Airtac GFR Filter Regulator GFR20006C1W
2. Press-lock mechanism with self-retaining function prevents pressure setting deviations from external interference;
3. Balanced-design pressure regulation system ensures stable adjustment with minimal drift and superior pressure characteristics;
4. Low-pressure variant available (0.4MPa max adjustable pressure) alongside standard configuration;
5. Innovative vortex-inducing structure enhances liquid-gas separation efficiency and reliably filters solid particulates;
6. Selectable filtration precision: 5μm or 40μm;
7. Three drainage configurations: manual, differential pressure-activated, and automatic discharge;
8. Optional fixed mounting bracket for enhanced stability.
Category: Pressure Regulating Filters | Brand: AIRTAC | Series: GFR
AirTAC GFR20006C1W Pressure Regulating Filter Specifications
- Model: GFR20006C1W
- Type: Combined pressure regulator + 40μm filter
- Port size: PT1/4 (BSPP thread)
- Operating pressure: 0.05–0.9 MPa
- Max flow rate: 2000 NL/min
- Filter element: Sintered bronze (washable)
- Pressure gauge: Integrated 1/8" dial (0-1.0 MPa scale)
- Body material: PA66+GF (30% glass fiber reinforced)
- Seal material: NBR + PUR composite
- Temperature range: -20℃ to 60℃
- Condensate drain: Manual push-button with dust shield
- Weight: 320g ±5g
- Dimensions: 98mm(H) × 50mm(W) × 50mm(D)
- Protection rating: IP42 (splash & dust resistant)
Modular filtration-regulator unit featuring precision pressure stabilization and particulate removal. The dual-chamber design separates filtration and regulation stages, with a transparent bowl for visual contamination monitoring. Includes anti-vibration gauge and ergonomic adjustment knob with ±2% pressure accuracy. Compatible with ISO 8573-1 air quality standards.
- Pneumatic tool air line conditioning
- Packaging machinery pressure stabilization
- Automated assembly line air preparation
- Medical device pneumatic systems
- Food processing equipment (FDA-compliant seals)
Maintenance protocol:
Drain condensate daily in high-humidity environments. Replace filter element when
pressure drop exceeds 0.05MPa. Use upstream lubricator for extended seal life.
- Install vertically with arrow marking airflow direction
- Precede unit with coarse filter (5μm+) in dirty environments
- Allow 25mm clearance below bowl for drainage access
- Lock adjustment knob after setting with 2Nm torque
| Property | Property Value |
|---|---|
| sku | GFR20006C1W |
| Port Size | PT1/8 |
