AirTAC GFC200-06 Combination Unit (GFC20006MF1)
The AirTAC AirTAC GFC200-06 Combination Unit (GFC20006MF1) is a genuine G-series two-unit air-preparation set: a filter regulator that filters and regulates in one body, coupled to a lubricator. Two bodies do the work of three, with PT1/8" ports, a 40 µm element, a manual drain and regulation over 0.05 - 0.9 MPa (7 - 130 psi).
- TypeTwo-unit set (F.R. + L.)
- Port sizePT1/8"
- Regulating range0.05 - 0.9 MPa (7 - 130 psi)
- Filtering grade40 µm
- DrainManual drain
- Bowl materialPC
- Pressure gaugeFitted
- ThreadPT
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the AirTAC GFC200-06 Combination Unit (GFC20006MF1)
The AirTAC GFC20006MF1 is a two-unit air-treatment set that combines a filter regulator and a lubricator: the first stage removes water and particulate and regulates downstream pressure, the second meters oil mist into the air line. This configuration is the 200 size with PT1/8 ports, a manual-drain bowl, the standard 40 um filter element and a square gauge reading in MPa.
This is a genuine AirTAC part. The GFC series covers sizes 200 to 600 with ports from 1/8 to 1 inch, drain options of differential-pressure, automatic or manual, 40 um or 5 um filtration, and PT, G or NPT threads. Max working pressure is 1.0 MPa (145 psi); operating temperature is -5 to 70 C (non-freezing). Flow figures are published as curves rather than one rating, so we confirm datasheet numbers on request.
AirTAC GFC200-06 Combination Unit (GFC20006MF1) Technical Specifications
| Model | AirTAC GFC200-06 Combination Unit (GFC20006MF1) |
|---|---|
| Series | GFC200 two-unit set |
| Composition | Filter regulator + lubricator (2 units) |
| Port size | PT1/8" (PT thread) |
| Filtering grade | 40 µm |
| Regulating range | 0.05 - 0.9 MPa (7 - 130 psi) |
| Pressure type | Standard type |
| Fluid | Compressed air |
|---|---|
| Max. working pressure | 1.0 MPa (145 psi) |
| Temperature range | -5 to +70 °C (unfreeze) |
| Drain type | Manual drain |
| Bowl material | PC |
| Pressure gauge | Fitted — square, MPa scale |
| Reflux valve | Not fitted |
Specifications follow the official AirTAC G-series air-preparation data. The regulating band is set by the drain type: automatic and differential-pressure drains regulate 0.15 - 0.9 MPa, a manual drain regulates 0.05 - 0.9 MPa. Standard type, regulating 0.05 - 0.9 MPa (7 - 130 psi). The set has no separate bracket code — the two units couple together with their own mounting hardware. Flow curves, weight and outline dimensions are not published in our data set — ask us and we will confirm from the factory datasheet.
Model Code: AirTAC GFC200-06 Combination Unit (GFC20006MF1)
| GFC200 | G-series two-unit set, 200 body — sets the port range. |
|---|---|
| 06 | Port size PT1/8". This body offers 06 = PT1/8", 08 = PT1/4". |
| M | Drain: Manual drain — this also sets the regulating band (0.05 - 0.9 MPa (7 - 130 psi)). |
| (blank) | Standard type. Blank is standard, L is the low-pressure type. |
| (blank) | Pressure gauge fitted (blank). |
| F | Gauge shape: Square. C is round, F is square. |
| 1 | Gauge scale: MPa. 1 is MPa, 2 is psi, 3 is bar. |
| (blank) | Filtering grade 40 µm. Only 40 µm (blank) and 5 µm (W) exist. |
| (blank) | PT thread. PT is the default; G is BSPP and T is NPT. |
| (blank) | No reverse-flow valve (the default). |
Field order is size, port, drain, type, gauge, shape, scale, grade, thread, reflux — there is no bracket position on a combination set. Constituent units, orderable separately as spares: GFR200-06 filter regulator and GL200-06 lubricator.
Size Class & How It Differs From GC
- GFC200PT1/8" - PT1/4"
- GFC300PT1/4" - PT1/2"
- GFC400PT3/8" - PT1/2"
- GFC600PT3/4" - PT1"
A GFC is two units because filtering and regulating share one body. A GC is three separate units — filter, regulator and lubricator. Both filter, regulate and lubricate; the GFC is the shorter assembly, the GC keeps the filter and regulator serviceable as separate bodies.
| This model | GFC200 · PT1/8" · 40 µm |
|---|---|
| One size up | GFC300 |
| Three-unit equivalent | GC200-06 |
| Build order | Filter regulator first, lubricator last |
Where the AirTAC GFC200-06 Combination Unit (GFC20006MF1) Is Used
Electronics fixture clamping
Treated air for the pneumatic clamps on a PCB test fixture, where regulated low-pressure holding and routine manual draining fit the operator's cycle.
Lab automation air supply
Point-of-use conditioning for small grippers and pipetting actuators on a laboratory automation bench, with MPa-scale readout matching the lab's instruments.
Machine setup air circuit
A compact set on a machine's setup panel feeding alignment cylinders and air blow-off, keeping standard-grade filtration, stable pressure and light lubrication at the point of use.
Is the AirTAC GFC200-06 Combination Unit (GFC20006MF1) the Right Set?
Choose the 200/300/400/600 size to match your port and flow band; 200 with PT1/8 is the compact end of the range. Manual drain (M) gives a 0.05-0.9 MPa (7-130 psi) regulator setting span - pick an automatic or differential-pressure drain code instead for unattended positions. The standard 40 um element suits general machine air; the W code gives 5 um. The square MPa gauge is specified here; round gauges and bar or psi scales, plus G or NPT threads, are orderable.
Because flow is published as curves rather than a single rated number, ask us to confirm sizing against your application before ordering.
Quick checklist
- ✓ Body size for your peak flow (PT1/8" here)
- ✓ Element 40 µm or 5 µm
- ✓ Drain sets the regulating band
- ✓ Gauge fitted, shape and scale
- ✓ Two-unit (GFC) or three-unit (GC) layout
- ✓ Oil mist acceptable downstream
Installation & Maintenance Notes
- check Install with the airflow arrow: filter regulator first, lubricator last.
- check Mount vertically, bowls down.
- check Keep inlet pressure at or below 1.0 MPa (145 psi).
- check Adjust only within 0.05 - 0.9 MPa (7 - 130 psi).
- check Drain condensate before the bowl fills; check the oil level.
- check Keep the set above freezing (-5 to +70 °C, unfreeze).
The PC bowls must not be cleaned with solvents — wipe them with a dry cloth. The lubricator adds an oil mist downstream, so if any branch must stay oil-free, take that branch off before the lubricator or use a GFR200-06 filter regulator on its own.
AirTAC GFC200-06 Combination Unit (GFC20006MF1) FAQ
We cannot quote a single rated flow figure because AirTAC publishes G-series flow as performance curves, not one number. Give us your working pressure and demand and we will confirm the size from the datasheet on request.
F selects the square gauge format and 1 sets its scale to MPa. A C in that position would be a round gauge, and the digit after it sets psi (2) or bar (3); a blank gauge position still includes the standard square gauge.
