential-pressure drain on the filter bowl, and no gauge fitted. It is a standard-pressure unit rated to 1.0 MPa (145 psi) inlet, working from -5 to 70 C (non-freezing), with polycarbonate bowls.
Omitting the gauge keeps the unit compact for panels where pressure is read elsewhere in the circuit. AirTAC builds the GFC series in sizes 200, 300, 400 and 600, with automatic, manual or differential-pressure drain options, 40 um or 5 um elements, gauge choices, and G (BSPP) or NPT thread versions to order; PT thread is standard here. Flow is published as curves rather than a single rating, so we confirm sizing and datasheet figures on request.
AirTAC GFC200-06 Combination Unit (GFC20006LN) Technical Specifications
| Model | AirTAC GFC200-06 Combination Unit (GFC20006LN) |
|---|---|
| Series | GFC200 two-unit set |
| Composition | Filter regulator + lubricator (2 units) |
| Port size | PT1/8" (PT thread) |
| Filtering grade | 40 µm |
| Regulating range | 0.15 - 0.9 MPa (20 - 130 psi) |
| Pressure type | Low-pressure type |
| Fluid | Compressed air |
|---|---|
| Max. working pressure | 1.0 MPa (145 psi) |
| Temperature range | -5 to +70 °C (unfreeze) |
| Drain type | Differential-pressure drain |
| Bowl material | PC |
| Pressure gauge | Not fitted |
| Reflux valve | Not fitted |
Specifications follow the official AirTAC G-series air-preparation data. The regulating band is set by the drain type: automatic and differential-pressure drains regulate 0.15 - 0.9 MPa, a manual drain regulates 0.05 - 0.9 MPa. The low-pressure type adjusts over a lower band than standard; we confirm the exact figures from the factory datasheet. The set has no separate bracket code — the two units couple together with their own mounting hardware. Flow curves, weight and outline dimensions are not published in our data set — ask us and we will confirm from the factory datasheet.
Model Code: AirTAC GFC200-06 Combination Unit (GFC20006LN)
| GFC200 | G-series two-unit set, 200 body — sets the port range. |
|---|---|
| 06 | Port size PT1/8". This body offers 06 = PT1/8", 08 = PT1/4". |
| (blank) | Drain: Differential-pressure drain — this also sets the regulating band (0.15 - 0.9 MPa (20 - 130 psi)). |
| L | Low-pressure type. Blank is standard, L is the low-pressure type. |
| N | No pressure gauge (N). |
| (blank) | Gauge shape: Factory standard. C is round, F is square. |
| (blank) | Gauge scale: Factory standard. 1 is MPa, 2 is psi, 3 is bar. |
| (blank) | Filtering grade 40 µm. Only 40 µm (blank) and 5 µm (W) exist. |
| (blank) | PT thread. PT is the default; G is BSPP and T is NPT. |
| (blank) | No reverse-flow valve (the default). |
Field order is size, port, drain, type, gauge, shape, scale, grade, thread, reflux — there is no bracket position on a combination set. Constituent units, orderable separately as spares: GFR200-06 filter regulator and GL200-06 lubricator.
Size Class & How It Differs From GC
- GFC200PT1/8" - PT1/4"
- GFC300PT1/4" - PT1/2"
- GFC400PT3/8" - PT1/2"
- GFC600PT3/4" - PT1"
A GFC is two units because filtering and regulating share one body. A GC is three separate units — filter, regulator and lubricator. Both filter, regulate and lubricate; the GFC is the shorter assembly, the GC keeps the filter and regulator serviceable as separate bodies.
| This model | GFC200 · PT1/8" · 40 µm |
|---|---|
| One size up | GFC300 |
| Three-unit equivalent | GC200-06 |
| Build order | Filter regulator first, lubricator last |
Where the AirTAC GFC200-06 Combination Unit (GFC20006LN) Is Used
Maintenance workshop air tools
Filters, regulates and lubricates the supply feeding impact wrenches and nailers at a maintenance workshop; with no gauge fitted, the panel's existing readout handles pressure display.
Machining-centre clamping circuit
Feeds the pneumatic clamping cylinders of a machining centre, where pressure is already read on the machine's own instrumentation, so the no-gauge LN version fits cleanly into the panel.
Press-circuit adjustment station
Lets line technicians set the working pressure of a pneumatic press circuit, with adjustment from 0.15-0.9 MPa via the differential-pressure drain and lubrication delivered to the press cylinders.
Is the AirTAC GFC200-06 Combination Unit (GFC20006LN) the Right Set?
Size 200 with its PT1/8 in. port is the compact step of the G-series; step up to 300, 400 or 600 when larger ports and more flow are needed. With the differential-pressure drain fitted here, pressure adjustment spans 0.15-0.9 MPa (20-130 psi); the N suffix means no gauge is fitted, which suits panels that already read pressure elsewhere - the LF1 version adds an embedded square MPa gauge if you want it built in. The standard 40 um element suits general plant air; the W option (5 um) screens finer particles. PT thread is standard; G (BSPP) and NPT are catalogue options. Because catalogue flow is published as curves, not a single rating, ask us to confirm sizing against your application before ordering.
Quick checklist
- ✓ Body size for your peak flow (PT1/8" here)
- ✓ Element 40 µm or 5 µm
- ✓ Drain sets the regulating band
- ✓ Gauge fitted, shape and scale
- ✓ Two-unit (GFC) or three-unit (GC) layout
- ✓ Oil mist acceptable downstream
Installation & Maintenance Notes
- check Install with the airflow arrow: filter regulator first, lubricator last.
- check Mount vertically, bowls down.
- check Keep inlet pressure at or below 1.0 MPa (145 psi).
- check Adjust only within 0.15 - 0.9 MPa (20 - 130 psi).
- check Drain condensate before the bowl fills; check the oil level.
- check Keep the set above freezing (-5 to +70 °C, unfreeze).
The PC bowls must not be cleaned with solvents — wipe them with a dry cloth. The lubricator adds an oil mist downstream, so if any branch must stay oil-free, take that branch off before the lubricator or use a GFR200-06 filter regulator on its own.
AirTAC GFC200-06 Combination Unit (GFC20006LN) FAQ
AirTAC publishes G-series flow as performance curves rather than a single rated figure, so no rated flow number is quoted here. Send us your application details and we will confirm the correct size against the datasheet curves on request.
The N suffix specifies the unit without a gauge - the regulator still adjusts pressure normally, but readout must come from elsewhere in your circuit. If you want a built-in readout, the LF1 version of the same set carries an embedded square gauge scaled in MPa, with the same PT1/8 port and differential-pressure drain.
