AirTAC GFC200-06 Combination Unit (GFC20006MF3)
The AirTAC AirTAC GFC200-06 Combination Unit (GFC20006MF3) is a genuine G-series two-unit air-preparation set: a filter regulator that filters and regulates in one body, coupled to a lubricator. Two bodies do the work of three, with PT1/8" ports, a 40 µm element, a manual drain and regulation over 0.05 - 0.9 MPa (7 - 130 psi).
- TypeTwo-unit set (F.R. + L.)
- Port sizePT1/8"
- Regulating range0.05 - 0.9 MPa (7 - 130 psi)
- Filtering grade40 µm
- DrainManual drain
- Bowl materialPC
- Pressure gaugeFitted
- ThreadPT
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the AirTAC GFC200-06 Combination Unit (GFC20006MF3)
The GFC20006MF3 is a genuine AirTAC G-series two-unit set: a filter regulator and a separate lubricator providing filtration, regulation and lubrication together. At 200 size with PT1/8 ports, this version has a manual drain on the bowl, the standard 40 um filter element, and an embedded square pressure gauge calibrated in bar (scale 3). No reverse valve is fitted. The regulator adjusts from 0.05 to 0.9 MPa (7-130 psi) on this manual-drain configuration.
Maximum working pressure is 1.0 MPa (145 psi), the operating range is -5 to 70 C, and the 200-size bowls are PC (polycarbonate). The G series spans 200, 300, 400 and 600 sizes, with automatic or differential-pressure drains, a 5 um optional element, MPa, psi or bar gauge scales, and G (BSPP) or NPT threads as catalogue options. Flow figures are published as curves, so we confirm datasheet details on request.
AirTAC GFC200-06 Combination Unit (GFC20006MF3) Technical Specifications
| Model | AirTAC GFC200-06 Combination Unit (GFC20006MF3) |
|---|---|
| Series | GFC200 two-unit set |
| Composition | Filter regulator + lubricator (2 units) |
| Port size | PT1/8" (PT thread) |
| Filtering grade | 40 µm |
| Regulating range | 0.05 - 0.9 MPa (7 - 130 psi) |
| Pressure type | Standard type |
| Fluid | Compressed air |
|---|---|
| Max. working pressure | 1.0 MPa (145 psi) |
| Temperature range | -5 to +70 °C (unfreeze) |
| Drain type | Manual drain |
| Bowl material | PC |
| Pressure gauge | Fitted — square, bar scale |
| Reflux valve | Not fitted |
Specifications follow the official AirTAC G-series air-preparation data. The regulating band is set by the drain type: automatic and differential-pressure drains regulate 0.15 - 0.9 MPa, a manual drain regulates 0.05 - 0.9 MPa. Standard type, regulating 0.05 - 0.9 MPa (7 - 130 psi). The set has no separate bracket code — the two units couple together with their own mounting hardware. Flow curves, weight and outline dimensions are not published in our data set — ask us and we will confirm from the factory datasheet.
Model Code: AirTAC GFC200-06 Combination Unit (GFC20006MF3)
| GFC200 | G-series two-unit set, 200 body — sets the port range. |
|---|---|
| 06 | Port size PT1/8". This body offers 06 = PT1/8", 08 = PT1/4". |
| M | Drain: Manual drain — this also sets the regulating band (0.05 - 0.9 MPa (7 - 130 psi)). |
| (blank) | Standard type. Blank is standard, L is the low-pressure type. |
| (blank) | Pressure gauge fitted (blank). |
| F | Gauge shape: Square. C is round, F is square. |
| 3 | Gauge scale: bar. 1 is MPa, 2 is psi, 3 is bar. |
| (blank) | Filtering grade 40 µm. Only 40 µm (blank) and 5 µm (W) exist. |
| (blank) | PT thread. PT is the default; G is BSPP and T is NPT. |
| (blank) | No reverse-flow valve (the default). |
Field order is size, port, drain, type, gauge, shape, scale, grade, thread, reflux — there is no bracket position on a combination set. Constituent units, orderable separately as spares: GFR200-06 filter regulator and GL200-06 lubricator.
Size Class & How It Differs From GC
- GFC200PT1/8" - PT1/4"
- GFC300PT1/4" - PT1/2"
- GFC400PT3/8" - PT1/2"
- GFC600PT3/4" - PT1"
A GFC is two units because filtering and regulating share one body. A GC is three separate units — filter, regulator and lubricator. Both filter, regulate and lubricate; the GFC is the shorter assembly, the GC keeps the filter and regulator serviceable as separate bodies.
| This model | GFC200 · PT1/8" · 40 µm |
|---|---|
| One size up | GFC300 |
| Three-unit equivalent | GC200-06 |
| Build order | Filter regulator first, lubricator last |
Where the AirTAC GFC200-06 Combination Unit (GFC20006MF3) Is Used
European-spec machine supply
Point-of-use air preparation on machinery documented in bar, feeding small actuators and valves through 1/8 in ports with a locally readable bar-scale gauge.
Maintenance-shop air drops
Conditioning air at maintenance bench drops for hand-held pneumatic tools, with manual draining at each shift and the standard 40 um element for general tool air.
Test-rig instrument air
Filtered and regulated supply for pneumatic test-rig instrumentation on 1/8 in lines, where the bar gauge matches the pressure units used on the rig documentation.
Is the AirTAC GFC200-06 Combination Unit (GFC20006MF3) the Right Set?
This code selects 200 size on PT1/8 ports, a manual drain (M) rather than the differential-pressure default or the automatic (A) option, the 40 um standard element instead of 5 um (W), and a square gauge on the bar scale - useful where equipment is documented in bar rather than MPa or psi. If your circuit calls for a different scale or a reverse valve, we can quote the matching code. Larger ports come with the 300, 400 and 600 sizes.
Flow is published as characteristic curves, not a single rating, so give us your flow and pressure duty and we will confirm sizing against the datasheet before you order.
Quick checklist
- ✓ Body size for your peak flow (PT1/8" here)
- ✓ Element 40 µm or 5 µm
- ✓ Drain sets the regulating band
- ✓ Gauge fitted, shape and scale
- ✓ Two-unit (GFC) or three-unit (GC) layout
- ✓ Oil mist acceptable downstream
Installation & Maintenance Notes
- check Install with the airflow arrow: filter regulator first, lubricator last.
- check Mount vertically, bowls down.
- check Keep inlet pressure at or below 1.0 MPa (145 psi).
- check Adjust only within 0.05 - 0.9 MPa (7 - 130 psi).
- check Drain condensate before the bowl fills; check the oil level.
- check Keep the set above freezing (-5 to +70 °C, unfreeze).
The PC bowls must not be cleaned with solvents — wipe them with a dry cloth. The lubricator adds an oil mist downstream, so if any branch must stay oil-free, take that branch off before the lubricator or use a GFR200-06 filter regulator on its own.
AirTAC GFC200-06 Combination Unit (GFC20006MF3) FAQ
Flow for the AirTAC G series is published as characteristic curves rather than a single rated figure, so we do not state one number. Tell us your flow and working pressure and we will confirm sizing against the datasheet curves on request before you order.
It selects the gauge scale of the embedded square gauge: scale 3 reads in bar, while scale 1 reads in MPa and scale 2 in psi. The rest of the code - 200 size, PT1/8, manual drain, 40 um element, no reverse valve - is unchanged.
