AirTAC GFC200-06 Combination Unit (GFC20006LNW)
The AirTAC AirTAC GFC200-06 Combination Unit (GFC20006LNW) is a genuine G-series two-unit air-preparation set: a filter regulator that filters and regulates in one body, coupled to a lubricator. Two bodies do the work of three, with PT1/8" ports, a 5 µm element, a differential-pressure drain and regulation over 0.15 - 0.9 MPa (20 - 130 psi).
- TypeTwo-unit set (F.R. + L.)
- Port sizePT1/8"
- Regulating range0.15 - 0.9 MPa (20 - 130 psi)
- Filtering grade5 µm
- DrainDifferential-pressure drain
- Bowl materialPC
- Pressure gaugeNot fitted
- ThreadPT
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the AirTAC GFC200-06 Combination Unit (GFC20006LNW)
The GFC20006LNW is a genuine AirTAC G-series two-unit set: a filter regulator plus a lubricator that together filter, regulate and oil-mist lubricate compressed air. This size 200 configuration has a PT1/8 in. port, the finer 5 um filter element (the W option), a differential-pressure drain on the filter bowl, and no gauge fitted. It is a standard-pressure unit rated to 1.0 MPa (145 psi) inlet, working from -5 to 70 C (non-freezing), with polycarbonate bowls.
Combining the finer 5 um element with a no-gauge, compact build suits circuits that need clean, lubricated air where pressure is read elsewhere. AirTAC builds the GFC series in sizes 200, 300, 400 and 600, with automatic, manual or differential-pressure drain options, 40 um or 5 um elements, gauge choices, and G (BSPP) or NPT thread versions to order; PT thread is standard here. Flow is published as curves rather than a single rating, so we confirm sizing and datasheet figures on request.
AirTAC GFC200-06 Combination Unit (GFC20006LNW) Technical Specifications
| Model | AirTAC GFC200-06 Combination Unit (GFC20006LNW) |
|---|---|
| Series | GFC200 two-unit set |
| Composition | Filter regulator + lubricator (2 units) |
| Port size | PT1/8" (PT thread) |
| Filtering grade | 5 µm |
| Regulating range | 0.15 - 0.9 MPa (20 - 130 psi) |
| Pressure type | Low-pressure type |
| Fluid | Compressed air |
|---|---|
| Max. working pressure | 1.0 MPa (145 psi) |
| Temperature range | -5 to +70 °C (unfreeze) |
| Drain type | Differential-pressure drain |
| Bowl material | PC |
| Pressure gauge | Not fitted |
| Reflux valve | Not fitted |
Specifications follow the official AirTAC G-series air-preparation data. The regulating band is set by the drain type: automatic and differential-pressure drains regulate 0.15 - 0.9 MPa, a manual drain regulates 0.05 - 0.9 MPa. The low-pressure type adjusts over a lower band than standard; we confirm the exact figures from the factory datasheet. The set has no separate bracket code — the two units couple together with their own mounting hardware. Flow curves, weight and outline dimensions are not published in our data set — ask us and we will confirm from the factory datasheet.
Model Code: AirTAC GFC200-06 Combination Unit (GFC20006LNW)
| GFC200 | G-series two-unit set, 200 body — sets the port range. |
|---|---|
| 06 | Port size PT1/8". This body offers 06 = PT1/8", 08 = PT1/4". |
| (blank) | Drain: Differential-pressure drain — this also sets the regulating band (0.15 - 0.9 MPa (20 - 130 psi)). |
| L | Low-pressure type. Blank is standard, L is the low-pressure type. |
| N | No pressure gauge (N). |
| (blank) | Gauge shape: Factory standard. C is round, F is square. |
| (blank) | Gauge scale: Factory standard. 1 is MPa, 2 is psi, 3 is bar. |
| W | Filtering grade 5 µm. Only 40 µm (blank) and 5 µm (W) exist. |
| (blank) | PT thread. PT is the default; G is BSPP and T is NPT. |
| (blank) | No reverse-flow valve (the default). |
Field order is size, port, drain, type, gauge, shape, scale, grade, thread, reflux — there is no bracket position on a combination set. Constituent units, orderable separately as spares: GFR200-06 filter regulator and GL200-06 lubricator.
Size Class & How It Differs From GC
- GFC200PT1/8" - PT1/4"
- GFC300PT1/4" - PT1/2"
- GFC400PT3/8" - PT1/2"
- GFC600PT3/4" - PT1"
A GFC is two units because filtering and regulating share one body. A GC is three separate units — filter, regulator and lubricator. Both filter, regulate and lubricate; the GFC is the shorter assembly, the GC keeps the filter and regulator serviceable as separate bodies.
| This model | GFC200 · PT1/8" · 5 µm |
|---|---|
| One size up | GFC300 |
| Three-unit equivalent | GC200-06 |
| Build order | Filter regulator first, lubricator last |
Where the AirTAC GFC200-06 Combination Unit (GFC20006LNW) Is Used
Control-panel actuator supply
Conditions the air feeding the pneumatic actuators inside a control panel, with the 5 um element screening finer particles and no gauge needed where the panel already displays pressure.
Textile machine cylinders
Filters to 5 um, regulates and lubricates the air feeding the cylinders on a textile machine, keeping the machine's air circuit clean without adding gauge hardware to the panel.
Small assembly-press feed
Supplies clean, pressure-set, lubricated air to the cylinders of a small assembly press, with pressure read on the machine's own instrumentation rather than on the unit.
Is the AirTAC GFC200-06 Combination Unit (GFC20006LNW) the Right Set?
Size 200 with its PT1/8 in. port is the compact step of the G-series; step up to 300, 400 or 600 when larger ports and more flow are needed. The W suffix specifies the 5 um element over the standard 40 um grade - pick it when downstream devices need finer particle removal. With the differential-pressure drain fitted here, pressure adjustment spans 0.15-0.9 MPa (20-130 psi), and the N suffix means no gauge is fitted; the LF1 version adds an embedded square MPa gauge if readout is required. PT thread is standard; G (BSPP) and NPT are catalogue options. Because catalogue flow is published as curves, not a single rating, ask us to confirm sizing against your application before ordering.
Quick checklist
- ✓ Body size for your peak flow (PT1/8" here)
- ✓ Element 40 µm or 5 µm
- ✓ Drain sets the regulating band
- ✓ Gauge fitted, shape and scale
- ✓ Two-unit (GFC) or three-unit (GC) layout
- ✓ Oil mist acceptable downstream
Installation & Maintenance Notes
- check Install with the airflow arrow: filter regulator first, lubricator last.
- check Mount vertically, bowls down.
- check Keep inlet pressure at or below 1.0 MPa (145 psi).
- check Adjust only within 0.15 - 0.9 MPa (20 - 130 psi).
- check Drain condensate before the bowl fills; check the oil level.
- check Keep the set above freezing (-5 to +70 °C, unfreeze).
The PC bowls must not be cleaned with solvents — wipe them with a dry cloth. The lubricator adds an oil mist downstream, so if any branch must stay oil-free, take that branch off before the lubricator or use a GFR200-06 filter regulator on its own.
AirTAC GFC200-06 Combination Unit (GFC20006LNW) FAQ
AirTAC publishes G-series flow as performance curves rather than a single rated figure, so no rated flow number is quoted here. Share your application details with us and we will confirm the correct size against the datasheet curves on request.
W specifies the 5 um filter element instead of the standard 40 um grade, and N specifies that no gauge is fitted - pressure is adjusted by the regulator but read elsewhere in your circuit. Both choices apply to this two-unit set only; its filtering, regulating and lubricating functions and PT1/8 port are otherwise identical to the other GFC20006 variants.
