AirTAC GFC200-06 Combination Unit (GFC20006MLC1W)
The AirTAC AirTAC GFC200-06 Combination Unit (GFC20006MLC1W) is a genuine G-series two-unit air-preparation set: a filter regulator that filters and regulates in one body, coupled to a lubricator. Two bodies do the work of three, with PT1/8" ports, a 5 µm element, a manual drain and regulation over 0.05 - 0.9 MPa (7 - 130 psi).
- TypeTwo-unit set (F.R. + L.)
- Port sizePT1/8"
- Regulating range0.05 - 0.9 MPa (7 - 130 psi)
- Filtering grade5 µm
- DrainManual drain
- Bowl materialPC
- Pressure gaugeFitted
- ThreadPT
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the AirTAC GFC200-06 Combination Unit (GFC20006MLC1W)
The AirTAC GFC series combines a filter-regulator and a lubricator in a matched two-piece set: compressed air is filtered of water and particulate, held at a set downstream pressure, then enriched with an oil mist for tools and actuators. This GFC20006MLC1W is the 200 size with PT1/8 standard ports, a manual drain on the polycarbonate filter bowl, the low-pressure type regulator with a 0.05-0.9 MPa (7-130 psi) adjustment span, a round external MPa gauge and the finer 5 um filtration element in place of the standard 40 um. Operating temperature is -5 to 70 C, non-freezing.
This is a genuine AirTAC part. The G series runs from 200 to 600 sizes with ports from 1/8 to 1 inch, with choices of drain type, filtration grade, gauge scale and G (BSPP) or NPT thread against the PT standard. Flow is published as curves rather than a single rated number, so we confirm datasheet and sizing figures on request.
AirTAC GFC200-06 Combination Unit (GFC20006MLC1W) Technical Specifications
| Model | AirTAC GFC200-06 Combination Unit (GFC20006MLC1W) |
|---|---|
| Series | GFC200 two-unit set |
| Composition | Filter regulator + lubricator (2 units) |
| Port size | PT1/8" (PT thread) |
| Filtering grade | 5 µm |
| Regulating range | 0.05 - 0.9 MPa (7 - 130 psi) |
| Pressure type | Low-pressure type |
| Fluid | Compressed air |
|---|---|
| Max. working pressure | 1.0 MPa (145 psi) |
| Temperature range | -5 to +70 °C (unfreeze) |
| Drain type | Manual drain |
| Bowl material | PC |
| Pressure gauge | Fitted — round, MPa scale |
| Reflux valve | Not fitted |
Specifications follow the official AirTAC G-series air-preparation data. The regulating band is set by the drain type: automatic and differential-pressure drains regulate 0.15 - 0.9 MPa, a manual drain regulates 0.05 - 0.9 MPa. The low-pressure type adjusts over a lower band than standard; we confirm the exact figures from the factory datasheet. The set has no separate bracket code — the two units couple together with their own mounting hardware. Flow curves, weight and outline dimensions are not published in our data set — ask us and we will confirm from the factory datasheet.
Model Code: AirTAC GFC200-06 Combination Unit (GFC20006MLC1W)
| GFC200 | G-series two-unit set, 200 body — sets the port range. |
|---|---|
| 06 | Port size PT1/8". This body offers 06 = PT1/8", 08 = PT1/4". |
| M | Drain: Manual drain — this also sets the regulating band (0.05 - 0.9 MPa (7 - 130 psi)). |
| L | Low-pressure type. Blank is standard, L is the low-pressure type. |
| (blank) | Pressure gauge fitted (blank). |
| C | Gauge shape: Round. C is round, F is square. |
| 1 | Gauge scale: MPa. 1 is MPa, 2 is psi, 3 is bar. |
| W | Filtering grade 5 µm. Only 40 µm (blank) and 5 µm (W) exist. |
| (blank) | PT thread. PT is the default; G is BSPP and T is NPT. |
| (blank) | No reverse-flow valve (the default). |
Field order is size, port, drain, type, gauge, shape, scale, grade, thread, reflux — there is no bracket position on a combination set. Constituent units, orderable separately as spares: GFR200-06 filter regulator and GL200-06 lubricator.
Size Class & How It Differs From GC
- GFC200PT1/8" - PT1/4"
- GFC300PT1/4" - PT1/2"
- GFC400PT3/8" - PT1/2"
- GFC600PT3/4" - PT1"
A GFC is two units because filtering and regulating share one body. A GC is three separate units — filter, regulator and lubricator. Both filter, regulate and lubricate; the GFC is the shorter assembly, the GC keeps the filter and regulator serviceable as separate bodies.
| This model | GFC200 · PT1/8" · 5 µm |
|---|---|
| One size up | GFC300 |
| Three-unit equivalent | GC200-06 |
| Build order | Filter regulator first, lubricator last |
Where the AirTAC GFC200-06 Combination Unit (GFC20006MLC1W) Is Used
Paint spray guns in an auto body booth
Supply spray guns with air filtered to 5 um so fine particles do not mark the finish, with regulated pressure and a light oil mist for the gun trigger mechanism.
Pneumatic sample pumps in a laboratory
Treat the air feeding diaphragm sample pumps and small lab actuators, where the 5 um element helps keep particulate out of sensitive pneumatic circuits.
Solenoid valve bank on a bottling line
Feed a manifold of solenoid valves controlling filler and capper functions, with the low-pressure type regulator holding a moderate set pressure and the lubricator conditioning air for the actuators downstream.
Is the AirTAC GFC200-06 Combination Unit (GFC20006MLC1W) the Right Set?
The 200 size with PT1/8 ports is the smallest step of the G series; move to 300/400/600 when the port or flow requirement grows. The W in this code selects the 5 um element instead of the 40 um standard, a real choice when downstream equipment needs finer particulate removal. Manual drain means hand-draining the bowl at intervals, with automatic and differential-pressure drain codes for unattended installations. The round external gauge is scaled in MPa (scale 1); an embedded square gauge with psi or bar scale is available. PT thread is standard, G (BSPP) and NPT are catalogue options. Flow is published as curves, not a single rating, so ask us to confirm sizing against your application before ordering.
Quick checklist
- ✓ Body size for your peak flow (PT1/8" here)
- ✓ Element 40 µm or 5 µm
- ✓ Drain sets the regulating band
- ✓ Gauge fitted, shape and scale
- ✓ Two-unit (GFC) or three-unit (GC) layout
- ✓ Oil mist acceptable downstream
Installation & Maintenance Notes
- check Install with the airflow arrow: filter regulator first, lubricator last.
- check Mount vertically, bowls down.
- check Keep inlet pressure at or below 1.0 MPa (145 psi).
- check Adjust only within 0.05 - 0.9 MPa (7 - 130 psi).
- check Drain condensate before the bowl fills; check the oil level.
- check Keep the set above freezing (-5 to +70 °C, unfreeze).
The PC bowls must not be cleaned with solvents — wipe them with a dry cloth. The lubricator adds an oil mist downstream, so if any branch must stay oil-free, take that branch off before the lubricator or use a GFR200-06 filter regulator on its own.
AirTAC GFC200-06 Combination Unit (GFC20006MLC1W) FAQ
AirTAC publishes flow for the G series as capacity curves rather than a single rated figure, so there is no one number to quote. Tell us your supply pressure, set pressure and equipment demand and we will confirm the sizing from the datasheet on request.
It selects the 5 um filtration element instead of the 40 um standard, for finer particulate removal in the filter-regulator half of the set. Everything else in the code stays the same: 200 size, PT1/8 ports, manual drain, low-pressure type and a round external gauge in MPa. Element grade, drain type and gauge scale are the main choices to weigh when decoding this family.
