AirTAC GFC200-06 Combination Unit (GFC20006MLC1)
The AirTAC AirTAC GFC200-06 Combination Unit (GFC20006MLC1) is a genuine G-series two-unit air-preparation set: a filter regulator that filters and regulates in one body, coupled to a lubricator. Two bodies do the work of three, with PT1/8" ports, a 40 µm element, a manual drain and regulation over 0.05 - 0.9 MPa (7 - 130 psi).
- TypeTwo-unit set (F.R. + L.)
- Port sizePT1/8"
- Regulating range0.05 - 0.9 MPa (7 - 130 psi)
- Filtering grade40 µm
- DrainManual drain
- Bowl materialPC
- Pressure gaugeFitted
- ThreadPT
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the AirTAC GFC200-06 Combination Unit (GFC20006MLC1)
The AirTAC GFC series is a two-piece air-treatment set: a filter-regulator plus a lubricator, so one installation filters water and particulate out of the compressed air, holds a set downstream pressure and adds a controlled oil mist for downstream tools and actuators. This GFC20006MLC1 is the 200 size with PT1/8 standard ports, a manual drain on the polycarbonate filter bowl, the low-pressure type regulator with a 0.05-0.9 MPa (7-130 psi) adjustment span, a round external pressure gauge reading in MPa, and the standard 40 um filtration element. Operating temperature is -5 to 70 C, non-freezing.
This is a genuine AirTAC part. The G series spans 200, 300, 400 and 600 sizes with ports from 1/8 to 1 inch, plus options for drain type, a 5 um element, gauge scale and G (BSPP) or NPT thread in place of the PT standard. Rated flow is published as curves rather than a single number, so we confirm the datasheet and sizing figures on request.
AirTAC GFC200-06 Combination Unit (GFC20006MLC1) Technical Specifications
| Model | AirTAC GFC200-06 Combination Unit (GFC20006MLC1) |
|---|---|
| Series | GFC200 two-unit set |
| Composition | Filter regulator + lubricator (2 units) |
| Port size | PT1/8" (PT thread) |
| Filtering grade | 40 µm |
| Regulating range | 0.05 - 0.9 MPa (7 - 130 psi) |
| Pressure type | Low-pressure type |
| Fluid | Compressed air |
|---|---|
| Max. working pressure | 1.0 MPa (145 psi) |
| Temperature range | -5 to +70 °C (unfreeze) |
| Drain type | Manual drain |
| Bowl material | PC |
| Pressure gauge | Fitted — round, MPa scale |
| Reflux valve | Not fitted |
Specifications follow the official AirTAC G-series air-preparation data. The regulating band is set by the drain type: automatic and differential-pressure drains regulate 0.15 - 0.9 MPa, a manual drain regulates 0.05 - 0.9 MPa. The low-pressure type adjusts over a lower band than standard; we confirm the exact figures from the factory datasheet. The set has no separate bracket code — the two units couple together with their own mounting hardware. Flow curves, weight and outline dimensions are not published in our data set — ask us and we will confirm from the factory datasheet.
Model Code: AirTAC GFC200-06 Combination Unit (GFC20006MLC1)
| GFC200 | G-series two-unit set, 200 body — sets the port range. |
|---|---|
| 06 | Port size PT1/8". This body offers 06 = PT1/8", 08 = PT1/4". |
| M | Drain: Manual drain — this also sets the regulating band (0.05 - 0.9 MPa (7 - 130 psi)). |
| L | Low-pressure type. Blank is standard, L is the low-pressure type. |
| (blank) | Pressure gauge fitted (blank). |
| C | Gauge shape: Round. C is round, F is square. |
| 1 | Gauge scale: MPa. 1 is MPa, 2 is psi, 3 is bar. |
| (blank) | Filtering grade 40 µm. Only 40 µm (blank) and 5 µm (W) exist. |
| (blank) | PT thread. PT is the default; G is BSPP and T is NPT. |
| (blank) | No reverse-flow valve (the default). |
Field order is size, port, drain, type, gauge, shape, scale, grade, thread, reflux — there is no bracket position on a combination set. Constituent units, orderable separately as spares: GFR200-06 filter regulator and GL200-06 lubricator.
Size Class & How It Differs From GC
- GFC200PT1/8" - PT1/4"
- GFC300PT1/4" - PT1/2"
- GFC400PT3/8" - PT1/2"
- GFC600PT3/4" - PT1"
A GFC is two units because filtering and regulating share one body. A GC is three separate units — filter, regulator and lubricator. Both filter, regulate and lubricate; the GFC is the shorter assembly, the GC keeps the filter and regulator serviceable as separate bodies.
| This model | GFC200 · PT1/8" · 40 µm |
|---|---|
| One size up | GFC300 |
| Three-unit equivalent | GC200-06 |
| Build order | Filter regulator first, lubricator last |
Where the AirTAC GFC200-06 Combination Unit (GFC20006MLC1) Is Used
CNC tool-changer and air-blast supply
Filter, regulate and lubricate the air feeding a machining centre's tool-change cylinder and chip-blow nozzles; the round MPa gauge lets the setter verify set pressure at the machine drop.
Automotive repair air tools
Feed impact wrenches, ratchets and air hammers in a service bay with filtered air and a continuous oil mist, so tool motors stay lubricated through the shift.
Carton-sealer cylinders on a packaging line
Treat the air supply to carton-sealing and flap-folding cylinders, with the low-pressure type holding a gentle set pressure suited to light actuation duties.
Is the AirTAC GFC200-06 Combination Unit (GFC20006MLC1) the Right Set?
The 200 size with PT1/8 ports is the compact entry step of the G series; step up to 300/400/600 for larger ports and more flow. The manual drain here means someone opens the bowl drain by hand at intervals, which suits attended points of use; automatic or differential-pressure drain versions of this set cover unattended drops. Filtration is the standard 40 um element, with the W suffix available for 5 um. The round external gauge reads in MPa (scale 1); an embedded square gauge with psi or bar scale is an alternative code. PT thread is standard, with G (BSPP) and NPT as catalogue options. Flow is published as curves, not a single rating, so ask us to confirm sizing against your application before ordering.
Quick checklist
- ✓ Body size for your peak flow (PT1/8" here)
- ✓ Element 40 µm or 5 µm
- ✓ Drain sets the regulating band
- ✓ Gauge fitted, shape and scale
- ✓ Two-unit (GFC) or three-unit (GC) layout
- ✓ Oil mist acceptable downstream
Installation & Maintenance Notes
- check Install with the airflow arrow: filter regulator first, lubricator last.
- check Mount vertically, bowls down.
- check Keep inlet pressure at or below 1.0 MPa (145 psi).
- check Adjust only within 0.05 - 0.9 MPa (7 - 130 psi).
- check Drain condensate before the bowl fills; check the oil level.
- check Keep the set above freezing (-5 to +70 °C, unfreeze).
The PC bowls must not be cleaned with solvents — wipe them with a dry cloth. The lubricator adds an oil mist downstream, so if any branch must stay oil-free, take that branch off before the lubricator or use a GFR200-06 filter regulator on its own.
AirTAC GFC200-06 Combination Unit (GFC20006MLC1) FAQ
AirTAC publishes flow for this series as capacity curves, not as a single rated figure, so quoting one number here would be misleading. Send us your line pressure, set pressure and downstream demand and we will confirm the sizing from the datasheet on request.
A GFC set pairs a filter-regulator with a lubricator in two bodies, covering filtering, regulating and lubricating with a shorter assembly than the separate filter, regulator and lubricator of a three-piece GC. This version adds a manual drain, the low-pressure type regulator and a round MPa gauge; drain type, element grade and gauge scale are the other choices you can decode into a different code.
