AirTAC GFC200-06 Combination Unit (GFC20006MC3K)
The AirTAC AirTAC GFC200-06 Combination Unit (GFC20006MC3K) is a genuine G-series two-unit air-preparation set: a filter regulator that filters and regulates in one body, coupled to a lubricator. Two bodies do the work of three, with PT1/8" ports, a 40 µm element, a manual drain and regulation over 0.05 - 0.9 MPa (7 - 130 psi).
- TypeTwo-unit set (F.R. + L.)
- Port sizePT1/8"
- Regulating range0.05 - 0.9 MPa (7 - 130 psi)
- Filtering grade40 µm
- DrainManual drain
- Bowl materialPC
- Pressure gaugeFitted
- ThreadPT
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the AirTAC GFC200-06 Combination Unit (GFC20006MC3K)
The AirTAC GFC20006MC3K is a two-unit air-treatment set: a filter regulator that strips water and particulate and sets downstream pressure, plus a lubricator that adds metered oil mist. The K option fits a reverse (check) valve so downstream pressure is held if supply is interrupted. This configuration is the 200 size with PT1/8 ports, manual drain, standard 40 um filtration and a round gauge reading in bar.
This is a genuine AirTAC part. GFC sets are available in sizes 200 to 600 with ports from 1/8 to 1 inch, a choice of differential-pressure, automatic or manual drain, 40 um or 5 um elements, and PT, G or NPT threads. Max working pressure is 1.0 MPa (145 psi) and temperature range is -5 to 70 C (non-freezing). Flow appears as curves in the catalogue, so we confirm datasheet figures on request.
AirTAC GFC200-06 Combination Unit (GFC20006MC3K) Technical Specifications
| Model | AirTAC GFC200-06 Combination Unit (GFC20006MC3K) |
|---|---|
| Series | GFC200 two-unit set |
| Composition | Filter regulator + lubricator (2 units) |
| Port size | PT1/8" (PT thread) |
| Filtering grade | 40 µm |
| Regulating range | 0.05 - 0.9 MPa (7 - 130 psi) |
| Pressure type | Standard type |
| Fluid | Compressed air |
|---|---|
| Max. working pressure | 1.0 MPa (145 psi) |
| Temperature range | -5 to +70 °C (unfreeze) |
| Drain type | Manual drain |
| Bowl material | PC |
| Pressure gauge | Fitted — round, bar scale |
| Reflux valve | Fitted (reverse flow permitted) |
Specifications follow the official AirTAC G-series air-preparation data. The regulating band is set by the drain type: automatic and differential-pressure drains regulate 0.15 - 0.9 MPa, a manual drain regulates 0.05 - 0.9 MPa. Standard type, regulating 0.05 - 0.9 MPa (7 - 130 psi). The set has no separate bracket code — the two units couple together with their own mounting hardware. Flow curves, weight and outline dimensions are not published in our data set — ask us and we will confirm from the factory datasheet.
Model Code: AirTAC GFC200-06 Combination Unit (GFC20006MC3K)
| GFC200 | G-series two-unit set, 200 body — sets the port range. |
|---|---|
| 06 | Port size PT1/8". This body offers 06 = PT1/8", 08 = PT1/4". |
| M | Drain: Manual drain — this also sets the regulating band (0.05 - 0.9 MPa (7 - 130 psi)). |
| (blank) | Standard type. Blank is standard, L is the low-pressure type. |
| (blank) | Pressure gauge fitted (blank). |
| C | Gauge shape: Round. C is round, F is square. |
| 3 | Gauge scale: bar. 1 is MPa, 2 is psi, 3 is bar. |
| (blank) | Filtering grade 40 µm. Only 40 µm (blank) and 5 µm (W) exist. |
| (blank) | PT thread. PT is the default; G is BSPP and T is NPT. |
| K | Reverse-flow (reflux) valve fitted. |
Field order is size, port, drain, type, gauge, shape, scale, grade, thread, reflux — there is no bracket position on a combination set. Constituent units, orderable separately as spares: GFR200-06 filter regulator and GL200-06 lubricator.
Size Class & How It Differs From GC
- GFC200PT1/8" - PT1/4"
- GFC300PT1/4" - PT1/2"
- GFC400PT3/8" - PT1/2"
- GFC600PT3/4" - PT1"
A GFC is two units because filtering and regulating share one body. A GC is three separate units — filter, regulator and lubricator. Both filter, regulate and lubricate; the GFC is the shorter assembly, the GC keeps the filter and regulator serviceable as separate bodies.
| This model | GFC200 · PT1/8" · 40 µm |
|---|---|
| One size up | GFC300 |
| Three-unit equivalent | GC200-06 |
| Build order | Filter regulator first, lubricator last |
Where the AirTAC GFC200-06 Combination Unit (GFC20006MC3K) Is Used
Small-parts press bench
Filtered, regulated and oiled air drives a light pneumatic press and its clamps at an assembly bench, with the check valve holding the ram position during supply dips.
Workshop tyre and chassis bay
A bay-side set feeding impact wrenches and inflation lines, where standard 40 um filtration, steady regulated pressure and oil mist suit general workshop tools.
Test-rig actuation supply
Point-of-use treatment for the actuator circuit of a leak-test rig, holding set pressure with the check valve while the manual drain is emptied between test batches.
Is the AirTAC GFC200-06 Combination Unit (GFC20006MC3K) the Right Set?
Pick the 200/300/400/600 size against your port and flow band; 200 with PT1/8 covers compact circuits. With manual drain (M), the regulator adjusts 0.05-0.9 MPa (7-130 psi); automatic and differential-pressure drain versions adjust 0.15-0.9 MPa (20-130 psi). This code keeps the standard 40 um element for general shop air; specify W for 5 um. The round bar gauge is fitted; MPa and psi scales and G or NPT threads are orderable. K adds the check valve.
Flow is published as curves, not a single rating, so ask us to confirm sizing from the datasheet before ordering.
Quick checklist
- ✓ Body size for your peak flow (PT1/8" here)
- ✓ Element 40 µm or 5 µm
- ✓ Drain sets the regulating band
- ✓ Gauge fitted, shape and scale
- ✓ Two-unit (GFC) or three-unit (GC) layout
- ✓ Oil mist acceptable downstream
Installation & Maintenance Notes
- check Install with the airflow arrow: filter regulator first, lubricator last.
- check Mount vertically, bowls down.
- check Keep inlet pressure at or below 1.0 MPa (145 psi).
- check Adjust only within 0.05 - 0.9 MPa (7 - 130 psi).
- check Drain condensate before the bowl fills; check the oil level.
- check Keep the set above freezing (-5 to +70 °C, unfreeze).
The PC bowls must not be cleaned with solvents — wipe them with a dry cloth. The lubricator adds an oil mist downstream, so if any branch must stay oil-free, take that branch off before the lubricator or use a GFR200-06 filter regulator on its own.
AirTAC GFC200-06 Combination Unit (GFC20006MC3K) FAQ
AirTAC does not publish a single rated flow figure for the G series; flow is given as performance curves. Share your inlet pressure and consumption and we will confirm the sizing from the datasheet on request.
M (manual) means someone opens the bowl valve to release condensate - fine for regularly visited points - and it widens the regulator adjustment range to 0.05-0.9 MPa (7-130 psi). Automatic drain empties itself, and the default differential-pressure drain bleeds as pressure drops; both adjust 0.15-0.9 MPa (20-130 psi).
