AirTAC GFC200-06 Combination Unit (GFC20006MF1K)
The AirTAC AirTAC GFC200-06 Combination Unit (GFC20006MF1K) is a genuine G-series two-unit air-preparation set: a filter regulator that filters and regulates in one body, coupled to a lubricator. Two bodies do the work of three, with PT1/8" ports, a 40 µm element, a manual drain and regulation over 0.05 - 0.9 MPa (7 - 130 psi).
- TypeTwo-unit set (F.R. + L.)
- Port sizePT1/8"
- Regulating range0.05 - 0.9 MPa (7 - 130 psi)
- Filtering grade40 µm
- DrainManual drain
- Bowl materialPC
- Pressure gaugeFitted
- ThreadPT
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the AirTAC GFC200-06 Combination Unit (GFC20006MF1K)
The GFC20006MF1K is a genuine AirTAC G-series two-unit set: a filter regulator plus a separate lubricator that together filter, regulate and lubricate compressed air. Built at 200 size with PT1/8 ports, this version carries a manual drain on the bowl, the standard 40 um filter element, an embedded square pressure gauge reading in MPa, and a reverse (check) valve as specified by the K in the code. The regulator adjusts from 0.05 to 0.9 MPa (7-130 psi) on this manual-drain configuration.
Maximum working pressure is 1.0 MPa (145 psi) and the operating range is -5 to 70 C. The 200-size bowls on both the filter regulator and the lubricator are PC (polycarbonate). AirTAC offers the G series in 200, 300, 400 and 600 sizes with automatic, manual or differential-pressure drains, 5 um or 40 um elements, MPa, psi or bar gauges, and G (BSPP) or NPT threads as catalogue options. Flow figures are published as curves, so we confirm datasheet details on request.
AirTAC GFC200-06 Combination Unit (GFC20006MF1K) Technical Specifications
| Model | AirTAC GFC200-06 Combination Unit (GFC20006MF1K) |
|---|---|
| Series | GFC200 two-unit set |
| Composition | Filter regulator + lubricator (2 units) |
| Port size | PT1/8" (PT thread) |
| Filtering grade | 40 µm |
| Regulating range | 0.05 - 0.9 MPa (7 - 130 psi) |
| Pressure type | Standard type |
| Fluid | Compressed air |
|---|---|
| Max. working pressure | 1.0 MPa (145 psi) |
| Temperature range | -5 to +70 °C (unfreeze) |
| Drain type | Manual drain |
| Bowl material | PC |
| Pressure gauge | Fitted — square, MPa scale |
| Reflux valve | Fitted (reverse flow permitted) |
Specifications follow the official AirTAC G-series air-preparation data. The regulating band is set by the drain type: automatic and differential-pressure drains regulate 0.15 - 0.9 MPa, a manual drain regulates 0.05 - 0.9 MPa. Standard type, regulating 0.05 - 0.9 MPa (7 - 130 psi). The set has no separate bracket code — the two units couple together with their own mounting hardware. Flow curves, weight and outline dimensions are not published in our data set — ask us and we will confirm from the factory datasheet.
Model Code: AirTAC GFC200-06 Combination Unit (GFC20006MF1K)
| GFC200 | G-series two-unit set, 200 body — sets the port range. |
|---|---|
| 06 | Port size PT1/8". This body offers 06 = PT1/8", 08 = PT1/4". |
| M | Drain: Manual drain — this also sets the regulating band (0.05 - 0.9 MPa (7 - 130 psi)). |
| (blank) | Standard type. Blank is standard, L is the low-pressure type. |
| (blank) | Pressure gauge fitted (blank). |
| F | Gauge shape: Square. C is round, F is square. |
| 1 | Gauge scale: MPa. 1 is MPa, 2 is psi, 3 is bar. |
| (blank) | Filtering grade 40 µm. Only 40 µm (blank) and 5 µm (W) exist. |
| (blank) | PT thread. PT is the default; G is BSPP and T is NPT. |
| K | Reverse-flow (reflux) valve fitted. |
Field order is size, port, drain, type, gauge, shape, scale, grade, thread, reflux — there is no bracket position on a combination set. Constituent units, orderable separately as spares: GFR200-06 filter regulator and GL200-06 lubricator.
Size Class & How It Differs From GC
- GFC200PT1/8" - PT1/4"
- GFC300PT1/4" - PT1/2"
- GFC400PT3/8" - PT1/2"
- GFC600PT3/4" - PT1"
A GFC is two units because filtering and regulating share one body. A GC is three separate units — filter, regulator and lubricator. Both filter, regulate and lubricate; the GFC is the shorter assembly, the GC keeps the filter and regulator serviceable as separate bodies.
| This model | GFC200 · PT1/8" · 40 µm |
|---|---|
| One size up | GFC300 |
| Three-unit equivalent | GC200-06 |
| Build order | Filter regulator first, lubricator last |
Where the AirTAC GFC200-06 Combination Unit (GFC20006MF1K) Is Used
Carton-sealer clamp cylinders
Air preparation for the small clamp and flap-tuck cylinders on a carton sealing conveyor, where the manual drain suits a station an operator visits each shift and the reverse valve is written into the circuit spec.
Lab automation air manifold
Conditioning supply air for benchtop laboratory automation - compact grippers and solenoid valves running on 1/8 in lines - with the square MPa gauge giving a direct local pressure readout at the panel.
Pneumatic screwdriver station
Filtering, regulating and lubricating air for a bench-mounted pneumatic screwdriver or nutrunner station, keeping the tool feed consistent at a set pressure with local indication.
Is the AirTAC GFC200-06 Combination Unit (GFC20006MF1K) the Right Set?
This code fixes the configuration: 200 size with PT1/8 ports for compact circuits, a manual drain (M) instead of the differential-pressure default or the automatic (A) option, the 40 um standard element rather than the 5 um (W) grade, a square gauge on the MPa scale, and a fitted reverse (check) valve (K). Step up to 300, 400 or 600 if your line needs larger ports and more capacity. Threads are PT as the standard; G (BSPP) and NPT (T) are catalogue options you can order.
Flow for the G series is published as characteristic curves, not a single rating, so share your flow and pressure requirement and we will confirm sizing against the datasheet before you order.
Quick checklist
- ✓ Body size for your peak flow (PT1/8" here)
- ✓ Element 40 µm or 5 µm
- ✓ Drain sets the regulating band
- ✓ Gauge fitted, shape and scale
- ✓ Two-unit (GFC) or three-unit (GC) layout
- ✓ Oil mist acceptable downstream
Installation & Maintenance Notes
- check Install with the airflow arrow: filter regulator first, lubricator last.
- check Mount vertically, bowls down.
- check Keep inlet pressure at or below 1.0 MPa (145 psi).
- check Adjust only within 0.05 - 0.9 MPa (7 - 130 psi).
- check Drain condensate before the bowl fills; check the oil level.
- check Keep the set above freezing (-5 to +70 °C, unfreeze).
The PC bowls must not be cleaned with solvents — wipe them with a dry cloth. The lubricator adds an oil mist downstream, so if any branch must stay oil-free, take that branch off before the lubricator or use a GFR200-06 filter regulator on its own.
AirTAC GFC200-06 Combination Unit (GFC20006MF1K) FAQ
AirTAC publishes G-series flow as characteristic curves rather than one rated figure, so we do not quote a single number. Send us your required flow and working pressure and we will confirm sizing against the datasheet curves on request before you order.
The M in the code selects the manual drain on the filter-regulator bowl, which is opened by hand to release collected water. The differential-pressure drain is the default, and an automatic drain (code A) is available if the station is not checked regularly.
