AirTAC GFC200-06 Combination Unit (GFC20006MF1WK)
The AirTAC AirTAC GFC200-06 Combination Unit (GFC20006MF1WK) is a genuine G-series two-unit air-preparation set: a filter regulator that filters and regulates in one body, coupled to a lubricator. Two bodies do the work of three, with PT1/8" ports, a 5 µm element, a manual drain and regulation over 0.05 - 0.9 MPa (7 - 130 psi).
- TypeTwo-unit set (F.R. + L.)
- Port sizePT1/8"
- Regulating range0.05 - 0.9 MPa (7 - 130 psi)
- Filtering grade5 µm
- DrainManual drain
- Bowl materialPC
- Pressure gaugeFitted
- ThreadPT
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the AirTAC GFC200-06 Combination Unit (GFC20006MF1WK)
The GFC20006MF1WK is a genuine AirTAC G-series two-unit set combining a filter regulator and a lubricator, so compressed air is filtered, regulated and lubricated by one ordered package. This 200-size, PT1/8 configuration specifies a manual drain, the 5 um fine filtration element, an embedded square gauge on the MPa scale, and a reverse (check) valve in the regulator section, as marked by the K. The regulator adjusts from 0.05 to 0.9 MPa (7-130 psi) on this manual-drain version.
It is rated for 1.0 MPa (145 psi) maximum working pressure and -5 to 70 C operation, with PC (polycarbonate) bowls on both units at 200 size. AirTAC builds the G series in 200, 300, 400 and 600 sizes, with drain, filter grade, gauge scale and thread (PT standard, G or NPT) as catalogue options. Flow is published as curves, so we confirm datasheet figures on request.
AirTAC GFC200-06 Combination Unit (GFC20006MF1WK) Technical Specifications
| Model | AirTAC GFC200-06 Combination Unit (GFC20006MF1WK) |
|---|---|
| Series | GFC200 two-unit set |
| Composition | Filter regulator + lubricator (2 units) |
| Port size | PT1/8" (PT thread) |
| Filtering grade | 5 µm |
| Regulating range | 0.05 - 0.9 MPa (7 - 130 psi) |
| Pressure type | Standard type |
| Fluid | Compressed air |
|---|---|
| Max. working pressure | 1.0 MPa (145 psi) |
| Temperature range | -5 to +70 °C (unfreeze) |
| Drain type | Manual drain |
| Bowl material | PC |
| Pressure gauge | Fitted — square, MPa scale |
| Reflux valve | Fitted (reverse flow permitted) |
Specifications follow the official AirTAC G-series air-preparation data. The regulating band is set by the drain type: automatic and differential-pressure drains regulate 0.15 - 0.9 MPa, a manual drain regulates 0.05 - 0.9 MPa. Standard type, regulating 0.05 - 0.9 MPa (7 - 130 psi). The set has no separate bracket code — the two units couple together with their own mounting hardware. Flow curves, weight and outline dimensions are not published in our data set — ask us and we will confirm from the factory datasheet.
Model Code: AirTAC GFC200-06 Combination Unit (GFC20006MF1WK)
| GFC200 | G-series two-unit set, 200 body — sets the port range. |
|---|---|
| 06 | Port size PT1/8". This body offers 06 = PT1/8", 08 = PT1/4". |
| M | Drain: Manual drain — this also sets the regulating band (0.05 - 0.9 MPa (7 - 130 psi)). |
| (blank) | Standard type. Blank is standard, L is the low-pressure type. |
| (blank) | Pressure gauge fitted (blank). |
| F | Gauge shape: Square. C is round, F is square. |
| 1 | Gauge scale: MPa. 1 is MPa, 2 is psi, 3 is bar. |
| W | Filtering grade 5 µm. Only 40 µm (blank) and 5 µm (W) exist. |
| (blank) | PT thread. PT is the default; G is BSPP and T is NPT. |
| K | Reverse-flow (reflux) valve fitted. |
Field order is size, port, drain, type, gauge, shape, scale, grade, thread, reflux — there is no bracket position on a combination set. Constituent units, orderable separately as spares: GFR200-06 filter regulator and GL200-06 lubricator.
Size Class & How It Differs From GC
- GFC200PT1/8" - PT1/4"
- GFC300PT1/4" - PT1/2"
- GFC400PT3/8" - PT1/2"
- GFC600PT3/4" - PT1"
A GFC is two units because filtering and regulating share one body. A GC is three separate units — filter, regulator and lubricator. Both filter, regulate and lubricate; the GFC is the shorter assembly, the GC keeps the filter and regulator serviceable as separate bodies.
| This model | GFC200 · PT1/8" · 5 µm |
|---|---|
| One size up | GFC300 |
| Three-unit equivalent | GC200-06 |
| Build order | Filter regulator first, lubricator last |
Where the AirTAC GFC200-06 Combination Unit (GFC20006MF1WK) Is Used
Assembly cell cylinder feed
Air preparation for small actuator drops in an assembly cell specified with fine filtration and a check valve in the regulator section, drained manually at each shift.
Control-panel pilot supply
Filtered, regulated and lubricated pilot air for valve manifolds and panel components on 1/8 in lines, where the 5 um element and MPa gauge are written into the panel spec.
Pneumatic fixture clamping
Conditioning air to workholding clamps on a machining fixture, holding the specified set pressure with local square-gauge indication and fine filtration ahead of the clamps.
Is the AirTAC GFC200-06 Combination Unit (GFC20006MF1WK) the Right Set?
Decode of this code: 200 size, PT1/8 ports, manual drain (M) instead of the differential-pressure default or automatic (A), 5 um element (W) rather than the 40 um standard, square MPa gauge, and the K option fitting a reverse (check) valve. Choose the same code without K if your circuit does not call for one, or step to 300/400/600 for larger ports.
Flow for the G series appears only as characteristic curves, not a single rating, so send your flow and pressure requirement and we will confirm sizing against the datasheet before you order.
Quick checklist
- ✓ Body size for your peak flow (PT1/8" here)
- ✓ Element 40 µm or 5 µm
- ✓ Drain sets the regulating band
- ✓ Gauge fitted, shape and scale
- ✓ Two-unit (GFC) or three-unit (GC) layout
- ✓ Oil mist acceptable downstream
Installation & Maintenance Notes
- check Install with the airflow arrow: filter regulator first, lubricator last.
- check Mount vertically, bowls down.
- check Keep inlet pressure at or below 1.0 MPa (145 psi).
- check Adjust only within 0.05 - 0.9 MPa (7 - 130 psi).
- check Drain condensate before the bowl fills; check the oil level.
- check Keep the set above freezing (-5 to +70 °C, unfreeze).
The PC bowls must not be cleaned with solvents — wipe them with a dry cloth. The lubricator adds an oil mist downstream, so if any branch must stay oil-free, take that branch off before the lubricator or use a GFR200-06 filter regulator on its own.
AirTAC GFC200-06 Combination Unit (GFC20006MF1WK) FAQ
AirTAC publishes G-series flow as characteristic curves rather than a single rated figure, so we will not quote a number here. Share your required flow, port size and working pressure and we will confirm sizing against the datasheet on request before you order.
K specifies that a reverse (check) valve is fitted in the regulator section. The same set ordered as GFC20006MF1W, without the K, is identical apart from that option.
