AirTAC GFC200-06 Combination Unit (GFC20006MC1)
The AirTAC AirTAC GFC200-06 Combination Unit (GFC20006MC1) is a genuine G-series two-unit air-preparation set: a filter regulator that filters and regulates in one body, coupled to a lubricator. Two bodies do the work of three, with PT1/8" ports, a 40 µm element, a manual drain and regulation over 0.05 - 0.9 MPa (7 - 130 psi).
- TypeTwo-unit set (F.R. + L.)
- Port sizePT1/8"
- Regulating range0.05 - 0.9 MPa (7 - 130 psi)
- Filtering grade40 µm
- DrainManual drain
- Bowl materialPC
- Pressure gaugeFitted
- ThreadPT
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the AirTAC GFC200-06 Combination Unit (GFC20006MC1)
GFC20006MC1 is a genuine AirTAC G-series two-unit air treatment set, pairing a filter regulator with a lubricator for size 200 pipework on PT1/8 (1/8 in) ports. The filter section strips water and particulate with the standard 40 um element and a manual drain; the regulator section holds downstream pressure with an adjustment range of 0.05-0.9 MPa (7-130 psi); the lubricator meters oil mist to the air tools and cylinders it feeds. Maximum working pressure is 1.0 MPa (145 psi), the temperature range is -5 to 70 C, and at this size both bowls are polycarbonate. A round external pressure gauge on the MPa scale is included.
This is a genuine AirTAC part from the G series, which spans sizes 200, 300, 400 and 600 with ports from 1/8 to 1 in and thread options PT (standard), G (BSPP) and NPT. Drain type, filter grade, gauge style and scale and reverse/check valve options can be selected across the range. Flow for the G series is published as curves rather than a single rating, so we confirm sizing and full datasheet figures for your application on request.
AirTAC GFC200-06 Combination Unit (GFC20006MC1) Technical Specifications
| Model | AirTAC GFC200-06 Combination Unit (GFC20006MC1) |
|---|---|
| Series | GFC200 two-unit set |
| Composition | Filter regulator + lubricator (2 units) |
| Port size | PT1/8" (PT thread) |
| Filtering grade | 40 µm |
| Regulating range | 0.05 - 0.9 MPa (7 - 130 psi) |
| Pressure type | Standard type |
| Fluid | Compressed air |
|---|---|
| Max. working pressure | 1.0 MPa (145 psi) |
| Temperature range | -5 to +70 °C (unfreeze) |
| Drain type | Manual drain |
| Bowl material | PC |
| Pressure gauge | Fitted — round, MPa scale |
| Reflux valve | Not fitted |
Specifications follow the official AirTAC G-series air-preparation data. The regulating band is set by the drain type: automatic and differential-pressure drains regulate 0.15 - 0.9 MPa, a manual drain regulates 0.05 - 0.9 MPa. Standard type, regulating 0.05 - 0.9 MPa (7 - 130 psi). The set has no separate bracket code — the two units couple together with their own mounting hardware. Flow curves, weight and outline dimensions are not published in our data set — ask us and we will confirm from the factory datasheet.
Model Code: AirTAC GFC200-06 Combination Unit (GFC20006MC1)
| GFC200 | G-series two-unit set, 200 body — sets the port range. |
|---|---|
| 06 | Port size PT1/8". This body offers 06 = PT1/8", 08 = PT1/4". |
| M | Drain: Manual drain — this also sets the regulating band (0.05 - 0.9 MPa (7 - 130 psi)). |
| (blank) | Standard type. Blank is standard, L is the low-pressure type. |
| (blank) | Pressure gauge fitted (blank). |
| C | Gauge shape: Round. C is round, F is square. |
| 1 | Gauge scale: MPa. 1 is MPa, 2 is psi, 3 is bar. |
| (blank) | Filtering grade 40 µm. Only 40 µm (blank) and 5 µm (W) exist. |
| (blank) | PT thread. PT is the default; G is BSPP and T is NPT. |
| (blank) | No reverse-flow valve (the default). |
Field order is size, port, drain, type, gauge, shape, scale, grade, thread, reflux — there is no bracket position on a combination set. Constituent units, orderable separately as spares: GFR200-06 filter regulator and GL200-06 lubricator.
Size Class & How It Differs From GC
- GFC200PT1/8" - PT1/4"
- GFC300PT1/4" - PT1/2"
- GFC400PT3/8" - PT1/2"
- GFC600PT3/4" - PT1"
A GFC is two units because filtering and regulating share one body. A GC is three separate units — filter, regulator and lubricator. Both filter, regulate and lubricate; the GFC is the shorter assembly, the GC keeps the filter and regulator serviceable as separate bodies.
| This model | GFC200 · PT1/8" · 40 µm |
|---|---|
| One size up | GFC300 |
| Three-unit equivalent | GC200-06 |
| Build order | Filter regulator first, lubricator last |
Where the AirTAC GFC200-06 Combination Unit (GFC20006MC1) Is Used
Vehicle service bay impact tool stations
Drops feeding impact wrenches and air ratchets at a workshop bench: the set filters shop air, holds steady tool pressure and feeds oil mist so the tools keep their internal lubrication.
Assembly bench clamping fixtures
Supply to small pneumatic clamp and swing cylinders on an assembly fixture, where the regulator sets a repeatable clamp force and the lubricator conditions the cylinders.
Packaging machine actuator supply
Air preparation ahead of small actuators and air jets on a carton-sealing or labelling machine, keeping water and debris out of the valves while maintaining set pressure.
Is the AirTAC GFC200-06 Combination Unit (GFC20006MC1) the Right Set?
Size 200 with PT1/8 ports is the smallest step in the G series; step up to 300, 400 or 600 when the application needs a larger port and more flow. The M code sets a manual drain, which also widens the regulator adjustment range to 0.05-0.9 MPa (7-130 psi); automatic and differential-pressure drains are catalogue alternatives that start regulating at 0.15 MPa. The standard 40 um element suits general air preparation; order the W variant for a 5 um element where finer filtration matters. This configuration carries a round external gauge on the MPa scale; psi or bar scales and the embedded square gauge are other catalogue options. PT is the standard thread, with G (BSPP) and NPT orderable as specification options. Because flow is published as curves rather than a single rating, ask us to confirm sizing against your application before ordering.
Quick checklist
- ✓ Body size for your peak flow (PT1/8" here)
- ✓ Element 40 µm or 5 µm
- ✓ Drain sets the regulating band
- ✓ Gauge fitted, shape and scale
- ✓ Two-unit (GFC) or three-unit (GC) layout
- ✓ Oil mist acceptable downstream
Installation & Maintenance Notes
- check Install with the airflow arrow: filter regulator first, lubricator last.
- check Mount vertically, bowls down.
- check Keep inlet pressure at or below 1.0 MPa (145 psi).
- check Adjust only within 0.05 - 0.9 MPa (7 - 130 psi).
- check Drain condensate before the bowl fills; check the oil level.
- check Keep the set above freezing (-5 to +70 °C, unfreeze).
The PC bowls must not be cleaned with solvents — wipe them with a dry cloth. The lubricator adds an oil mist downstream, so if any branch must stay oil-free, take that branch off before the lubricator or use a GFR200-06 filter regulator on its own.
AirTAC GFC200-06 Combination Unit (GFC20006MC1) FAQ
AirTAC publishes G-series flow as curves, not as a single rated figure, so we do not quote one number. Tell us your application and we will confirm the sizing and the full datasheet curve for the size 200 set at PT1/8 on request.
M is the manual drain on the filter bowl: you drain collected water by hand rather than automatically. Manual-drain sets also regulate from 0.05 MPa (7 psi) upward, whereas automatic and differential-pressure drain versions start at 0.15 MPa (20 psi).
