AirTAC GFC200-06 Combination Unit (GFC20006MLF1)
The AirTAC AirTAC GFC200-06 Combination Unit (GFC20006MLF1) is a genuine G-series two-unit air-preparation set: a filter regulator that filters and regulates in one body, coupled to a lubricator. Two bodies do the work of three, with PT1/8" ports, a 40 µm element, a manual drain and regulation over 0.05 - 0.9 MPa (7 - 130 psi).
- TypeTwo-unit set (F.R. + L.)
- Port sizePT1/8"
- Regulating range0.05 - 0.9 MPa (7 - 130 psi)
- Filtering grade40 µm
- DrainManual drain
- Bowl materialPC
- Pressure gaugeFitted
- ThreadPT
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the AirTAC GFC200-06 Combination Unit (GFC20006MLF1)
The AirTAC GFC series is a two-unit air-treatment set pairing a filter-regulator with a lubricator, so one assembly removes water and particulate, holds a set downstream pressure and meters oil mist into the air line. This GFC20006MLF1 is the 200 size with PT1/8 standard ports, a manual drain on the polycarbonate filter bowl, the low-pressure type regulator with a 0.05-0.9 MPa (7-130 psi) adjustment span, the embedded square pressure gauge reading in MPa, and the standard 40 um filtration element. Operating temperature is -5 to 70 C, non-freezing.
This is a genuine AirTAC part. The G series covers 200, 300, 400 and 600 sizes with ports from 1/8 to 1 inch, and options including drain type, a 5 um element, gauge scale and G (BSPP) or NPT thread instead of the PT standard. Rated flow is published as curves rather than a single number, so we confirm the datasheet and sizing figures on request.
AirTAC GFC200-06 Combination Unit (GFC20006MLF1) Technical Specifications
| Model | AirTAC GFC200-06 Combination Unit (GFC20006MLF1) |
|---|---|
| Series | GFC200 two-unit set |
| Composition | Filter regulator + lubricator (2 units) |
| Port size | PT1/8" (PT thread) |
| Filtering grade | 40 µm |
| Regulating range | 0.05 - 0.9 MPa (7 - 130 psi) |
| Pressure type | Low-pressure type |
| Fluid | Compressed air |
|---|---|
| Max. working pressure | 1.0 MPa (145 psi) |
| Temperature range | -5 to +70 °C (unfreeze) |
| Drain type | Manual drain |
| Bowl material | PC |
| Pressure gauge | Fitted — square, MPa scale |
| Reflux valve | Not fitted |
Specifications follow the official AirTAC G-series air-preparation data. The regulating band is set by the drain type: automatic and differential-pressure drains regulate 0.15 - 0.9 MPa, a manual drain regulates 0.05 - 0.9 MPa. The low-pressure type adjusts over a lower band than standard; we confirm the exact figures from the factory datasheet. The set has no separate bracket code — the two units couple together with their own mounting hardware. Flow curves, weight and outline dimensions are not published in our data set — ask us and we will confirm from the factory datasheet.
Model Code: AirTAC GFC200-06 Combination Unit (GFC20006MLF1)
| GFC200 | G-series two-unit set, 200 body — sets the port range. |
|---|---|
| 06 | Port size PT1/8". This body offers 06 = PT1/8", 08 = PT1/4". |
| M | Drain: Manual drain — this also sets the regulating band (0.05 - 0.9 MPa (7 - 130 psi)). |
| L | Low-pressure type. Blank is standard, L is the low-pressure type. |
| (blank) | Pressure gauge fitted (blank). |
| F | Gauge shape: Square. C is round, F is square. |
| 1 | Gauge scale: MPa. 1 is MPa, 2 is psi, 3 is bar. |
| (blank) | Filtering grade 40 µm. Only 40 µm (blank) and 5 µm (W) exist. |
| (blank) | PT thread. PT is the default; G is BSPP and T is NPT. |
| (blank) | No reverse-flow valve (the default). |
Field order is size, port, drain, type, gauge, shape, scale, grade, thread, reflux — there is no bracket position on a combination set. Constituent units, orderable separately as spares: GFR200-06 filter regulator and GL200-06 lubricator.
Size Class & How It Differs From GC
- GFC200PT1/8" - PT1/4"
- GFC300PT1/4" - PT1/2"
- GFC400PT3/8" - PT1/2"
- GFC600PT3/4" - PT1"
A GFC is two units because filtering and regulating share one body. A GC is three separate units — filter, regulator and lubricator. Both filter, regulate and lubricate; the GFC is the shorter assembly, the GC keeps the filter and regulator serviceable as separate bodies.
| This model | GFC200 · PT1/8" · 40 µm |
|---|---|
| One size up | GFC300 |
| Three-unit equivalent | GC200-06 |
| Build order | Filter regulator first, lubricator last |
Where the AirTAC GFC200-06 Combination Unit (GFC20006MLF1) Is Used
Assembly-cell air prep at the drop header
Mount the set at the air drop of a manual assembly cell so filtered, regulated, lubricated air reaches screwdrivers and clamping fixtures, with the embedded square gauge visible on the panel.
Pick-and-place gripper supply
Condition the air feeding gripper cylinders and suction ejectors on a handling station, with the low-pressure type regulator set to a gentle pressure for light components.
Nail gun supply in a truss plant
Feed pneumatic nailers on a truss or framing line with filtered air and oil mist, and drain the bowl by hand as part of the daily start-up check.
Is the AirTAC GFC200-06 Combination Unit (GFC20006MLF1) the Right Set?
The 200 size with PT1/8 ports is the compact step of the G series; step to 300/400/600 for larger ports and more flow. The manual drain suits attended installations where the bowl is drained by hand, while automatic and differential-pressure drain codes serve unattended drops. Filtration is the 40 um standard, with the W suffix giving 5 um. Here the gauge is the embedded square type on MPa scale (scale 1); the round external gauge and psi or bar scales are alternative codes. PT thread is standard, with G (BSPP) and NPT as catalogue options. Flow is published as curves, not a single rating, so ask us to confirm sizing against your application before ordering.
Quick checklist
- ✓ Body size for your peak flow (PT1/8" here)
- ✓ Element 40 µm or 5 µm
- ✓ Drain sets the regulating band
- ✓ Gauge fitted, shape and scale
- ✓ Two-unit (GFC) or three-unit (GC) layout
- ✓ Oil mist acceptable downstream
Installation & Maintenance Notes
- check Install with the airflow arrow: filter regulator first, lubricator last.
- check Mount vertically, bowls down.
- check Keep inlet pressure at or below 1.0 MPa (145 psi).
- check Adjust only within 0.05 - 0.9 MPa (7 - 130 psi).
- check Drain condensate before the bowl fills; check the oil level.
- check Keep the set above freezing (-5 to +70 °C, unfreeze).
The PC bowls must not be cleaned with solvents — wipe them with a dry cloth. The lubricator adds an oil mist downstream, so if any branch must stay oil-free, take that branch off before the lubricator or use a GFR200-06 filter regulator on its own.
AirTAC GFC200-06 Combination Unit (GFC20006MLF1) FAQ
Flow for the G series is published as capacity curves, not as a single rated figure, so we do not state a number here. Share your supply pressure, set pressure and downstream demand and we will confirm the sizing from the datasheet on request.
The gauge position F selects the embedded square pressure gauge, here on MPa scale (scale 1). Round external gauges are the alternative body style, and scales 2 and 3 give psi and bar readings. Alongside gauge choice, the main decode decisions for this family are drain type and filter grade, with G (BSPP) or NPT thread available against the PT standard.
